slip::DenseVector3dField3d< T > Class Template Reference

This is a Dense Vector3d Field. This container statisfies the BidirectionnalContainer concepts of the STL. It is also an 3d extension of the RandomAccessContainer concept. That is to say the bracket element access is replaced by the triple bracket element access. It is a specialization of GenericMultiComponent3d using Vector3d blocks. It implements arithmetic and mathematical operators and read/write methods (tecplot and gnuplot file format...). Contrary to slip::RegularVector3dField3d, this container is not associated with a grid. More...

#include <DenseVector3dField3d.hpp>

Inheritance diagram for slip::DenseVector3dField3d< T >:

Public Types
typedef slip::Vector3d< T >	value_type
typedef DenseVector3dField3d< T >	self
typedef GenericMultiComponent3d < slip::Vector3d< T > >	base
typedef value_type *	pointer
typedef const value_type *	const_pointer
typedef value_type &	reference
typedef const value_type &	const_reference
typedef ptrdiff_t	difference_type
typedef std::size_t	size_type
typedef pointer	iterator
typedef const_pointer	const_iterator
typedef std::reverse_iterator < iterator >	reverse_iterator
typedef std::reverse_iterator < const_iterator >	const_reverse_iterator
typedef pointer	row_iterator
typedef const_pointer	const_row_iterator
typedef slip::stride_iterator < pointer >	col_iterator
typedef slip::stride_iterator < const_pointer >	const_col_iterator
typedef std::reverse_iterator < iterator >	reverse_row_iterator
typedef std::reverse_iterator < const_iterator >	const_reverse_row_iterator
typedef std::reverse_iterator < col_iterator >	reverse_col_iterator
typedef std::reverse_iterator < const_col_iterator >	const_reverse_col_iterator
typedef slip::GenericMultiComponent3d < slip::Vector3d< T > >::iterator3d	iterator3d
typedef slip::GenericMultiComponent3d < slip::Vector3d< T > >::const_iterator2d	const_iterator3d
typedef T	vector3d_value_type
typedef vector3d_value_type *	vector3d_pointer
typedef const vector3d_value_type *	const_vector3d_pointer
typedef vector3d_value_type &	vector3d_reference
typedef const vector3d_value_type	const_vector3d_reference
typedef slip::kstride_iterator < vector3d_pointer, 3 >	vector3d_iterator
typedef slip::kstride_iterator < const_vector3d_pointer, 3 >	const_vector3d_iterator
typedef slip::lin_alg_traits < value_type >::value_type	norm_type
typedef const GenericMultiComponent3d < slip::Vector3d< T > >	const_self
typedef slip::stride_iterator < pointer >	slice_iterator
typedef slip::stride_iterator < const_pointer >	const_slice_iterator
typedef slip::stride_iterator < slice_iterator >	slice_range_iterator
typedef slip::stride_iterator < const_slice_iterator >	const_slice_range_iterator
typedef slip::stride_iterator < pointer >	row_range_iterator
typedef slip::stride_iterator < const_pointer >	const_row_range_iterator
typedef slip::stride_iterator < col_iterator >	col_range_iterator
typedef slip::stride_iterator < const_col_iterator >	const_col_range_iterator
typedef std::reverse_iterator < slice_iterator >	reverse_slice_iterator
typedef std::reverse_iterator < const_slice_iterator >	const_reverse_slice_iterator
typedef std::reverse_iterator < slice_range_iterator >	reverse_slice_range_iterator
typedef std::reverse_iterator < const_slice_range_iterator >	const_reverse_slice_range_iterator
typedef std::reverse_iterator < row_range_iterator >	reverse_row_range_iterator
typedef std::reverse_iterator < const_row_range_iterator >	const_reverse_row_range_iterator
typedef std::reverse_iterator < col_range_iterator >	reverse_col_range_iterator
typedef std::reverse_iterator < const_col_range_iterator >	const_reverse_col_range_iterator
typedef slip::Array3d < slip::Vector3d< T > >::iterator2d	iterator2d
typedef slip::Array3d < slip::Vector3d< T > >::const_iterator2d	const_iterator2d
typedef std::reverse_iterator < iterator2d >	reverse_iterator2d
typedef std::reverse_iterator < const_iterator2d >	const_reverse_iterator2d
typedef slip::Array3d < slip::Vector3d< T > >::iterator3d_range	iterator3d_range
typedef slip::Array3d < slip::Vector3d< T > >::const_iterator3d_range	const_iterator3d_range
typedef std::reverse_iterator < iterator3d >	reverse_iterator3d
typedef std::reverse_iterator < const_iterator3d >	const_reverse_iterator3d
typedef std::reverse_iterator < iterator3d_range >	reverse_iterator3d_range
typedef std::reverse_iterator < const_iterator3d_range >	const_reverse_iterator3d_range
typedef slip::Vector3d< T > ::value_type	block_value_type
typedef block_value_type *	block_pointer
typedef const block_value_type *	const_block_pointer
typedef block_value_type &	block_reference
typedef const block_value_type	const_block_reference
typedef slip::kstride_iterator < typename slip::Vector3d< T > ::pointer, slip::Vector3d< T > ::SIZE >	component_iterator
typedef slip::kstride_iterator < typename slip::Vector3d< T > ::const_pointer, slip::Vector3d< T >::SIZE >	const_component_iterator
typedef std::reverse_iterator < component_iterator >	reverse_component_iterator
typedef std::reverse_iterator < const_component_iterator >	const_reverse_component_iterator
typedef slip::stride_iterator < block_pointer >	component_slice_iterator
typedef slip::stride_iterator < const_block_pointer >	const_component_slice_iterator
typedef slip::stride_iterator < block_pointer >	component_slice_range_iterator
typedef slip::stride_iterator < const_block_pointer >	const_component_slice_range_iterator
typedef component_iterator	component_row_iterator
typedef const_component_iterator	const_component_row_iterator
typedef slip::stride_iterator < block_pointer >	component_row_range_iterator
typedef slip::stride_iterator < const_block_pointer >	const_component_row_range_iterator
typedef slip::stride_iterator < block_pointer >	component_col_iterator
typedef slip::stride_iterator < const_block_pointer >	const_component_col_iterator
typedef slip::stride_iterator < block_pointer >	component_col_range_iterator
typedef slip::stride_iterator < const_block_pointer >	const_component_col_range_iterator
typedef std::reverse_iterator < component_slice_iterator >	reverse_component_slice_iterator
typedef std::reverse_iterator < const_component_slice_iterator >	const_reverse_component_slice_iterator
typedef std::reverse_iterator < component_slice_range_iterator >	reverse_component_slice_range_iterator
typedef std::reverse_iterator < const_component_slice_range_iterator >	const_reverse_component_slice_range_iterator
typedef std::reverse_iterator < component_row_iterator >	reverse_component_row_iterator
typedef std::reverse_iterator < const_component_row_iterator >	const_reverse_component_row_iterator
typedef std::reverse_iterator < component_row_range_iterator >	reverse_component_row_range_iterator
typedef std::reverse_iterator < const_component_row_range_iterator >	const_reverse_component_row_range_iterator
typedef std::reverse_iterator < component_col_iterator >	reverse_component_col_iterator
typedef std::reverse_iterator < const_component_col_iterator >	const_reverse_component_col_iterator
typedef std::reverse_iterator < component_col_range_iterator >	reverse_component_col_range_iterator
typedef std::reverse_iterator < const_component_col_range_iterator >	const_reverse_component_col_range_iterator
typedef slip::component_iterator3d_box < self, slip::Vector3d< T > ::SIZE >	component_iterator3d
typedef std::reverse_iterator < component_iterator3d >	reverse_component_iterator3d
typedef slip::const_component_iterator3d_box < const_self, slip::Vector3d < T >::SIZE >	const_component_iterator3d
typedef std::reverse_iterator < const_component_iterator3d >	const_reverse_component_iterator3d
typedef slip::component_iterator3d_range < self, slip::Vector3d< T > ::SIZE >	component_iterator3d_range
typedef std::reverse_iterator < component_iterator3d_range >	reverse_component_iterator3d_range
typedef slip::const_component_iterator3d_range < const_self, slip::Vector3d < T >::SIZE >	const_component_iterator3d_range
typedef std::reverse_iterator < const_component_iterator3d_range >	const_reverse_component_iterator3d_range
typedef iterator3d	default_iterator
typedef const_iterator3d	const_default_iterator

Public Member Functions
std::string	name () const
	Returns the name of the class. More...
void	resize (const size_type slices, const size_type rows, const size_type cols, const slip::Vector3d< T > &val=slip::Vector3d< T >())
	Resizes a GenericMultiComponent3d. More...
size_type	dim1 () const
	Returns the number of slices (first dimension size) in the GenericMultiComponent3d. More...
size_type	slices () const
	Returns the number of slices (first dimension size) in the GenericMultiComponent3d. More...
size_type	dim2 () const
	Returns the number of rows (second dimension size) in the GenericMultiComponent3d. More...
size_type	rows () const
	Returns the number of rows (first dimension size) in the GenericMultiComponent3d. More...
size_type	dim3 () const
	Returns the number of columns (third dimension size) in the GenericMultiComponent3d. More...
size_type	columns () const
	Returns the number of columns (third dimension size) in the GenericMultiComponent3d. More...
size_type	cols () const
	Returns the number of columns (third dimension size) in the GenericMultiComponent3d. More...
size_type	size () const
	Returns the number of elements in the GenericMultiComponent3d. More...
size_type	max_size () const
	Returns the maximal size (number of elements) in the GenericMultiComponent3d. More...
size_type	slice_size () const
	Returns the number of elements in a slice of the GenericMultiComponent3d. More...
bool	empty () const
	Returns true if the GenericMultiComponent3d is empty. (Thus size() == 0) More...
void	swap (self &M)
	Swaps data with another GenericMultiComponent3d. More...
slip::Vector3d< T >	min () const
	Returns the min elements of the GenericMultiComponent3d according to the operator <. More...
slip::Vector3d< T >	max () const
	Returns the max elements of the GenericMultiComponent3d according to the operator <. More...
GenericMultiComponent3d < slip::Vector3d< T > > &	apply (slip::Vector3d< T >(*fun)(slip::Vector3d< T >))
	Returns the sums of the elements of the GenericMultiComponent3d. More...
GenericMultiComponent3d < slip::Vector3d< T > > &	apply (slip::Vector3d< T >(*fun)(const slip::Vector3d< T > &))
	Applys the one-parameter C-function fun to each element of the GenericMultiComponent3d. More...
Constructors & Destructors
	DenseVector3dField3d ()
	Constructs a DenseVector3dField3d. More...
	DenseVector3dField3d (const size_type slices, const size_type rows, const size_type cols)
	Constructs a DenseVector3dField3d. More...
	DenseVector3dField3d (const size_type slices, const size_type rows, const size_type cols, const slip::Vector3d< T > &val)
	Constructs a DenseVector3dField3d initialized by the scalar value val. More...
	DenseVector3dField3d (const size_type slices, const size_type rows, const size_type cols, const T *val)
	Constructs a DenseVector3dField3d initialized by an array val. More...
	DenseVector3dField3d (const size_type slices, const size_type rows, const size_type cols, const slip::Vector3d< T > *val)
	Constructs a DenseVector3dField3d initialized by an array val. More...
template<typename InputIterator >
	DenseVector3dField3d (const size_type slices, const size_type rows, const size_type cols, InputIterator first, InputIterator last)
	Contructs a DenseVector3dField3d from a range. More...
template<typename InputIterator >
	DenseVector3dField3d (const size_type slices, const size_type rows, const size_type cols, InputIterator first1, InputIterator last1, InputIterator first2, InputIterator first3)
	Contructs a DenseVector3dField3d from a 3 ranges. More...
	DenseVector3dField3d (const self &rhs)
	Constructs a copy of the DenseVector3dField3d rhs. More...
	~DenseVector3dField3d ()
	Destructor of the DenseVector3dField3d. More...
i/o operators
void	write_tecplot (const std::string &file_path_name, const std::string &title, const std::string &zone)
	Writes a DenseVector3dField3d to a tecplot file path name. More...
void	read_tecplot (const std::string &file_path_name)
	Reads a DenseVector3dField3d from a tecplot file path name. More...
Assignment operators and methods
self &	operator= (const slip::Vector3d< T > &val)
	Affects all the element of the DenseVector3dField3d by val. More...
self &	operator= (const T &val)
	Affects all the element of the DenseVector3dField3d by val. More...
Element access operators
T &	Vx1 (const size_type k, const size_type i, const size_type j)
	Subscript access to first element of the data contained in the DenseVector3dField3d. More...
const T &	Vx1 (const size_type k, const size_type i, const size_type j) const
	Subscript access to first element of the data contained in the DenseVector3dField3d. More...
T &	u (const size_type k, const size_type i, const size_type j)
	Subscript access to first element of the data contained in the DenseVector3dField3d. More...
const T &	u (const size_type k, const size_type i, const size_type j) const
	Subscript access to first element of the data contained in the DenseVector3dField3d. More...
T &	Vx2 (const size_type k, const size_type i, const size_type j)
	Subscript access to second element of the data contained in the DenseVector3dField3d. More...
const T &	Vx2 (const size_type k, const size_type i, const size_type j) const
	Subscript access to second element of the data contained in the DenseVector3dField3d. More...
T &	v (const size_type k, const size_type i, const size_type j)
	Subscript access to second element of the data contained in the DenseVector3dField3d. More...
const T &	v (const size_type k, const size_type i, const size_type j) const
	Subscript access to second element of the data contained in the DenseVector3dField3d. More...
T &	Vx3 (const size_type k, const size_type i, const size_type j)
	Subscript access to third element of the data contained in the DenseVector3dField3d. More...
const T &	Vx3 (const size_type k, const size_type i, const size_type j) const
	Subscript access to third element of the data contained in the DenseVector3dField3d. More...
T &	w (const size_type k, const size_type i, const size_type j)
	Subscript access to third element of the data contained in the DenseVector3dField3d. More...
const T &	w (const size_type k, const size_type i, const size_type j) const
	Subscript access to third element of the data contained in the DenseVector3dField3d. More...
norm_type	norm (const size_type k, const size_type i, const size_type j) const
	Subscript access to a local norm contained in the DenseVector3dField3d. More...
Arithmetic operators
self &	operator+= (const T &val)
	Add val to each element of the DenseVector3dField3d. More...
self &	operator-= (const T &val)
self &	operator*= (const T &val)
self &	operator/= (const T &val)
self	operator- () const
self &	operator+= (const slip::Vector3d< T > &val)
	Add val to each element of the DenseVector3dField3d. More...
self &	operator-= (const slip::Vector3d< T > &val)
self &	operator*= (const slip::Vector3d< T > &val)
self &	operator/= (const slip::Vector3d< T > &val)
self &	operator+= (const self &rhs)
self &	operator-= (const self &rhs)
self &	operator*= (const self &rhs)
self &	operator/= (const self &rhs)
Mathematical operators
template<typename Container3D >
void	norm (Container3D &result)
	Computes Eucliean norm of each element in the field and write it to a Container3D. More...
One dimensional global iterators
iterator	begin ()
	Returns a read/write iterator that points to the first element in the GenericMultiComponent3d. Iteration is done in ordinary element order. More...
const_iterator	begin () const
	Returns a read-only (constant) iterator that points to the first element in the GenericMultiComponent3d. Iteration is done in ordinary element order. More...
iterator	end ()
	Returns a read/write iterator that points one past the last element in the GenericMultiComponent3d. Iteration is done in ordinary element order. More...
const_iterator	end () const
	Returns a read-only (constant) iterator that points one past the last element in the GenericMultiComponent3d. Iteration is done in ordinary element order. More...
reverse_iterator	rbegin ()
	Returns a read/write reverse iterator that points to the last element in the GenericMultiComponent3d. Iteration is done in reverse element order. More...
const_reverse_iterator	rbegin () const
	Returns a read-only (constant) reverse iterator that points to the last element in the GenericMultiComponent3d. Iteration is done in reverse element order. More...
reverse_iterator	rend ()
	Returns a read/write reverse iterator that points to one before the first element in the GenericMultiComponent3d. Iteration is done in reverse element order. More...
const_reverse_iterator	rend () const
	Returns a read-only (constant) reverse iterator that points to one before the first element in the GenericMultiComponent3d. Iteration is done in reverse element order. More...
One dimensional component global iterators
component_iterator	begin (const std::size_t component)
	Returns a read/write iterator that points to the first element in the GenericMultiComponent3d. Iteration is done in ordinary element order. More...
const_component_iterator	begin (const std::size_t component) const
	Returns a read-only (constant) iterator that points to the first element in the GenericMultiComponent3d. Iteration is done in ordinary element order. More...
component_iterator	end (const std::size_t component)
	Returns a read/write iterator that points one past the last element in the GenericMultiComponent3d. Iteration is done in ordinary element order. More...
const_component_iterator	end (const std::size_t component) const
	Returns a read-only (constant) iterator that points one past the last element in the GenericMultiComponent3d. Iteration is done in ordinary element order. More...
reverse_component_iterator	rbegin (const std::size_t component)
	Returns a read/write iterator that points to the first element in the GenericMultiComponent3d. Iteration is done in ordinary element order. More...
const_reverse_component_iterator	rbegin (const std::size_t component) const
	Returns a read-only (constant) iterator that points to the first element in the GenericMultiComponent3d. Iteration is done in ordinary element order. More...
reverse_component_iterator	rend (const std::size_t component)
	Returns a read/write iterator that points one past the last element in the GenericMultiComponent3d. Iteration is done in ordinary element order. More...
const_reverse_component_iterator	rend (const std::size_t component) const
	Returns a read-only (constant) iterator that points one past the last element in the GenericMultiComponent3d. Iteration is done in ordinary element order. More...
One dimensional slice iterators
slice_iterator	slice_begin (const size_type row, const size_type col)
	Returns a read/write iterator that points to the first element of the line (row,col) threw the slices in the GenericMultiComponent3d. Iteration is done in ordinary element order (increasing slice number). More...
const_slice_iterator	slice_begin (const size_type row, const size_type col) const
	Returns a read-only (constant) iterator that points to the first element of the line (row,col) threw the slices in the GenericMultiComponent3d. Iteration is done in ordinary element order (increasing slice number). More...
slice_iterator	slice_end (const size_type row, const size_type col)
	Returns a read/write iterator that points to the one past the end element of the line (row,col) threw the slices in the GenericMultiComponent3d. Iteration is done in ordinary element order (increasing slice number). More...
const_slice_iterator	slice_end (const size_type row, const size_type col) const
	Returns a read-only (constant) iterator that points to the one past the end element of the line (row,col) threw the slices in the GenericMultiComponent3d. Iteration is done in ordinary element order (increasing slice number). More...
reverse_slice_iterator	slice_rbegin (const size_type row, const size_type col)
	Returns a read/write iterator that points to the last element of the line (row,col) threw the slices in the GenericMultiComponent3d. Iteration is done in reverse element order (decreasing slice number). More...
const_reverse_slice_iterator	slice_rbegin (const size_type row, const size_type col) const
	Returns a read-only (constant) iterator that points to the last element of the line (row,col) threw the slices in the GenericMultiComponent3d. Iteration is done in reverse element order (decreasing slice number). More...
reverse_slice_iterator	slice_rend (const size_type row, const size_type col)
	Returns a read/write iterator that points to the one before the first element of the line (row,col) threw the slices in the GenericMultiComponent3d. Iteration is done in reverse element order (decreasing slice number). More...
const_reverse_slice_iterator	slice_rend (const size_type row, const size_type col) const
	Returns a read (constant) iterator that points to the one before the first element of the line (row,col) threw the slices in the GenericMultiComponent3d. Iteration is done in reverse element order (decreasing slice number). More...
One dimensional slice range iterators
slice_range_iterator	slice_begin (const size_type row, const size_type col, const slip::Range< int > &range)
	Returns a read/write iterator that points to the first element of the Range range of the of the line (row,col) threw the slices in the GenericMultiComponent3d. Iteration is done in ordinary element order according to the Range. More...
const_slice_range_iterator	slice_begin (const size_type row, const size_type col, const slip::Range< int > &range) const
	Returns a read only (constant) iterator that points to the first element of the Range range of the of the line (row,col) threw the slices in the GenericMultiComponent3d. Iteration is done in ordinary element order according to the Range. More...
slice_range_iterator	slice_end (const size_type row, const size_type col, const slip::Range< int > &range)
	Returns a read/write iterator that points one past the end element of the Range range of the of the line (row,col) threw the slices in the GenericMultiComponent3d. Iteration is done in ordinary element order according to the Range. More...
const_slice_range_iterator	slice_end (const size_type row, const size_type col, const slip::Range< int > &range) const
	Returns a read_only iterator that points one past the last element of the Range range of the of the line (row,col) threw the slices in the GenericMultiComponent3d. Iteration is done in ordinary element order according to the Range. More...
reverse_slice_range_iterator	slice_rbegin (const size_type row, const size_type col, const slip::Range< int > &range)
	Returns a read/write iterator that points to the last element of the Range range of the of the line (row,col) threw the slices in the GenericMultiComponent3d. Iteration is done in the reverse element order according to the Range. More...
const_reverse_slice_range_iterator	slice_rbegin (const size_type row, const size_type col, const slip::Range< int > &range) const
	Returns a read only (constant) iterator that points to the last element of the Range range of the of the line (row,col) threw the slices in the GenericMultiComponent3d. Iteration is done in reverse element order according to the Range. More...
reverse_slice_range_iterator	slice_rend (const size_type row, const size_type col, const slip::Range< int > &range)
	Returns a read/write iterator that points to the first element of the Range range of the of the line (row,col) threw the slices in the GenericMultiComponent3d. Iteration is done in reverse element order according to the Range. More...
const_reverse_slice_range_iterator	slice_rend (const size_type row, const size_type col, const slip::Range< int > &range) const
	Returns a read_only iterator that points one past the lastto the first element of the Range range of the of the line (row,col) threw the slices in the GenericMultiComponent3d. Iteration is done in reverse element order according to the Range. More...
One dimensional component slice iterators
component_slice_iterator	slice_begin (const std::size_t component, const size_type row, const size_type col)
	Returns a read/write iterator that points to the first element of the line (row,col) threw the slices in the GenericMultiComponent3d. Iteration is done in ordinary element order (increasing slice number). More...
const_component_slice_iterator	slice_begin (const std::size_t component, const size_type row, const size_type col) const
	Returns a read-only (constant) iterator that points to the first element of the line (row,col) threw the slices in the GenericMultiComponent3d. Iteration is done in ordinary element order (increasing slice number). More...
component_slice_iterator	slice_end (const std::size_t component, const size_type row, const size_type col)
	Returns a read/write iterator that points to the one past the end element of the line (row,col) threw the slices in the GenericMultiComponent3d. Iteration is done in ordinary element order (increasing slice number). More...
const_component_slice_iterator	slice_end (const std::size_t component, const size_type row, const size_type col) const
	Returns a read-only (constant) iterator that points to the one past the end element of the line (row,col) threw the slices in the GenericMultiComponent3d. Iteration is done in ordinary element order (increasing slice number). More...
reverse_component_slice_iterator	slice_rbegin (const std::size_t component, const size_type row, const size_type col)
	Returns a read/write iterator that points to the last element of the line (row,col) threw the slices in the GenericMultiComponent3d. Iteration is done in reverse element order (decreasing slice number). More...
const_reverse_component_slice_iterator	slice_rbegin (const std::size_t component, const size_type row, const size_type col) const
	Returns a read-only (constant) iterator that points to the last element of the line (row,col) threw the slices in the GenericMultiComponent3d. Iteration is done in reverse element order (decreasing slice number). More...
reverse_component_slice_iterator	slice_rend (const std::size_t component, const size_type row, const size_type col)
	Returns a read/write iterator that points to the one before the first element of the line (row,col) threw the slices in the GenericMultiComponent3d. Iteration is done in reverse element order (decreasing slice number). More...
const_reverse_component_slice_iterator	slice_rend (const std::size_t component, const size_type row, const size_type col) const
	Returns a read (constant) iterator that points to the one before the first element of the line (row,col) threw the slices in the GenericMultiComponent3d. Iteration is done in reverse element order (decreasing slice number). More...
One dimensional component slice range iterators
component_slice_range_iterator	slice_begin (const std::size_t component, const size_type row, const size_type col, const slip::Range< int > &range)
	Returns a read/write iterator that points to the first element of the Range range of the of the line (row,col) threw the slices in the GenericMultiComponent3d. Iteration is done in ordinary element order according to the Range. More...
const_component_slice_range_iterator	slice_begin (const std::size_t component, const size_type row, const size_type col, const slip::Range< int > &range) const
	Returns a read only (constant) iterator that points to the first element of the Range range of the of the line (row,col) threw the slices in the GenericMultiComponent3d. Iteration is done in ordinary element order according to the Range. More...
component_slice_range_iterator	slice_end (const std::size_t component, const size_type row, const size_type col, const slip::Range< int > &range)
	Returns a read/write iterator that points one past the end element of the Range range of the of the line (row,col) threw the slices in the GenericMultiComponent3d. Iteration is done in ordinary element order according to the Range. More...
const_component_slice_range_iterator	slice_end (const std::size_t component, const size_type row, const size_type col, const slip::Range< int > &range) const
	Returns a read_only iterator that points one past the last element of the Range range of the of the line (row,col) threw the slices in the GenericMultiComponent3d. Iteration is done in ordinary element order according to the Range. More...
reverse_component_slice_range_iterator	slice_rbegin (const std::size_t component, const size_type row, const size_type col, const slip::Range< int > &range)
	Returns a read/write iterator that points to the last element of the Range range of the of the line (row,col) threw the slices in the GenericMultiComponent3d. Iteration is done in the reverse element order according to the Range. More...
const_reverse_component_slice_range_iterator	slice_rbegin (const std::size_t component, const size_type row, const size_type col, const slip::Range< int > &range) const
	Returns a read only (constant) iterator that points to the last element of the Range range of the of the line (row,col) threw the slices in the GenericMultiComponent3d. Iteration is done in reverse element order according to the Range. More...
reverse_component_slice_range_iterator	slice_rend (const std::size_t component, const size_type row, const size_type col, const slip::Range< int > &range)
	Returns a read/write iterator that points to the first element of the Range range of the of the line (row,col) threw the slices in the GenericMultiComponent3d. Iteration is done in reverse element order according to the Range. More...
const_reverse_component_slice_range_iterator	slice_rend (const std::size_t component, const size_type row, const size_type col, const slip::Range< int > &range) const
	Returns a read_only iterator that points one past the lastto the first element of the Range range of the of the line (row,col) threw the slices in the GenericMultiComponent3d. Iteration is done in reverse element order according to the Range. More...
One dimensional row iterators
row_iterator	row_begin (const size_type slice, const size_type row)
	Returns a read/write iterator that points to the first element of the row row of the slice slice in the GenericMultiComponent3d. Iteration is done in ordinary element order. More...
const_row_iterator	row_begin (const size_type slice, const size_type row) const
	Returns a read_only iterator that points to the first element of the row row of the slice slice in the GenericMultiComponent3d. Iteration is done in ordinary element order. More...
row_iterator	row_end (const size_type slice, const size_type row)
	Returns a read/write iterator that points to the past-the-end element of the row row of the slice slice in the GenericMultiComponent3d. Iteration is done in ordinary element order. More...
const_row_iterator	row_end (const size_type slice, const size_type row) const
	Returns a read_only iterator that points to the past-the-end element of the row row of the slice slice in the GenericMultiComponent3d. Iteration is done in ordinary element order. More...
reverse_row_iterator	row_rbegin (const size_type slice, const size_type row)
	Returns a read/write reverse iterator that points to the last element of the row row of the slice slice in the GenericMultiComponent3d. Iteration is done in reverse element order. More...
const_reverse_row_iterator	row_rbegin (const size_type slice, const size_type row) const
	Returns a read_only reverse iterator that points to the last element of the row row of the slice slice in the GenericMultiComponent3d. Iteration is done in reverse element order. More...
reverse_row_iterator	row_rend (const size_type slice, const size_type row)
	Returns a read/write reverse iterator that points to the first element of the row row of the slice slice in the GenericMultiComponent3d. Iteration is done in reverse element order. More...
const_reverse_row_iterator	row_rend (const size_type slice, const size_type row) const
	Returns a read_only reverse iterator that points to the first element of the row row of the slice slice in the GenericMultiComponent3d. Iteration is done in reverse element order. More...
One dimensional row range iterators
row_range_iterator	row_begin (const size_type slice, const size_type row, const slip::Range< int > &range)
	Returns a read/write iterator that points to the first element of the Range range of the row row in the GenericMultiComponent3d. Iteration is done in ordinary element order according to the Range. More...
const_row_range_iterator	row_begin (const size_type slice, const size_type row, const slip::Range< int > &range) const
	Returns a read-only iterator that points to the first element of the Range range of the row row in the GenericMultiComponent3d. Iteration is done in ordinary element order according to the Range. More...
row_range_iterator	row_end (const size_type slice, const size_type row, const slip::Range< int > &range)
	Returns a read/write iterator that points one past the end element of the Range range of the row row in the GenericMultiComponent3d. Iteration is done in ordinary element order according to the Range. More...
const_row_range_iterator	row_end (const size_type slice, const size_type row, const slip::Range< int > &range) const
	Returns a read_only iterator that points one past the last element of the Range range of the row row in the GenericMultiComponent3d. Iteration is done in ordinary element order according to the Range. More...
reverse_row_range_iterator	row_rbegin (const size_type slice, const size_type row, const slip::Range< int > &range)
	Returns a read-write iterator that points to the last element of the Range range of the row of a slice row and slice in the GenericMultiComponent3d. Iteration is done in the reverse element order according to the Range. More...
const_reverse_row_range_iterator	row_rbegin (const size_type slice, const size_type row, const slip::Range< int > &range) const
	Returns a read-only iterator that points to the last element of the Range range of the row of a slice row in the GenericMultiComponent3d. Iteration is done in the reverse element order according to the Range. More...
reverse_row_range_iterator	row_rend (const size_type slice, const size_type row, const slip::Range< int > &range)
	Returns a read-write iterator that points one before the first element of the Range range of the row of a slice row in the GenericMultiComponent3d. Iteration is done in the reverse element order according to the Range. More...
const_reverse_row_range_iterator	row_rend (const size_type slice, const size_type row, const slip::Range< int > &range) const
	Returns a read-only iterator that points one before the first element of the Range range of the row of a slice row in the GenericMultiComponent3d. Iteration is done in the reverse element order according to the Range. More...
One dimensional component row iterators
component_row_iterator	row_begin (const std::size_t component, const size_type slice, const size_type row)
	Returns a read/write iterator that points to the first element of the row row of the slice slice in the GenericMultiComponent3d. Iteration is done in ordinary element order. More...
const_component_row_iterator	row_begin (const std::size_t component, const size_type slice, const size_type row) const
	Returns a read_only iterator that points to the first element of the row row of the slice slice in the GenericMultiComponent3d. Iteration is done in ordinary element order. More...
component_row_iterator	row_end (const std::size_t component, const size_type slice, const size_type row)
	Returns a read/write iterator that points to the past-the-end element of the row row of the slice slice in the GenericMultiComponent3d. Iteration is done in ordinary element order. More...
const_component_row_iterator	row_end (const std::size_t component, const size_type slice, const size_type row) const
	Returns a read_only iterator that points to the past-the-end element of the row row of the slice slice in the GenericMultiComponent3d. Iteration is done in ordinary element order. More...
reverse_component_row_iterator	row_rbegin (const std::size_t component, const size_type slice, const size_type row)
	Returns a read/write reverse iterator that points to the last element of the row row of the slice slice in the GenericMultiComponent3d. Iteration is done in reverse element order. More...
const_reverse_component_row_iterator	row_rbegin (const std::size_t component, const size_type slice, const size_type row) const
	Returns a read_only reverse iterator that points to the last element of the row row of the slice slice in the GenericMultiComponent3d. Iteration is done in reverse element order. More...
reverse_component_row_iterator	row_rend (const std::size_t component, const size_type slice, const size_type row)
	Returns a read/write reverse iterator that points to the first element of the row row of the slice slice in the GenericMultiComponent3d. Iteration is done in reverse element order. More...
const_reverse_component_row_iterator	row_rend (const std::size_t component, const size_type slice, const size_type row) const
	Returns a read_only reverse iterator that points to the first element of the row row of the slice slice in the GenericMultiComponent3d. Iteration is done in reverse element order. More...
One dimensional component row range iterators
component_row_range_iterator	row_begin (const std::size_t component, const size_type slice, const size_type row, const slip::Range< int > &range)
	Returns a read/write iterator that points to the first element of the Range range of the row row in the GenericMultiComponent3d. Iteration is done in ordinary element order according to the Range. More...
const_component_row_range_iterator	row_begin (const std::size_t component, const size_type slice, const size_type row, const slip::Range< int > &range) const
	Returns a read-only iterator that points to the first element of the Range range of the row row in the GenericMultiComponent3d. Iteration is done in ordinary element order according to the Range. More...
component_row_range_iterator	row_end (const std::size_t component, const size_type slice, const size_type row, const slip::Range< int > &range)
	Returns a read/write iterator that points one past the end element of the Range range of the row row in the GenericMultiComponent3d. Iteration is done in ordinary element order according to the Range. More...
const_component_row_range_iterator	row_end (const std::size_t component, const size_type slice, const size_type row, const slip::Range< int > &range) const
	Returns a read_only iterator that points one past the last element of the Range range of the row row in the GenericMultiComponent3d. Iteration is done in ordinary element order according to the Range. More...
reverse_component_row_range_iterator	row_rbegin (const std::size_t component, const size_type slice, const size_type row, const slip::Range< int > &range)
	Returns a read-write iterator that points to the last element of the Range range of the row of a slice row and slice in the GenericMultiComponent3d. Iteration is done in the reverse element order according to the Range. More...
const_reverse_component_row_range_iterator	row_rbegin (const std::size_t component, const size_type slice, const size_type row, const slip::Range< int > &range) const
	Returns a read-only iterator that points to the last element of the Range range of the row of a slice row in the GenericMultiComponent3d. Iteration is done in the reverse element order according to the Range. More...
reverse_component_row_range_iterator	row_rend (const std::size_t component, const size_type slice, const size_type row, const slip::Range< int > &range)
	Returns a read-write iterator that points one before the first element of the Range range of the row of a slice row in the GenericMultiComponent3d. Iteration is done in the reverse element order according to the Range. More...
const_reverse_component_row_range_iterator	row_rend (const std::size_t component, const size_type slice, const size_type row, const slip::Range< int > &range) const
	Returns a read-only iterator that points one before the first element of the Range range of the row of a slice row in the GenericMultiComponent3d. Iteration is done in the reverse element order according to the Range. More...
One dimensional col iterators
col_iterator	col_begin (const size_type slice, const size_type col)
	Returns a read/write iterator that points to the first element of the column column of the slice slice in the GenericMultiComponent3d. Iteration is done modulo the number of columns. More...
const_col_iterator	col_begin (const size_type slice, const size_type col) const
	Returns a read_only iterator that points to the first element of the column column of the slice slice in the GenericMultiComponent3d. Iteration is done modulo the number of columns. More...
col_iterator	col_end (const size_type slice, const size_type col)
	Returns a read/write iterator that points to the past-the-end element of the column column of the slice slice in the GenericMultiComponent3d. Iteration is done modulo the number of columns. More...
const_col_iterator	col_end (const size_type slice, const size_type col) const
	Returns a read_only iterator that points to the past-the-end element of the column column of the slice slice in the GenericMultiComponent3d. Iteration is done modulo the number of columns. More...
reverse_col_iterator	col_rbegin (const size_type slice, const size_type col)
	Returns a read/write reverse iterator that points to the last element of the column column of the slice slice in the GenericMultiComponent3d. Iteration is done modulo the number of columns. More...
const_reverse_col_iterator	col_rbegin (const size_type slice, const size_type col) const
	Returns a read_only reverse iterator that points to the last element of the column column of the slice slice in the GenericMultiComponent3d. Iteration is done modulo the number of columns. More...
reverse_col_iterator	col_rend (const size_type slice, const size_type col)
	Returns a read/write reverse iterator that points to the first element of the column column of the slice slice in the GenericMultiComponent3d. Iteration is done modulo the number of columns. More...
const_reverse_col_iterator	col_rend (const size_type slice, const size_type col) const
	Returns a read_only reverse iterator that points to the first element of the column column of the slice slice in the GenericMultiComponent3d. Iteration is done modulo the number of columns. More...
One dimensional col range iterators
col_range_iterator	col_begin (const size_type slice, const size_type col, const slip::Range< int > &range)
	Returns a read-write iterator that points to the first element of the Range range of the col col in the GenericMultiComponent3d. Iteration is done in ordinary element order according to the Range. More...
const_col_range_iterator	col_begin (const size_type slice, const size_type col, const slip::Range< int > &range) const
	Returns a read-only iterator that points to the first element of the Range range of the col col in the GenericMultiComponent3d. Iteration is done in ordinary element order according to the Range. More...
col_range_iterator	col_end (const size_type slice, const size_type col, const slip::Range< int > &range)
	Returns a read-write iterator that points to the past the end element of the Range range of the col col in the GenericMultiComponent3d. Iteration is done in ordinary element order according to the Range. More...
const_col_range_iterator	col_end (const size_type slice, const size_type col, const slip::Range< int > &range) const
	Returns a read-only iterator that points to the past the end element of the Range range of the col col in the GenericMultiComponent3d. Iteration is done in ordinary element order according to the Range. More...
reverse_col_range_iterator	col_rbegin (const size_type slice, const size_type col, const slip::Range< int > &range)
	Returns a read-write iterator that points to the last element of the Range range of the col of a slice col in the GenericMultiComponent3d. Iteration is done in the reverse element order according to the Range. More...
const_reverse_col_range_iterator	col_rbegin (const size_type slice, const size_type col, const slip::Range< int > &range) const
	Returns a read_only iterator that points to the last element of the Range & range of the col of a slice col in the GenericMultiComponent3d. Iteration is done in the reverse element order according to the Range. More...
reverse_col_range_iterator	col_rend (const size_type slice, const size_type col, const slip::Range< int > &range)
	Returns a read-write iterator that points to one before the first element of the Range range of the col of a slice col in the GenericMultiComponent3d. Iteration is done in the reverse element order according to the Range. More...
const_reverse_col_range_iterator	col_rend (const size_type slice, const size_type col, const slip::Range< int > &range) const
	Returns a read-only iterator that points to the first element of the Range range of the col of a slice col in the GenericMultiComponent3d. Iteration is done in the reverse element order according to the Range. More...
One dimensional component col iterators
component_col_iterator	col_begin (const std::size_t component, const size_type slice, const size_type col)
	Returns a read/write iterator that points to the first element of the column column of the slice slice in the GenericMultiComponent3d. Iteration is done modulo the number of columns. More...
const_component_col_iterator	col_begin (const std::size_t component, const size_type slice, const size_type col) const
	Returns a read_only iterator that points to the first element of the column column of the slice slice in the GenericMultiComponent3d. Iteration is done modulo the number of columns. More...
component_col_iterator	col_end (const std::size_t component, const size_type slice, const size_type col)
	Returns a read/write iterator that points to the past-the-end element of the column column of the slice slice in the GenericMultiComponent3d. Iteration is done modulo the number of columns. More...
const_component_col_iterator	col_end (const std::size_t component, const size_type slice, const size_type col) const
	Returns a read_only iterator that points to the past-the-end element of the column column of the slice slice in the GenericMultiComponent3d. Iteration is done modulo the number of columns. More...
reverse_component_col_iterator	col_rbegin (const std::size_t component, const size_type slice, const size_type col)
	Returns a read/write reverse iterator that points to the last element of the column column of the slice slice in the GenericMultiComponent3d. Iteration is done modulo the number of columns. More...
const_reverse_component_col_iterator	col_rbegin (const std::size_t component, const size_type slice, const size_type col) const
	Returns a read_only reverse iterator that points to the last element of the column column of the slice slice in the GenericMultiComponent3d. Iteration is done modulo the number of columns. More...
reverse_component_col_iterator	col_rend (const std::size_t component, const size_type slice, const size_type col)
	Returns a read/write reverse iterator that points to the first element of the column column of the slice slice in the GenericMultiComponent3d. Iteration is done modulo the number of columns. More...
const_reverse_component_col_iterator	col_rend (const std::size_t component, const size_type slice, const size_type col) const
	Returns a read_only reverse iterator that points to the first element of the column column of the slice slice in the GenericMultiComponent3d. Iteration is done modulo the number of columns. More...
One dimensional component col range iterators
component_col_range_iterator	col_begin (const std::size_t component, const size_type slice, const size_type col, const slip::Range< int > &range)
	Returns a read-write iterator that points to the first element of the Range range of the col col in the GenericMultiComponent3d. Iteration is done in ordinary element order according to the Range. More...
const_component_col_range_iterator	col_begin (const std::size_t component, const size_type slice, const size_type col, const slip::Range< int > &range) const
	Returns a read-only iterator that points to the first element of the Range range of the col col in the GenericMultiComponent3d. Iteration is done in ordinary element order according to the Range. More...
component_col_range_iterator	col_end (const std::size_t component, const size_type slice, const size_type col, const slip::Range< int > &range)
	Returns a read-write iterator that points to the past the end element of the Range range of the col col in the GenericMultiComponent3d. Iteration is done in ordinary element order according to the Range. More...
const_component_col_range_iterator	col_end (const std::size_t component, const size_type slice, const size_type col, const slip::Range< int > &range) const
	Returns a read-only iterator that points to the past the end element of the Range range of the col col in the GenericMultiComponent3d. Iteration is done in ordinary element order according to the Range. More...
reverse_component_col_range_iterator	col_rbegin (const std::size_t component, const size_type slice, const size_type col, const slip::Range< int > &range)
	Returns a read-write iterator that points to the last element of the Range range of the col of a slice col in the GenericMultiComponent3d. Iteration is done in the reverse element order according to the Range. More...
const_reverse_component_col_range_iterator	col_rbegin (const std::size_t component, const size_type slice, const size_type col, const slip::Range< int > &range) const
	Returns a read_only iterator that points to the last element of the Range & range of the col of a slice col in the GenericMultiComponent3d. Iteration is done in the reverse element order according to the Range. More...
reverse_component_col_range_iterator	col_rend (const std::size_t component, const size_type slice, const size_type col, const slip::Range< int > &range)
	Returns a read-write iterator that points to one before the first element of the Range range of the col of a slice col in the GenericMultiComponent3d. Iteration is done in the reverse element order according to the Range. More...
const_reverse_component_col_range_iterator	col_rend (const std::size_t component, const size_type slice, const size_type col, const slip::Range< int > &range) const
	Returns a read-only iterator that points to the first element of the Range range of the col of a slice col in the GenericMultiComponent3d. Iteration is done in the reverse element order according to the Range. More...
One dimensional global plane iterators
iterator	plane_begin (const size_type slice)
	Returns a read/write iterator that points to the first element in the in the slice plane of the GenericMultiComponent3d. Iteration is done in ordinary element order. More...
const_iterator	plane_begin (const size_type slice) const
	Returns a read-only (constant) iterator that points to the first element in the slice plane of the GenericMultiComponent3d. Iteration is done in ordinary element order. More...
iterator	plane_end (const size_type slice)
	Returns a read/write iterator that points one past the last element in the slice plane of the GenericMultiComponent3d. Iteration is done in ordinary element order. More...
const_iterator	plane_end (const size_type slice) const
	Returns a read-only (constant) iterator that points one past the last element in the slice plane of the GenericMultiComponent3d. Iteration is done in ordinary element order. More...
reverse_iterator	plane_rbegin (const size_type slice)
	Returns a read/write reverse iterator that points to the last element in the slice plane of the GenericMultiComponent3d. Iteration is done in reverse element order. More...
const_reverse_iterator	plane_rbegin (const size_type slice) const
	Returns a read-only (constant) reverse iterator that points to the last element in the slice plane k of the GenericMultiComponent3d. Iteration is done in reverse element order. More...
reverse_iterator	plane_rend (const size_type slice)
	Returns a read/write reverse iterator that points to one before the first element in the slice plane of the GenericMultiComponent3d. Iteration is done in reverse element order. More...
const_reverse_iterator	plane_rend (const size_type slice) const
	Returns a read-only (constant) reverse iterator that points to one before the first element in the slice plane of the GenericMultiComponent3d. Iteration is done in reverse element order. More...
One dimensional component global plane iterators
component_iterator	plane_begin (const std::size_t component, const size_type slice)
	Returns a read/write iterator that points to the first element in the in the slice plane of the GenericMultiComponent3d. Iteration is done in ordinary element order. More...
const_component_iterator	plane_begin (const std::size_t component, const size_type slice) const
	Returns a read-only (constant) iterator that points to the first element in the slice plane of the GenericMultiComponent3d. Iteration is done in ordinary element order. More...
component_iterator	plane_end (const std::size_t component, const size_type slice)
	Returns a read/write iterator that points one past the last element in the slice plane of the GenericMultiComponent3d. Iteration is done in ordinary element order. More...
const_component_iterator	plane_end (const std::size_t component, const size_type slice) const
	Returns a read-only (constant) iterator that points one past the last element in the slice plane of the GenericMultiComponent3d. Iteration is done in ordinary element order. More...
reverse_component_iterator	plane_rbegin (const std::size_t component, const size_type slice)
	Returns a read/write reverse iterator that points to the last element in the slice plane of the GenericMultiComponent3d. Iteration is done in reverse element order. More...
const_reverse_component_iterator	plane_rbegin (const std::size_t component, const size_type slice) const
	Returns a read-only (constant) reverse iterator that points to the last element in the slice plane k of the GenericMultiComponent3d. Iteration is done in reverse element order. More...
reverse_component_iterator	plane_rend (const std::size_t component, const size_type slice)
	Returns a read/write reverse iterator that points to one before the first element in the slice plane of the GenericMultiComponent3d. Iteration is done in reverse element order. More...
const_reverse_component_iterator	plane_rend (const std::size_t component, const size_type slice) const
	Returns a read-only (constant) reverse iterator that points to one before the first element in the slice plane of the GenericMultiComponent3d. Iteration is done in reverse element order. More...
two dimensionnal plane iterators : Global iterators
iterator2d	plane_upper_left (PLANE_ORIENTATION P, const size_type plane_coordinate)
	Returns a read/write iterator that points to the first element of the plane in the GenericMultiComponent3d. It points to the upper left element of the plane Iteration is done in ordinary element order. More...
const_iterator2d	plane_upper_left (PLANE_ORIENTATION P, const size_type plane_coordinate) const
	Returns a read/write const iterator that points to the first element of the plane in the GenericMultiComponent3d. It points to the upper left element of the plane Iteration is done in ordinary element order. More...
iterator2d	plane_bottom_right (PLANE_ORIENTATION P, const size_type plane_coordinate)
	Returns a read/write iterator that points to the last element of the plane in the GenericMultiComponent3d. It points to past the end element of the bottom right element of the plane Iteration is done in ordinary element order. More...
const_iterator2d	plane_bottom_right (PLANE_ORIENTATION P, const size_type plane_coordinate) const
	Returns a read/write const iterator that points to the last element of the plane in the GenericMultiComponent3d. It points to past the end element of the bottom right element of the plane Iteration is done in ordinary element order. More...
reverse_iterator2d	plane_rupper_left (PLANE_ORIENTATION P, const size_type plane_coordinate)
	Returns a read/write reverse_iterator that points to the bottom right element of the plane in the GenericMultiComponent3d. Iteration is done in backward element order. More...
const_reverse_iterator2d	plane_rupper_left (PLANE_ORIENTATION P, const size_type plane_coordinate) const
	Returns a read/write const reverse iterator that points to the bottom right element of the plane in the GenericMultiComponent3d. Iteration is done in backward element order. More...
reverse_iterator2d	plane_rbottom_right (PLANE_ORIENTATION P, const size_type plane_coordinate)
	Returns a read/write reverse_iterator that points to the upper left element of the plane in the GenericMultiComponent3d. Iteration is done in backward element order. More...
const_reverse_iterator2d	plane_rbottom_right (PLANE_ORIENTATION P, const size_type plane_coordinate) const
	Returns a read/write const reverse iterator that points to the upper left element of the plane in the GenericMultiComponent3d. Iteration is done in backward element order. More...
two dimensionnal plane iterators : box iterators
iterator2d	plane_upper_left (PLANE_ORIENTATION P, const size_type plane_coordinate, const Box2d< int > &b)
	Returns a read/write iterator that points to the first element of a box within a plane in the GenericMultiComponent3d. It points to the upper left element of the box Iteration is done in ordinary element order. More...
const_iterator2d	plane_upper_left (PLANE_ORIENTATION P, const size_type plane_coordinate, const Box2d< int > &b) const
	Returns a read/write const iterator that points to the first element of a box within a plane in the GenericMultiComponent3d. It points to the upper left element of the plane Iteration is done in ordinary element order. More...
iterator2d	plane_bottom_right (PLANE_ORIENTATION P, const size_type plane_coordinate, const Box2d< int > &b)
	Returns a read/write iterator that points to the last element of a box within a plane in the GenericMultiComponent3d. It points to past the end element of the bottom right element of the plane Iteration is done in ordinary element order. More...
const_iterator2d	plane_bottom_right (PLANE_ORIENTATION P, const size_type plane_coordinate, const Box2d< int > &b) const
	Returns a read/write const iterator that points to the last element of a box within a plane in the GenericMultiComponent3d. It points to past the end element of the bottom right element of the plane Iteration is done in ordinary element order. More...
reverse_iterator2d	plane_rupper_left (PLANE_ORIENTATION P, const size_type plane_coordinate, const Box2d< int > &b)
	Returns a read/write reverse iterator that points to the last element of a box within a plane in the GenericMultiComponent3d. It points to the bottom right element of the box Iteration is done in backward element order. More...
const_reverse_iterator2d	plane_rupper_left (PLANE_ORIENTATION P, const size_type plane_coordinate, const Box2d< int > &b) const
	Returns a read/write const reverse iterator that points to the last element of a box within a plane in the GenericMultiComponent3d. It points to the bottom right element of the plane Iteration is done in backward element order. More...
reverse_iterator2d	plane_rbottom_right (PLANE_ORIENTATION P, const size_type plane_coordinate, const Box2d< int > &b)
	Returns a read/write reverse iterator that points to the first element of a box within a plane in the GenericMultiComponent3d. It points to the upper left element of the plane Iteration is done in backward element order. More...
const_reverse_iterator2d	plane_rbottom_right (PLANE_ORIENTATION P, const size_type plane_coordinate, const Box2d< int > &b) const
	Returns a read/write const reverse iterator that points to the first element of a box within a plane in the GenericMultiComponent3d. It points to the bottom right element of the plane Iteration is done in backward element order. More...
three dimensionnal iterators : Global iterators
iterator3d	front_upper_left ()
	Returns a read/write iterator3d that points to the first element of the GenericMultiComponent3d. It points to the front upper left element of the GenericMultiComponent3d. More...
const_iterator3d	front_upper_left () const
	Returns a read-only iterator3d that points to the first element of the GenericMultiComponent3d. It points to the front upper left element of the GenericMultiComponent3d. More...
iterator3d	back_bottom_right ()
	Returns a read/write iterator3d that points to the past the end element of the GenericMultiComponent3d. It points to past the end element of the back bottom right element of the GenericMultiComponent3d. More...
const_iterator3d	back_bottom_right () const
	Returns a read-only iterator3d that points to the past the end element of the GenericMultiComponent3d. It points to past the end element of the back bottom right element of the GenericMultiComponent3d. More...
reverse_iterator3d	rfront_upper_left ()
	Returns a read/write reverse iterator3d. It points to the back bottom right element of the GenericMultiComponent3d. Iteration is done within the GenericMultiComponent3d in the reverse order. More...
const_reverse_iterator3d	rfront_upper_left () const
	Returns a read only reverse iterator3d that points. It points to the back bottom right element of the GenericMultiComponent3d. Iteration is done within the GenericMultiComponent3d in the reverse order. More...
reverse_iterator3d	rback_bottom_right ()
	Returns a read/write reverse iterator3d. It points to past the front upper left element of the GenericMultiComponent3d. Iteration is done in the reverse order. More...
const_reverse_iterator3d	rback_bottom_right () const
	Returns a read only reverse iterator3d. It points to past the front upper left element of the GenericMultiComponent3d. Iteration is done in the reverse order. More...
three dimensionnal iterators : Box iterators
iterator3d	front_upper_left (const Box3d< int > &box)
	Returns a read/write iterator3d that points to the first element of the GenericMultiComponent3d. It points to the front upper left element of the Box3d associated to the GenericMultiComponent3d. More...
const_iterator3d	front_upper_left (const Box3d< int > &box) const
	Returns a read only iterator3d that points to the first element of the GenericMultiComponent3d. It points to the front upper left element of the Box3d associated to the GenericMultiComponent3d. More...
iterator3d	back_bottom_right (const Box3d< int > &box)
	Returns a read/write iterator3d that points to the past the end element of the GenericMultiComponent3d. It points to past the end element of the back bottom right element of the Box3d associated to the GenericMultiComponent3d. More...
const_iterator3d	back_bottom_right (const Box3d< int > &box) const
	Returns a read only iterator3d that points to the past the end element of the GenericMultiComponent3d. It points to past the end element of the back bottom right element of the Box3d associated to the GenericMultiComponent3d. More...
reverse_iterator3d	rfront_upper_left (const Box3d< int > &box)
	Returns a read/write reverse iterator3d. It points to the back bottom right element of the Box3d associated to the GenericMultiComponent3d. Iteration is done in the reverse order. More...
const_reverse_iterator3d	rfront_upper_left (const Box3d< int > &box) const
	Returns a read only reverse iterator3d. It points to the back bottom right element of the Box3d box associated to the GenericMultiComponent3d. Iteration is done in the reverse order. More...
reverse_iterator3d	rback_bottom_right (const Box3d< int > &box)
	Returns a read/write reverse iterator3d. It points to one before the front upper left element of the Box3d box associated to the GenericMultiComponent3d. More...
const_reverse_iterator3d	rback_bottom_right (const Box3d< int > &box) const
	Returns a read-only reverse iterator3d. It points to one before the front upper left element of the Box3d box associated to the GenericMultiComponent3d. More...
three dimensionnal iterators : Range iterators
iterator3d_range	front_upper_left (const Range< int > &slice_range, const Range< int > &row_range, const Range< int > &col_range)
	Returns a read/write iterator3d_range that points to the front upper left element of the ranges slice_range, row_range and col_range associated to the GenericMultiComponent3d. More...
const_iterator3d_range	front_upper_left (const Range< int > &slice_range, const Range< int > &row_range, const Range< int > &col_range) const
	Returns a read-only iterator3d_range that points to the to the front upper left element of the ranges slice_range, row_range and col_range associated to the GenericMultiComponent3d. More...
iterator3d_range	back_bottom_right (const Range< int > &slice_range, const Range< int > &row_range, const Range< int > &col_range)
	Returns a read/write iterator3d_range that points to the past the end back bottom right element of the ranges slice_range, row_range and col_range associated to the GenericMultiComponent3d. More...
const_iterator3d_range	back_bottom_right (const Range< int > &slice_range, const Range< int > &row_range, const Range< int > &col_range) const
	Returns a read-only iterator3d_range that points to the past the end back bottom right element of the ranges slice_range, row_range and col_range associated to the GenericMultiComponent3d. More...
reverse_iterator3d_range	rfront_upper_left (const Range< int > &slice_range, const Range< int > &row_range, const Range< int > &col_range)
	Returns a read/write reverse_iterator3d_range that points to the past the back bottom right element of the ranges row_range and col_range associated to the GenericMultiComponent3d. Iteration is done in the reverse order. More...
const_reverse_iterator3d_range	rfront_upper_left (const Range< int > &slice_range, const Range< int > &row_range, const Range< int > &col_range) const
	Returns a read-only reverse_iterator3d_range that points to the past the back bottom right element of the ranges row_range and col_range associated to the GenericMultiComponent3d. Iteration is done in the reverse order. More...
reverse_iterator3d_range	rback_bottom_right (const Range< int > &slice_range, const Range< int > &row_range, const Range< int > &col_range)
	Returns a read/write reverse_iterator3d_range that points to one before the front upper left element of the ranges row_range and col_range associated to the GenericMultiComponent3d. Iteration is done in the reverse order. More...
const_reverse_iterator3d_range	rback_bottom_right (const Range< int > &slice_range, const Range< int > &row_range, const Range< int > &col_range) const
	Returns a read-only reverse_iterator3d_range that points to one before the front upper left element of the ranges row_range and col_range associated to the GenericMultiComponent3d.Iteration is done in the reverse order. More...
Three dimensionnal component iterators : Global component iterators
component_iterator3d	front_upper_left (const std::size_t component)
	Returns a read/write component_iterator3d that points to the first element of the GenericMultiComponent3d. It points to the front upper left element of the GenericMultiComponent3d. More...
const_component_iterator3d	front_upper_left (const std::size_t component) const
	Returns a read only const_component_iterator3d that points to the first element of the GenericMultiComponent3d. It points to the front upper left element of the GenericMultiComponent3d. More...
component_iterator3d	front_upper_left (const std::size_t component, const Box3d< int > &box)
	Returns a read/write component iterator3d that points to the first element of the GenericMultiComponent3d. It points to the front upper left element of the Box3d associated to the GenericMultiComponent3d. More...
const_component_iterator3d	front_upper_left (const std::size_t component, const Box3d< int > &box) const
	Returns a read only component iterator3d that points to the first element of the GenericMultiComponent3d. It points to the front upper left element of the Box3d associated to the GenericMultiComponent3d. More...
component_iterator3d_range	front_upper_left (const std::size_t component, const Range< int > &slice_range, const Range< int > &row_range, const Range< int > &col_range)
	Returns a read/write component_iterator3d_range that points to the front upper left element of the ranges slice_range, row_range and col_range associated to the GenericMultiComponent3d. More...
const_component_iterator3d_range	front_upper_left (const std::size_t component, const Range< int > &slice_range, const Range< int > &row_range, const Range< int > &col_range) const
	Returns a read/write component_const_iterator3d_range that points to the front upper left element of the ranges slice_range, row_range and col_range associated to the GenericMultiComponent3d. More...
component_iterator3d	back_bottom_right (const std::size_t component)
	Returns a read/write component_iterator3d that points to the past the end element of the GenericMultiComponent3d. It points to past the end element of the back bottom right element of the GenericMultiComponent3d. More...
const_component_iterator3d	back_bottom_right (const std::size_t component) const
	Returns a read only const_component_iterator3d that points to the past the end element of the GenericMultiComponent3d. It points to past the end element of the back bottom right element of the GenericMultiComponent3d. More...
component_iterator3d	back_bottom_right (const std::size_t component, const Box3d< int > &box)
	Returns a read/write component iterator3d that points to the past the end element of the GenericMultiComponent3d. It points to past the end element of the back bottom right element of the Box3d associated to the GenericMultiComponent3d. More...
const_component_iterator3d	back_bottom_right (const std::size_t component, const Box3d< int > &box) const
	Returns a read only component iterator3d that points to the past the end element of the GenericMultiComponent3d. It points to past the end element of the back bottom right element of the Box3d associated to the GenericMultiComponent3d. More...
component_iterator3d_range	back_bottom_right (const std::size_t component, const Range< int > &slice_range, const Range< int > &row_range, const Range< int > &col_range)
	Returns a read/write component_iterator3d_range that points to the past the end back bottom right element of the ranges slice_range, row_range and col_range associated to the GenericMultiComponent3d. More...
const_component_iterator3d_range	back_bottom_right (const std::size_t component, const Range< int > &slice_range, const Range< int > &row_range, const Range< int > &col_range) const
	Returns a read/write const_component iterator3d_range that points to the past the end back bottom right element of the ranges slice_range, row_range and col_range associated to the GenericMultiComponent3d. More...
reverse_component_iterator3d	rfront_upper_left (const std::size_t component)
	Returns a read/write reverse component iterator3d. It points to the back bottom right element of the GenericMultiComponent3d. Iteration is done within the GenericMultiComponent3d in the reverse order. More...
const_reverse_component_iterator3d	rfront_upper_left (const std::size_t component) const
	Returns a read only reverse component iterator3d that points. It points to the back bottom right element of the GenericMultiComponent3d. Iteration is done within the GenericMultiComponent3d in the reverse order. More...
reverse_component_iterator3d	rfront_upper_left (const std::size_t component, const Box3d< int > &box)
	Returns a read/write reverse component iterator3d. It points to the back bottom right element of the Box3d associated to the GenericMultiComponent3d. Iteration is done in the reverse order. More...
const_reverse_component_iterator3d	rfront_upper_left (const std::size_t component, const Box3d< int > &box) const
	Returns a read only reverse component iterator3d. It points to the back bottom right element of the Box3d box associated to the GenericMultiComponent3d. Iteration is done in the reverse order. More...
reverse_component_iterator3d_range	rfront_upper_left (const std::size_t component, const Range< int > &slice_range, const Range< int > &row_range, const Range< int > &col_range)
	Returns a read/write reverse_component_iterator3d_range. It points to the back bottom right element of the ranges slice_range, row_range and col_range associated to the GenericMultiComponent3d. More...
const_reverse_component_iterator3d_range	rfront_upper_left (const std::size_t component, const Range< int > &slice_range, const Range< int > &row_range, const Range< int > &col_range) const
	Returns a read/write reverse_const_component_iterator3d_range. It points to the back bottom right element of the ranges slice_range, row_range and col_range associated to the GenericMultiComponent3d. More...
reverse_component_iterator3d	rback_bottom_right (const std::size_t component)
	Returns a read/write reverse component iterator3d. It points to past the front upper left element of the GenericMultiComponent3d. Iteration is done in the reverse order. More...
const_reverse_component_iterator3d	rback_bottom_right (const std::size_t component) const
	Returns a read only reverse component iterator3d. It points to past the front upper left element of the GenericMultiComponent3d. Iteration is done in the reverse order. More...
reverse_component_iterator3d	rback_bottom_right (const std::size_t component, const Box3d< int > &box)
	Returns a read/write reverse component iterator3d. It points to one before the front upper left element of the Box3d box associated to the GenericMultiComponent3d. More...
const_reverse_component_iterator3d	rback_bottom_right (const std::size_t component, const Box3d< int > &box) const
	Returns a read-only reverse component iterator3d. It points to one before the front upper left element of the Box3d box associated to the GenericMultiComponent3d. More...
reverse_component_iterator3d_range	rback_bottom_right (const std::size_t component, const Range< int > &slice_range, const Range< int > &row_range, const Range< int > &col_range)
	Returns a read/write reverse_component_iterator3d_range. It points to one before the front upper left element of the ranges slice_range, row_range and col_range associated to the GenericMultiComponent3d. More...
const_reverse_component_iterator3d_range	rback_bottom_right (const std::size_t component, const Range< int > &slice_range, const Range< int > &row_range, const Range< int > &col_range) const
	Returns a read/write reverse_const_component_iterator3d_range. It points to one before the front upper left element of the ranges slice_range, row_range and col_range associated to the GenericMultiComponent3d. More...
Assignment operators and methods
void	fill (const slip::Vector3d< T > &value)
	Fills the container range [begin(),begin()+size()) with copies of value. More...
void	fill (const typename slip::Vector3d< T >::pointer value)
	Fills the container range [begin(),begin()+size()) with a copy of the value array. More...
void	fill (const slip::Vector3d< T > *value)
	Fills the container range [begin(),begin()+size()) with a copy of the value array. More...
void	fill (InputIterator first, InputIterator last)
	Fills the container range [begin(),begin()+size()) with a copy of the range [first,last) More...
void	fill (std::vector< InputIterator > first_iterators_list, InputIterator last)
	Fills the container range [begin(),begin()+size()) with a copy of the range [first,last) More...
void	fill (std::size_t component, InputIterator first, InputIterator last)
	Fills the container range [begin(),begin()+size()) with a copy of the range [first,last) More...
Element access operators
Less than comparison operator (GenericMultiComponent3d ordering relation) Parameters x A GenericMultiComponent3d y A GenericMultiComponent3d of the same type of x Returns true iff x is lexicographically less than y Precondition x.size() == y.size() More than comparison operator Parameters x A GenericMultiComponent3d y A GenericMultiComponent3d of the same type of x Returns true iff y > x Precondition x.size() == y.size() Less than equal comparison operator Parameters x A GenericMultiComponent3d y A GenericMultiComponent3d of the same type of x Returns true iff !(y > x) Precondition x.size() == y.size() More than equal comparison operator Parameters x A GenericMultiComponent3d y A GenericMultiComponent3d of the same type of x Returns true iff !(x < y) Precondition x.size() == y.size()
pointer *	operator[] (const size_type k)
	Subscript access to the slice datas contained in the GenericMultiComponent3d. More...
const_pointer const *	operator[] (const size_type k) const
	Subscript access to the slice datas contained in the GenericMultiComponent3d. More...
reference	operator() (const size_type k, const size_type i, const size_type j)
	Subscript access to the data contained in the GenericMultiComponent3d. More...
const_reference	operator() (const size_type k, const size_type i, const size_type j) const
	Subscript access to the data contained in the GenericMultiComponent3d. More...

Static Public Attributes
static const std::size_t	DIM = 3
static const std::size_t	COMPONENTS

Friends
class	boost::serialization::access

Detailed Description

template<typename T>
class slip::DenseVector3dField3d< T >

This is a Dense Vector3d Field. This container statisfies the BidirectionnalContainer concepts of the STL. It is also an 3d extension of the RandomAccessContainer concept. That is to say the bracket element access is replaced by the triple bracket element access. It is a specialization of GenericMultiComponent3d using Vector3d blocks. It implements arithmetic and mathematical operators and read/write methods (tecplot and gnuplot file format...). Contrary to slip::RegularVector3dField3d, this container is not associated with a grid.

Author

Benoit Tremblais <tremblais_AT_sic.univ-poitiers.fr>

Version

0.0.3

Date

2014/03/25

Parameters

T	Type of object in the DenseVector3dField3d

Axis conventions:

axis and notation conventions

Definition at line 131 of file DenseVector3dField3d.hpp.

Member Typedef Documentation

template<typename T>

typedef GenericMultiComponent3d<slip::Vector3d<T> > slip::DenseVector3dField3d< T >::base

Definition at line 161 of file DenseVector3dField3d.hpp.

typedef block_value_type* slip::GenericMultiComponent3d< slip::Vector3d< T > >::block_pointer

inherited

Definition at line 256 of file GenericMultiComponent3d.hpp.

typedef block_value_type& slip::GenericMultiComponent3d< slip::Vector3d< T > >::block_reference

inherited

Definition at line 258 of file GenericMultiComponent3d.hpp.

typedef slip::Vector3d< T > ::value_type slip::GenericMultiComponent3d< slip::Vector3d< T > >::block_value_type

inherited

Definition at line 255 of file GenericMultiComponent3d.hpp.

template<typename T>

typedef slip::stride_iterator<pointer> slip::DenseVector3dField3d< T >::col_iterator

Definition at line 181 of file DenseVector3dField3d.hpp.

typedef slip::stride_iterator<col_iterator> slip::GenericMultiComponent3d< slip::Vector3d< T > >::col_range_iterator

inherited

Definition at line 213 of file GenericMultiComponent3d.hpp.

typedef slip::stride_iterator<block_pointer> slip::GenericMultiComponent3d< slip::Vector3d< T > >::component_col_iterator

inherited

Definition at line 276 of file GenericMultiComponent3d.hpp.

typedef slip::stride_iterator<block_pointer> slip::GenericMultiComponent3d< slip::Vector3d< T > >::component_col_range_iterator

inherited

Definition at line 278 of file GenericMultiComponent3d.hpp.

typedef slip::kstride_iterator<typename slip::Vector3d< T > ::pointer,slip::Vector3d< T > ::SIZE> slip::GenericMultiComponent3d< slip::Vector3d< T > >::component_iterator

inherited

Definition at line 260 of file GenericMultiComponent3d.hpp.

typedef slip::component_iterator3d_box<self,slip::Vector3d< T > ::SIZE> slip::GenericMultiComponent3d< slip::Vector3d< T > >::component_iterator3d

inherited

Definition at line 296 of file GenericMultiComponent3d.hpp.

typedef slip::component_iterator3d_range<self,slip::Vector3d< T > ::SIZE> slip::GenericMultiComponent3d< slip::Vector3d< T > >::component_iterator3d_range

inherited

Definition at line 301 of file GenericMultiComponent3d.hpp.

typedef component_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::component_row_iterator

inherited

Definition at line 272 of file GenericMultiComponent3d.hpp.

typedef slip::stride_iterator<block_pointer> slip::GenericMultiComponent3d< slip::Vector3d< T > >::component_row_range_iterator

inherited

Definition at line 274 of file GenericMultiComponent3d.hpp.

typedef slip::stride_iterator<block_pointer> slip::GenericMultiComponent3d< slip::Vector3d< T > >::component_slice_iterator

inherited

Definition at line 268 of file GenericMultiComponent3d.hpp.

typedef slip::stride_iterator<block_pointer> slip::GenericMultiComponent3d< slip::Vector3d< T > >::component_slice_range_iterator

inherited

Definition at line 270 of file GenericMultiComponent3d.hpp.

typedef const block_value_type* slip::GenericMultiComponent3d< slip::Vector3d< T > >::const_block_pointer

inherited

Definition at line 257 of file GenericMultiComponent3d.hpp.

typedef const block_value_type slip::GenericMultiComponent3d< slip::Vector3d< T > >::const_block_reference

inherited

Definition at line 259 of file GenericMultiComponent3d.hpp.

template<typename T>

typedef slip::stride_iterator<const_pointer> slip::DenseVector3dField3d< T >::const_col_iterator

Definition at line 182 of file DenseVector3dField3d.hpp.

typedef slip::stride_iterator<const_col_iterator> slip::GenericMultiComponent3d< slip::Vector3d< T > >::const_col_range_iterator

inherited

Definition at line 214 of file GenericMultiComponent3d.hpp.

typedef slip::stride_iterator<const_block_pointer> slip::GenericMultiComponent3d< slip::Vector3d< T > >::const_component_col_iterator

inherited

Definition at line 277 of file GenericMultiComponent3d.hpp.

typedef slip::stride_iterator<const_block_pointer> slip::GenericMultiComponent3d< slip::Vector3d< T > >::const_component_col_range_iterator

inherited

Definition at line 279 of file GenericMultiComponent3d.hpp.

typedef slip::kstride_iterator<typename slip::Vector3d< T > ::const_pointer,slip::Vector3d< T > ::SIZE> slip::GenericMultiComponent3d< slip::Vector3d< T > >::const_component_iterator

inherited

Definition at line 261 of file GenericMultiComponent3d.hpp.

typedef slip::const_component_iterator3d_box<const_self,slip::Vector3d< T > ::SIZE> slip::GenericMultiComponent3d< slip::Vector3d< T > >::const_component_iterator3d

inherited

Definition at line 298 of file GenericMultiComponent3d.hpp.

typedef slip::const_component_iterator3d_range<const_self,slip::Vector3d< T > ::SIZE> slip::GenericMultiComponent3d< slip::Vector3d< T > >::const_component_iterator3d_range

inherited

Definition at line 303 of file GenericMultiComponent3d.hpp.

typedef const_component_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::const_component_row_iterator

inherited

Definition at line 273 of file GenericMultiComponent3d.hpp.

typedef slip::stride_iterator<const_block_pointer> slip::GenericMultiComponent3d< slip::Vector3d< T > >::const_component_row_range_iterator

inherited

Definition at line 275 of file GenericMultiComponent3d.hpp.

typedef slip::stride_iterator<const_block_pointer> slip::GenericMultiComponent3d< slip::Vector3d< T > >::const_component_slice_iterator

inherited

Definition at line 269 of file GenericMultiComponent3d.hpp.

typedef slip::stride_iterator<const_block_pointer> slip::GenericMultiComponent3d< slip::Vector3d< T > >::const_component_slice_range_iterator

inherited

Definition at line 271 of file GenericMultiComponent3d.hpp.

typedef const_iterator3d slip::GenericMultiComponent3d< slip::Vector3d< T > >::const_default_iterator

inherited

Definition at line 309 of file GenericMultiComponent3d.hpp.

template<typename T>

typedef const_pointer slip::DenseVector3dField3d< T >::const_iterator

Definition at line 173 of file DenseVector3dField3d.hpp.

typedef slip::Array3d<slip::Vector3d< T > >::const_iterator2d slip::GenericMultiComponent3d< slip::Vector3d< T > >::const_iterator2d

inherited

Definition at line 239 of file GenericMultiComponent3d.hpp.

template<typename T>

typedef slip::GenericMultiComponent3d<slip::Vector3d<T> >::const_iterator2d slip::DenseVector3dField3d< T >::const_iterator3d

Definition at line 190 of file DenseVector3dField3d.hpp.

typedef slip::Array3d<slip::Vector3d< T > >::const_iterator3d_range slip::GenericMultiComponent3d< slip::Vector3d< T > >::const_iterator3d_range

inherited

Definition at line 247 of file GenericMultiComponent3d.hpp.

template<typename T>

typedef const value_type* slip::DenseVector3dField3d< T >::const_pointer

Definition at line 165 of file DenseVector3dField3d.hpp.

template<typename T>

typedef const value_type& slip::DenseVector3dField3d< T >::const_reference

Definition at line 167 of file DenseVector3dField3d.hpp.

template<typename T>

typedef std::reverse_iterator<const_col_iterator> slip::DenseVector3dField3d< T >::const_reverse_col_iterator

Definition at line 187 of file DenseVector3dField3d.hpp.

typedef std::reverse_iterator<const_col_range_iterator> slip::GenericMultiComponent3d< slip::Vector3d< T > >::const_reverse_col_range_iterator

inherited

Definition at line 227 of file GenericMultiComponent3d.hpp.

typedef std::reverse_iterator<const_component_col_iterator> slip::GenericMultiComponent3d< slip::Vector3d< T > >::const_reverse_component_col_iterator

inherited

Definition at line 290 of file GenericMultiComponent3d.hpp.

typedef std::reverse_iterator<const_component_col_range_iterator> slip::GenericMultiComponent3d< slip::Vector3d< T > >::const_reverse_component_col_range_iterator

inherited

Definition at line 292 of file GenericMultiComponent3d.hpp.

typedef std::reverse_iterator<const_component_iterator> slip::GenericMultiComponent3d< slip::Vector3d< T > >::const_reverse_component_iterator

inherited

Definition at line 264 of file GenericMultiComponent3d.hpp.

typedef std::reverse_iterator<const_component_iterator3d> slip::GenericMultiComponent3d< slip::Vector3d< T > >::const_reverse_component_iterator3d

inherited

Definition at line 299 of file GenericMultiComponent3d.hpp.

typedef std::reverse_iterator<const_component_iterator3d_range> slip::GenericMultiComponent3d< slip::Vector3d< T > >::const_reverse_component_iterator3d_range

inherited

Definition at line 304 of file GenericMultiComponent3d.hpp.

typedef std::reverse_iterator<const_component_row_iterator> slip::GenericMultiComponent3d< slip::Vector3d< T > >::const_reverse_component_row_iterator

inherited

Definition at line 286 of file GenericMultiComponent3d.hpp.

typedef std::reverse_iterator<const_component_row_range_iterator> slip::GenericMultiComponent3d< slip::Vector3d< T > >::const_reverse_component_row_range_iterator

inherited

Definition at line 288 of file GenericMultiComponent3d.hpp.

typedef std::reverse_iterator<const_component_slice_iterator> slip::GenericMultiComponent3d< slip::Vector3d< T > >::const_reverse_component_slice_iterator

inherited

Definition at line 282 of file GenericMultiComponent3d.hpp.

typedef std::reverse_iterator<const_component_slice_range_iterator> slip::GenericMultiComponent3d< slip::Vector3d< T > >::const_reverse_component_slice_range_iterator

inherited

Definition at line 284 of file GenericMultiComponent3d.hpp.

template<typename T>

typedef std::reverse_iterator<const_iterator> slip::DenseVector3dField3d< T >::const_reverse_iterator

Definition at line 176 of file DenseVector3dField3d.hpp.

typedef std::reverse_iterator<const_iterator2d> slip::GenericMultiComponent3d< slip::Vector3d< T > >::const_reverse_iterator2d

inherited

Definition at line 241 of file GenericMultiComponent3d.hpp.

typedef std::reverse_iterator<const_iterator3d> slip::GenericMultiComponent3d< slip::Vector3d< T > >::const_reverse_iterator3d

inherited

Definition at line 250 of file GenericMultiComponent3d.hpp.

typedef std::reverse_iterator<const_iterator3d_range> slip::GenericMultiComponent3d< slip::Vector3d< T > >::const_reverse_iterator3d_range

inherited

Definition at line 252 of file GenericMultiComponent3d.hpp.

template<typename T>

typedef std::reverse_iterator<const_iterator> slip::DenseVector3dField3d< T >::const_reverse_row_iterator

Definition at line 185 of file DenseVector3dField3d.hpp.

typedef std::reverse_iterator<const_row_range_iterator> slip::GenericMultiComponent3d< slip::Vector3d< T > >::const_reverse_row_range_iterator

inherited

Definition at line 225 of file GenericMultiComponent3d.hpp.

typedef std::reverse_iterator<const_slice_iterator> slip::GenericMultiComponent3d< slip::Vector3d< T > >::const_reverse_slice_iterator

inherited

Definition at line 217 of file GenericMultiComponent3d.hpp.

typedef std::reverse_iterator<const_slice_range_iterator> slip::GenericMultiComponent3d< slip::Vector3d< T > >::const_reverse_slice_range_iterator

inherited

Definition at line 223 of file GenericMultiComponent3d.hpp.

template<typename T>

typedef const_pointer slip::DenseVector3dField3d< T >::const_row_iterator

Definition at line 180 of file DenseVector3dField3d.hpp.

typedef slip::stride_iterator<const_pointer> slip::GenericMultiComponent3d< slip::Vector3d< T > >::const_row_range_iterator

inherited

Definition at line 212 of file GenericMultiComponent3d.hpp.

typedef const GenericMultiComponent3d<slip::Vector3d< T > > slip::GenericMultiComponent3d< slip::Vector3d< T > >::const_self

inherited

Definition at line 186 of file GenericMultiComponent3d.hpp.

typedef slip::stride_iterator<const_pointer> slip::GenericMultiComponent3d< slip::Vector3d< T > >::const_slice_iterator

inherited

Definition at line 204 of file GenericMultiComponent3d.hpp.

typedef slip::stride_iterator<const_slice_iterator> slip::GenericMultiComponent3d< slip::Vector3d< T > >::const_slice_range_iterator

inherited

Definition at line 210 of file GenericMultiComponent3d.hpp.

template<typename T>

typedef slip::kstride_iterator<const_vector3d_pointer,3> slip::DenseVector3dField3d< T >::const_vector3d_iterator

Definition at line 198 of file DenseVector3dField3d.hpp.

template<typename T>

typedef const vector3d_value_type* slip::DenseVector3dField3d< T >::const_vector3d_pointer

Definition at line 194 of file DenseVector3dField3d.hpp.

template<typename T>

typedef const vector3d_value_type slip::DenseVector3dField3d< T >::const_vector3d_reference

Definition at line 196 of file DenseVector3dField3d.hpp.

typedef iterator3d slip::GenericMultiComponent3d< slip::Vector3d< T > >::default_iterator

inherited

Definition at line 308 of file GenericMultiComponent3d.hpp.

template<typename T>

typedef ptrdiff_t slip::DenseVector3dField3d< T >::difference_type

Definition at line 169 of file DenseVector3dField3d.hpp.

template<typename T>

typedef pointer slip::DenseVector3dField3d< T >::iterator

Definition at line 172 of file DenseVector3dField3d.hpp.

typedef slip::Array3d<slip::Vector3d< T > >::iterator2d slip::GenericMultiComponent3d< slip::Vector3d< T > >::iterator2d

inherited

Definition at line 238 of file GenericMultiComponent3d.hpp.

template<typename T>

typedef slip::GenericMultiComponent3d<slip::Vector3d<T> >::iterator3d slip::DenseVector3dField3d< T >::iterator3d

Definition at line 189 of file DenseVector3dField3d.hpp.

typedef slip::Array3d<slip::Vector3d< T > >::iterator3d_range slip::GenericMultiComponent3d< slip::Vector3d< T > >::iterator3d_range

inherited

Definition at line 246 of file GenericMultiComponent3d.hpp.

template<typename T>

typedef slip::lin_alg_traits<value_type>::value_type slip::DenseVector3dField3d< T >::norm_type

Definition at line 200 of file DenseVector3dField3d.hpp.

template<typename T>

typedef value_type* slip::DenseVector3dField3d< T >::pointer

Definition at line 164 of file DenseVector3dField3d.hpp.

template<typename T>

typedef value_type& slip::DenseVector3dField3d< T >::reference

Definition at line 166 of file DenseVector3dField3d.hpp.

template<typename T>

typedef std::reverse_iterator<col_iterator> slip::DenseVector3dField3d< T >::reverse_col_iterator

Definition at line 186 of file DenseVector3dField3d.hpp.

typedef std::reverse_iterator<col_range_iterator> slip::GenericMultiComponent3d< slip::Vector3d< T > >::reverse_col_range_iterator

inherited

Definition at line 226 of file GenericMultiComponent3d.hpp.

typedef std::reverse_iterator<component_col_iterator> slip::GenericMultiComponent3d< slip::Vector3d< T > >::reverse_component_col_iterator

inherited

Definition at line 289 of file GenericMultiComponent3d.hpp.

typedef std::reverse_iterator<component_col_range_iterator> slip::GenericMultiComponent3d< slip::Vector3d< T > >::reverse_component_col_range_iterator

inherited

Definition at line 291 of file GenericMultiComponent3d.hpp.

typedef std::reverse_iterator<component_iterator> slip::GenericMultiComponent3d< slip::Vector3d< T > >::reverse_component_iterator

inherited

Definition at line 263 of file GenericMultiComponent3d.hpp.

typedef std::reverse_iterator<component_iterator3d> slip::GenericMultiComponent3d< slip::Vector3d< T > >::reverse_component_iterator3d

inherited

Definition at line 297 of file GenericMultiComponent3d.hpp.

typedef std::reverse_iterator<component_iterator3d_range> slip::GenericMultiComponent3d< slip::Vector3d< T > >::reverse_component_iterator3d_range

inherited

Definition at line 302 of file GenericMultiComponent3d.hpp.

typedef std::reverse_iterator<component_row_iterator> slip::GenericMultiComponent3d< slip::Vector3d< T > >::reverse_component_row_iterator

inherited

Definition at line 285 of file GenericMultiComponent3d.hpp.

typedef std::reverse_iterator<component_row_range_iterator> slip::GenericMultiComponent3d< slip::Vector3d< T > >::reverse_component_row_range_iterator

inherited

Definition at line 287 of file GenericMultiComponent3d.hpp.

typedef std::reverse_iterator<component_slice_iterator> slip::GenericMultiComponent3d< slip::Vector3d< T > >::reverse_component_slice_iterator

inherited

Definition at line 281 of file GenericMultiComponent3d.hpp.

typedef std::reverse_iterator<component_slice_range_iterator> slip::GenericMultiComponent3d< slip::Vector3d< T > >::reverse_component_slice_range_iterator

inherited

Definition at line 283 of file GenericMultiComponent3d.hpp.

template<typename T>

typedef std::reverse_iterator<iterator> slip::DenseVector3dField3d< T >::reverse_iterator

Definition at line 175 of file DenseVector3dField3d.hpp.

typedef std::reverse_iterator<iterator2d> slip::GenericMultiComponent3d< slip::Vector3d< T > >::reverse_iterator2d

inherited

Definition at line 240 of file GenericMultiComponent3d.hpp.

typedef std::reverse_iterator<iterator3d> slip::GenericMultiComponent3d< slip::Vector3d< T > >::reverse_iterator3d

inherited

Definition at line 249 of file GenericMultiComponent3d.hpp.

typedef std::reverse_iterator<iterator3d_range> slip::GenericMultiComponent3d< slip::Vector3d< T > >::reverse_iterator3d_range

inherited

Definition at line 251 of file GenericMultiComponent3d.hpp.

template<typename T>

typedef std::reverse_iterator<iterator> slip::DenseVector3dField3d< T >::reverse_row_iterator

Definition at line 184 of file DenseVector3dField3d.hpp.

typedef std::reverse_iterator<row_range_iterator> slip::GenericMultiComponent3d< slip::Vector3d< T > >::reverse_row_range_iterator

inherited

Definition at line 224 of file GenericMultiComponent3d.hpp.

typedef std::reverse_iterator<slice_iterator> slip::GenericMultiComponent3d< slip::Vector3d< T > >::reverse_slice_iterator

inherited

Definition at line 216 of file GenericMultiComponent3d.hpp.

typedef std::reverse_iterator<slice_range_iterator> slip::GenericMultiComponent3d< slip::Vector3d< T > >::reverse_slice_range_iterator

inherited

Definition at line 222 of file GenericMultiComponent3d.hpp.

template<typename T>

typedef pointer slip::DenseVector3dField3d< T >::row_iterator

Definition at line 179 of file DenseVector3dField3d.hpp.

typedef slip::stride_iterator<pointer> slip::GenericMultiComponent3d< slip::Vector3d< T > >::row_range_iterator

inherited

Definition at line 211 of file GenericMultiComponent3d.hpp.

template<typename T>

typedef DenseVector3dField3d<T> slip::DenseVector3dField3d< T >::self

Definition at line 160 of file DenseVector3dField3d.hpp.

template<typename T>

typedef std::size_t slip::DenseVector3dField3d< T >::size_type

Definition at line 170 of file DenseVector3dField3d.hpp.

typedef slip::stride_iterator<pointer> slip::GenericMultiComponent3d< slip::Vector3d< T > >::slice_iterator

inherited

Definition at line 203 of file GenericMultiComponent3d.hpp.

typedef slip::stride_iterator<slice_iterator> slip::GenericMultiComponent3d< slip::Vector3d< T > >::slice_range_iterator

inherited

Definition at line 209 of file GenericMultiComponent3d.hpp.

template<typename T>

typedef slip::Vector3d<T> slip::DenseVector3dField3d< T >::value_type

Definition at line 159 of file DenseVector3dField3d.hpp.

template<typename T>

typedef slip::kstride_iterator<vector3d_pointer,3> slip::DenseVector3dField3d< T >::vector3d_iterator

Definition at line 197 of file DenseVector3dField3d.hpp.

template<typename T>

typedef vector3d_value_type* slip::DenseVector3dField3d< T >::vector3d_pointer

Definition at line 193 of file DenseVector3dField3d.hpp.

template<typename T>

typedef vector3d_value_type& slip::DenseVector3dField3d< T >::vector3d_reference

Definition at line 195 of file DenseVector3dField3d.hpp.

template<typename T>

typedef T slip::DenseVector3dField3d< T >::vector3d_value_type

Definition at line 192 of file DenseVector3dField3d.hpp.

Constructor & Destructor Documentation

template<typename T>

slip::DenseVector3dField3d< T >::DenseVector3dField3d ( )

inline

Constructs a DenseVector3dField3d.

Definition at line 211 of file DenseVector3dField3d.hpp.

template<typename T>

slip::DenseVector3dField3d< T >::DenseVector3dField3d ( const size_type  slices, const size_type  rows, const size_type  cols  )

inline

Constructs a DenseVector3dField3d.

Parameters

slices	first dimension of the GenericMultiComponent3d
rows	second dimension of the GenericMultiComponent3d
cols	third dimension of the GenericMultiComponent3d

Definition at line 221 of file DenseVector3dField3d.hpp.

template<typename T>

slip::DenseVector3dField3d< T >::DenseVector3dField3d ( const size_type  slices, const size_type  rows, const size_type  cols, const slip::Vector3d< T > &  val  )

inline

Constructs a DenseVector3dField3d initialized by the scalar value val.

Parameters

slices	first dimension of the GenericMultiComponent3d
rows	second dimension of the GenericMultiComponent3d
cols	third dimension of the GenericMultiComponent3d
val	initialization value of the elements

Definition at line 234 of file DenseVector3dField3d.hpp.

template<typename T>

slip::DenseVector3dField3d< T >::DenseVector3dField3d ( const size_type  slices, const size_type  rows, const size_type  cols, const T *  val  )

inline

Constructs a DenseVector3dField3d initialized by an array val.

Parameters

slices	first dimension of the GenericMultiComponent3d
rows	second dimension of the GenericMultiComponent3d
cols	third dimension of the GenericMultiComponent3d
val	initialization linear array value of the elements

Definition at line 248 of file DenseVector3dField3d.hpp.

template<typename T>

slip::DenseVector3dField3d< T >::DenseVector3dField3d ( const size_type  slices, const size_type  rows, const size_type  cols, const slip::Vector3d< T > *  val  )

inline

Constructs a DenseVector3dField3d initialized by an array val.

Parameters

slices	first dimension of the GenericMultiComponent3d
rows	second dimension of the GenericMultiComponent3d
cols	third dimension of the GenericMultiComponent3d
val	initialization array value of the elements

Definition at line 262 of file DenseVector3dField3d.hpp.

template<typename T>

template<typename InputIterator >

slip::DenseVector3dField3d< T >::DenseVector3dField3d ( const size_type  slices, const size_type  rows, const size_type  cols, InputIterator  first, InputIterator  last  )

inline

Contructs a DenseVector3dField3d from a range.

Parameters

slices	first dimension of the GenericMultiComponent3d
rows	second dimension of the GenericMultiComponent3d
cols	third dimension of the GenericMultiComponent3d
first	An input iterator.
last	An input iterator.

Create a DenseVector3dField3d consisting of copies of the elements from [first,last).

Definition at line 282 of file DenseVector3dField3d.hpp.

template<typename T>

template<typename InputIterator >

slip::DenseVector3dField3d< T >::DenseVector3dField3d ( const size_type  slices, const size_type  rows, const size_type  cols, InputIterator  first1, InputIterator  last1, InputIterator  first2, InputIterator  first3  )

inline

Contructs a DenseVector3dField3d from a 3 ranges.

Parameters

slices	first dimension of the GenericMultiComponent3d
rows	second dimension of the GenericMultiComponent3d
cols	third dimension of the GenericMultiComponent3d
first1	An input iterator.
last1	An input iterator.
first2	An input iterator.
first3	An input iterator.

Create a DenseVector3dField3d consisting of copies of the elements from [first1,last1), [first2,first2 + (last1 - first1)), [first3,first3 + (last1 - first1)),

Definition at line 310 of file DenseVector3dField3d.hpp.

template<typename T>

slip::DenseVector3dField3d< T >::DenseVector3dField3d ( const self &  rhs )

inline

Constructs a copy of the DenseVector3dField3d rhs.

Definition at line 332 of file DenseVector3dField3d.hpp.

template<typename T>

slip::DenseVector3dField3d< T >::~DenseVector3dField3d ( )

inline

Destructor of the DenseVector3dField3d.

Definition at line 339 of file DenseVector3dField3d.hpp.

Member Function Documentation

GenericMultiComponent3d<slip::Vector3d< T > >& slip::GenericMultiComponent3d< slip::Vector3d< T > >::apply ( slip::Vector3d< T > (*)(slip::Vector3d< T > )  fun )

inherited

Returns the sums of the elements of the GenericMultiComponent3d.

Precondition

size() != 0

Applys the one-parameter C-function fun to each element of the GenericMultiComponent3d

Parameters

fun	The one-parameter C function

Returns

the resulting GenericMultiComponent3d

GenericMultiComponent3d<slip::Vector3d< T > >& slip::GenericMultiComponent3d< slip::Vector3d< T > >::apply ( slip::Vector3d< T > (*)(const slip::Vector3d< T > &)  fun )

inherited

Applys the one-parameter C-function fun to each element of the GenericMultiComponent3d.

Parameters

fun	The one-const-parameter C function

Returns

the resulting GenericMultiComponent3d

iterator3d slip::GenericMultiComponent3d< slip::Vector3d< T > >::back_bottom_right ( )

inherited

Returns a read/write iterator3d that points to the past the end element of the GenericMultiComponent3d. It points to past the end element of the back bottom right element of the GenericMultiComponent3d.

Returns

begin iterator3d value

Remarks

This iterator is compatible with BidirectionalIterator algorithms.

Example

slip::GenericMultiComponent3d<slip::color<double> > M(3,4,5);
//Print M
std::copy(M.front_upper_left(),M.back_bottom_right(),
          std::ostream_iterator<slip::color<double> >(std::cout," "));

const_iterator3d slip::GenericMultiComponent3d< slip::Vector3d< T > >::back_bottom_right ( ) const

inherited

Returns a read-only iterator3d that points to the past the end element of the GenericMultiComponent3d. It points to past the end element of the back bottom right element of the GenericMultiComponent3d.

Returns

begin const iterator3d value

Remarks

This iterator is compatible with BidirectionalIterator algorithms.

Example

slip::GenericMultiComponent3d<slip::color<double> > const M(3,4,5);
//Print M
std::copy(M.front_upper_left(),M.back_bottom_right(),
          std::ostream_iterator<slip::color<double> >(std::cout," "));

iterator3d slip::GenericMultiComponent3d< slip::Vector3d< T > >::back_bottom_right ( const Box3d< int > &  box )

inherited

Returns a read/write iterator3d that points to the past the end element of the GenericMultiComponent3d. It points to past the end element of the back bottom right element of the Box3d associated to the GenericMultiComponent3d.

Parameters

box	a Box3d defining the range of indices to iterate within the GenericMultiComponent3d.

Returns

end iterator3d value

Remarks

This iterator is compatible with BidirectionalIterator algorithms.

Precondition

The box indices must be inside the range of the GenericMultiComponent3d ones.

Example

slip::GenericMultiComponent3d<slip::color<double> > M(3,4,5);
slip::Box3d<int> b(1,1,1,2,2,3);
//Print M within a box
std::copy(M.front_upper_left(b),M.back_bottom_right(b),
          std::ostream_iterator<slip::color<double> >(std::cout," "));

const_iterator3d slip::GenericMultiComponent3d< slip::Vector3d< T > >::back_bottom_right ( const Box3d< int > &  box ) const

inherited

Returns a read only iterator3d that points to the past the end element of the GenericMultiComponent3d. It points to past the end element of the back bottom right element of the Box3d associated to the GenericMultiComponent3d.

Parameters

box	a Box3d defining the range of indices to iterate within the GenericMultiComponent3d.

Returns

end const iterator3d value

Remarks

This iterator is compatible with BidirectionalIterator algorithms.

Precondition

The box indices must be inside the range of the GenericMultiComponent3d ones.

Example

slip::GenericMultiComponent3d<slip::color<double> > const M(3,4,5);
slip::Box3d<int> b(1,1,1,2,2,3);
//Print M within a box
std::copy(M.front_upper_left(b),M.back_bottom_right(b),
          std::ostream_iterator<slip::color<double> >(std::cout," "));

iterator3d_range slip::GenericMultiComponent3d< slip::Vector3d< T > >::back_bottom_right ( const Range< int > &  slice_range, const Range< int > &  row_range, const Range< int > &  col_range  )

inherited

Returns a read/write iterator3d_range that points to the past the end back bottom right element of the ranges slice_range, row_range and col_range associated to the GenericMultiComponent3d.

Parameters

slice_range	The range of the slices.
row_range	The range of the rows.
col_range	The range of the columns.

Precondition

slice_range, row_range and col_range must be valid.

The ranges indices must be inside the ranges of the GenericMultiComponent3d ones.

Returns

iterator3d_range value

Remarks

This iterator is compatible with BidirectionalIterator algorithms.

Example

slip::GenericMultiComponent3d<slip::color<double> > M(3,4,5);
slip::Range<int> sr(0,2,2);
slip::Range<int> rr(0,3,2);
slip::Range<int> cr(0,4,2);
//Print M within a range
std::copy(M.front_upper_left(sr,rr,cr),M.back_bottom_right(sr,rr,cr),
          std::ostream_iterator<slip::color<double> >(std::cout," "));

const_iterator3d_range slip::GenericMultiComponent3d< slip::Vector3d< T > >::back_bottom_right ( const Range< int > &  slice_range, const Range< int > &  row_range, const Range< int > &  col_range  ) const

inherited

Returns a read-only iterator3d_range that points to the past the end back bottom right element of the ranges slice_range, row_range and col_range associated to the GenericMultiComponent3d.

Parameters

slice_range	The range of the slices.
row_range	The range of the rows.
col_range	The range of the columns.

Precondition

slice_range, row_range and col_range must be valid.

The ranges indices must be inside the ranges of the GenericMultiComponent3d ones.

Returns

const_iterator3d_range value

Remarks

This iterator is compatible with BidirectionalIterator algorithms.

Example

slip::GenericMultiComponent3d<slip::color<double> > const M(3,4,5);
slip::Range<int> sr(0,2,2);
slip::Range<int> rr(0,3,2);
slip::Range<int> cr(0,4,2);
//Print M within a range
std::copy(M.front_upper_left(sr,rr,cr),M.back_bottom_right(sr,rr,cr),
          std::ostream_iterator<slip::color<double> >(std::cout," "));

component_iterator3d slip::GenericMultiComponent3d< slip::Vector3d< T > >::back_bottom_right ( const std::size_t  component )

inherited

Returns a read/write component_iterator3d that points to the past the end element of the GenericMultiComponent3d. It points to past the end element of the back bottom right element of the GenericMultiComponent3d.

Parameters

component

The component number.

Returns

begin iterator3d value

Remarks

This iterator is compatible with BidirectionalIterator algorithms.

Example:

 slip::GenericMultiComponent3d<slip::Vector3d<double> > A1(8,8,4);
 slip::GenericMultiComponent3d<slip::Vector3d<double> > A2(8,8,4);
//copy the first component of the elements of A1 in A2
std::copy(A1.front_upper_left(0),A1.back_bottom_right(0),A2.front_upper_left(0));

const_component_iterator3d slip::GenericMultiComponent3d< slip::Vector3d< T > >::back_bottom_right ( const std::size_t  component ) const

inherited

Returns a read only const_component_iterator3d that points to the past the end element of the GenericMultiComponent3d. It points to past the end element of the back bottom right element of the GenericMultiComponent3d.

Parameters

component

The component number.

Returns

begin iterator3d value

Remarks

This iterator is compatible with BidirectionalIterator algorithms.

component_iterator3d slip::GenericMultiComponent3d< slip::Vector3d< T > >::back_bottom_right ( const std::size_t  component, const Box3d< int > &  box  )

inherited

Returns a read/write component iterator3d that points to the past the end element of the GenericMultiComponent3d. It points to past the end element of the back bottom right element of the Box3d associated to the GenericMultiComponent3d.

Parameters

component	The component number.
box	a Box3d defining the range of indices to iterate within the GenericMultiComponent3d.

Returns

end iterator3d value

Remarks

This iterator is compatible with BidirectionalIterator algorithms.

Precondition

The box indices must be inside the range of the GenericMultiComponent3d ones.

const_component_iterator3d slip::GenericMultiComponent3d< slip::Vector3d< T > >::back_bottom_right ( const std::size_t  component, const Box3d< int > &  box  ) const

inherited

Returns a read only component iterator3d that points to the past the end element of the GenericMultiComponent3d. It points to past the end element of the back bottom right element of the Box3d associated to the GenericMultiComponent3d.

Parameters

component	The component number.
box	a Box3d defining the range of indices to iterate within the GenericMultiComponent3d.

Returns

end const iterator3d value

Remarks

This iterator is compatible with BidirectionalIterator algorithms.

Precondition

The box indices must be inside the range of the GenericMultiComponent3d ones.

component_iterator3d_range slip::GenericMultiComponent3d< slip::Vector3d< T > >::back_bottom_right ( const std::size_t  component, const Range< int > &  slice_range, const Range< int > &  row_range, const Range< int > &  col_range  )

inherited

Returns a read/write component_iterator3d_range that points to the past the end back bottom right element of the ranges slice_range, row_range and col_range associated to the GenericMultiComponent3d.

Parameters

component	The component number.
slice_range	The range of the slices.
row_range	The range of the rows.
col_range	The range of the columns.

Precondition

slice_range, row_range and col_range must be valid.

The ranges indices must be inside the ranges of the GenericMultiComponent3d ones.

Returns

iterator3d_range value

Remarks

This iterator is compatible with BidirectionalIterator algorithms.

const_component_iterator3d_range slip::GenericMultiComponent3d< slip::Vector3d< T > >::back_bottom_right ( const std::size_t  component, const Range< int > &  slice_range, const Range< int > &  row_range, const Range< int > &  col_range  ) const

inherited

Returns a read/write const_component iterator3d_range that points to the past the end back bottom right element of the ranges slice_range, row_range and col_range associated to the GenericMultiComponent3d.

Parameters

component	The component number.
slice_range	The range of the slices.
row_range	The range of the rows.
col_range	The range of the columns.

Precondition

slice_range, row_range and col_range must be valid.

The ranges indices must be inside the ranges of the GenericMultiComponent3d ones.

Returns

iterator3d_range value

Remarks

This iterator is compatible with BidirectionalIterator algorithms.

iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::begin ( )

inherited

Returns a read/write iterator that points to the first element in the GenericMultiComponent3d. Iteration is done in ordinary element order.

Returns

begin iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Example:

 slip::GenericMultiComponent3d<slip::color<double> > A1(10,9,5);
 slip::GenericMultiComponent3d<slip::color<double> > A2(10,9,5);
 slip::GenericMultiComponent3d<slip::color<double> > S(10,9,5);
//copy A1 in S
std::copy(A1.begin(),A1.end(),S.begin());

const_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::begin ( ) const

inherited

Returns a read-only (constant) iterator that points to the first element in the GenericMultiComponent3d. Iteration is done in ordinary element order.

Returns

const begin iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Example:

 slip::GenericMultiComponent3d<slip::color<double> > const A1(10,9,5);
 slip::GenericMultiComponent3d<slip::color<double> > const A2(10,9,5);
 slip::GenericMultiComponent3d<slip::color<double> > S(10,9,5);
//copy A1 in S
std::copy(A1.begin(),A1.end(),S.begin());
//copy A1 in S
std::copy(A1.begin(),A1.end(),S.begin());

component_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::begin ( const std::size_t  component )

inherited

Returns a read/write iterator that points to the first element in the GenericMultiComponent3d. Iteration is done in ordinary element order.

Parameters

component

The component number.

Returns

begin component_iterator value

const_component_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::begin ( const std::size_t  component ) const

inherited

Returns a read-only (constant) iterator that points to the first element in the GenericMultiComponent3d. Iteration is done in ordinary element order.

Parameters

component

The component number.

Returns

const begin component_iterator value

col_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::col_begin ( const size_type  slice, const size_type  col  )

inherited

Returns a read/write iterator that points to the first element of the column column of the slice slice in the GenericMultiComponent3d. Iteration is done modulo the number of columns.

Parameters

slice	The index of the slice.
col	The index of the column

Returns

begin col_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

const_col_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::col_begin ( const size_type  slice, const size_type  col  ) const

inherited

Returns a read_only iterator that points to the first element of the column column of the slice slice in the GenericMultiComponent3d. Iteration is done modulo the number of columns.

Parameters

slice	The index of the slice.
col	The index of the column

Returns

begin const_col_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

col_range_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::col_begin ( const size_type  slice, const size_type  col, const slip::Range< int > &  range  )

inherited

Returns a read-write iterator that points to the first element of the Range range of the col col in the GenericMultiComponent3d. Iteration is done in ordinary element order according to the Range.

Parameters

slice	The index of the slice.
col	The index of the column to iterate.
range	Range of the column to iterate

Returns

begin col_range_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Precondition

col must be compatible with the range of the GenericMultiComponent3d.

The range must be inside the whole range of the GenericMultiComponent3d.

Example:

 slip::GenericMultiComponent3d<slip::color<double> > A1(8,8,8);
 slip::GenericMultiComponent3d<slip::color<double> > A2(4,8,5);
 slip::Range<int> range(0,A1.dim2()-1,2);
//copy the the elements of the column 0 of the slice 0 of A1 iterated according to the
//range in the column 1 of the slice 1 of A2
std::copy(A1.col_begin(0,0,range),A1.col_end(0,0,range),A2.col_begin(1,1));

const_col_range_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::col_begin ( const size_type  slice, const size_type  col, const slip::Range< int > &  range  ) const

inherited

Returns a read-only iterator that points to the first element of the Range range of the col col in the GenericMultiComponent3d. Iteration is done in ordinary element order according to the Range.

Parameters

slice	The index of the slice.
col	The index of the column to iterate.
range	Range of the column to iterate.

Returns

begin const_col_range_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Precondition

col must be compatible with the range of the GenericMultiComponent3d.

The range must be inside the whole range of the GenericMultiComponent3d.

Example:

 slip::GenericMultiComponent3d<slip::color<double> > const A1(8,8,8);
 slip::GenericMultiComponent3d<slip::color<double> > A2(4,8,5);
 slip::Range<int> range(0,A1.dim2()-1,2);
//copy the the elements of the column 0 of the slice 0 of A1 iterated according to the
//range in the column 1 of the slice 1 of A2
std::copy(A1.col_begin(0,0,range),A1.col_end(0,0,range),A2.col_begin(1,1));

component_col_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::col_begin ( const std::size_t  component, const size_type  slice, const size_type  col  )

inherited

Returns a read/write iterator that points to the first element of the column column of the slice slice in the GenericMultiComponent3d. Iteration is done modulo the number of columns.

Parameters

component	The component number.
slice	The index of the slice.
col	The index of the column

Returns

begin col_iterator value

const_component_col_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::col_begin ( const std::size_t  component, const size_type  slice, const size_type  col  ) const

inherited

Returns a read_only iterator that points to the first element of the column column of the slice slice in the GenericMultiComponent3d. Iteration is done modulo the number of columns.

Parameters

component	The component number.
slice	The index of the slice.
col	The index of the column

Returns

begin const_col_iterator value

component_col_range_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::col_begin ( const std::size_t  component, const size_type  slice, const size_type  col, const slip::Range< int > &  range  )

inherited

Returns a read-write iterator that points to the first element of the Range range of the col col in the GenericMultiComponent3d. Iteration is done in ordinary element order according to the Range.

Parameters

component	The component number.
slice	The index of the slice.
col	The index of the column to iterate.
range	Range of the column to iterate

Returns

begin col_range_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Precondition

col must be compatible with the range of the GenericMultiComponent3d.

The range must be inside the whole range of the GenericMultiComponent3d.

 slip::Array3d<double> A1(8,8,8);
 slip::Array3d<double> A2(4,8,5);
 slip::Range<int> range(0,A1.dim1()-1,2);
//copy the the elements of the column 0 of A1 iterated according to the
//range in the column 1 of A2
std::copy(A1.col_begin(0,range),A1.col_end(0,range),A2.col_begin(1));

const_component_col_range_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::col_begin ( const std::size_t  component, const size_type  slice, const size_type  col, const slip::Range< int > &  range  ) const

inherited

Returns a read-only iterator that points to the first element of the Range range of the col col in the GenericMultiComponent3d. Iteration is done in ordinary element order according to the Range.

Parameters

component	The component number.
slice	The index of the slice.
col	The index of the column to iterate.
range	Range of the column to iterate.

Returns

begin const_col_range_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Precondition

col must be compatible with the range of the GenericMultiComponent3d.

The range must be inside the whole range of the GenericMultiComponent3d.

 slip::Array3d<double> A1(8,8,8);
 slip::Array3d<double> A2(4,8,5);
 slip::Range<int> range(0,A1.dim1()-1,2);
//copy the the elements of the column 0 of A1 iterated according to the
//range in the column 1 of A2
std::copy(A1.col_begin(0,range),A1.col_end(0,range),A2.col_begin(1));

col_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::col_end ( const size_type  slice, const size_type  col  )

inherited

Returns a read/write iterator that points to the past-the-end element of the column column of the slice slice in the GenericMultiComponent3d. Iteration is done modulo the number of columns.

Parameters

slice	The index of the slice.
col	The index of the column

Returns

end col_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

const_col_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::col_end ( const size_type  slice, const size_type  col  ) const

inherited

Returns a read_only iterator that points to the past-the-end element of the column column of the slice slice in the GenericMultiComponent3d. Iteration is done modulo the number of columns.

Parameters

slice	The index of the slice.
col	The index of the column

Returns

end const_col_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

col_range_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::col_end ( const size_type  slice, const size_type  col, const slip::Range< int > &  range  )

inherited

Returns a read-write iterator that points to the past the end element of the Range range of the col col in the GenericMultiComponent3d. Iteration is done in ordinary element order according to the Range.

Parameters

slice	The index of the slice.
col	The index of the column to iterate.
range	Range of the column to iterate.

Returns

begin col_range_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Precondition

col must be compatible with the range of the GenericMultiComponent3d.

The range must be inside the whole range of the GenericMultiComponent3d.

Example:

 slip::GenericMultiComponent3d<slip::color<double> > A1(8,8,8);
 slip::GenericMultiComponent3d<slip::color<double> > A2(4,8,5);
 slip::Range<int> range(0,A1.dim2()-1,2);
//copy the the elements of the column 0 of the slice 0 of A1 iterated according to the
//range in the column 1 of the slice 1 of A2
std::copy(A1.col_begin(0,0,range),A1.col_end(0,0,range),A2.col_begin(1,1));

const_col_range_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::col_end ( const size_type  slice, const size_type  col, const slip::Range< int > &  range  ) const

inherited

Returns a read-only iterator that points to the past the end element of the Range range of the col col in the GenericMultiComponent3d. Iteration is done in ordinary element order according to the Range.

Parameters

slice	The index of the slice.
col	The index of the column to iterate.
range	Range of the column to iterate

Returns

begin const_col_range_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Precondition

col must be compatible with the range of the GenericMultiComponent3d.

The range must be inside the whole range of the GenericMultiComponent3d.

Example:

 slip::GenericMultiComponent3d<slip::color<double> > const A1(8,8,8);
 slip::GenericMultiComponent3d<slip::color<double> > A2(4,8,5);
 slip::Range<int> range(0,A1.dim2()-1,2);
//copy the the elements of the column 0 of the slice 0 of A1 iterated according to the
//range in the column 1 of the slice 1 of A2
std::copy(A1.col_begin(0,0,range),A1.col_end(0,0,range),A2.col_begin(1,1));

component_col_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::col_end ( const std::size_t  component, const size_type  slice, const size_type  col  )

inherited

Returns a read/write iterator that points to the past-the-end element of the column column of the slice slice in the GenericMultiComponent3d. Iteration is done modulo the number of columns.

Parameters

component	The component number.
slice	The index of the slice.
col	The index of the column

Returns

end col_iterator value

const_component_col_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::col_end ( const std::size_t  component, const size_type  slice, const size_type  col  ) const

inherited

Returns a read_only iterator that points to the past-the-end element of the column column of the slice slice in the GenericMultiComponent3d. Iteration is done modulo the number of columns.

Parameters

component	The component number.
slice	The index of the slice.
col	The index of the column

Returns

end const_col_iterator value

component_col_range_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::col_end ( const std::size_t  component, const size_type  slice, const size_type  col, const slip::Range< int > &  range  )

inherited

Returns a read-write iterator that points to the past the end element of the Range range of the col col in the GenericMultiComponent3d. Iteration is done in ordinary element order according to the Range.

Parameters

component	The component number.
slice	The index of the slice.
col	The index of the column to iterate.
range	Range of the column to iterate.

Returns

begin col_range_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Precondition

col must be compatible with the range of the GenericMultiComponent3d.

The range must be inside the whole range of the GenericMultiComponent3d.

 slip::Array3d<double> A1(8,8,8);
 slip::Array3d<double> A2(4,8,5);
 slip::Range<int> range(0,A1.dim1()-1,2);
//copy the the elements of the column 0 of A1 iterated according to the
//range in the column 1 of A2
std::copy(A1.col_begin(0,range),A1.col_end(0,range),A2.col_begin(1));

const_component_col_range_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::col_end ( const std::size_t  component, const size_type  slice, const size_type  col, const slip::Range< int > &  range  ) const

inherited

Returns a read-only iterator that points to the past the end element of the Range range of the col col in the GenericMultiComponent3d. Iteration is done in ordinary element order according to the Range.

Parameters

component	The component number.
slice	The index of the slice.
col	The index of the column to iterate.
range	Range of the column to iterate.

Returns

begin const_col_range_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Precondition

col must be compatible with the range of the GenericMultiComponent3d.

The range must be inside the whole range of the GenericMultiComponent3d.

 slip::Array3d<double> A1(8,8,8);
 slip::Array3d<double> A2(4,8,5);
 slip::Range<int> range(0,A1.dim1()-1,2);
//copy the the elements of the column 0 of A1 iterated according to the
//range in the column 1 of A2
std::copy(A1.col_begin(0,range),A1.col_end(0,range),A2.col_begin(1));

reverse_col_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::col_rbegin ( const size_type  slice, const size_type  col  )

inherited

Returns a read/write reverse iterator that points to the last element of the column column of the slice slice in the GenericMultiComponent3d. Iteration is done modulo the number of columns.

Parameters

slice	The index of the slice.
col	The index of the column

Returns

begin reverse_col_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

const_reverse_col_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::col_rbegin ( const size_type  slice, const size_type  col  ) const

inherited

Returns a read_only reverse iterator that points to the last element of the column column of the slice slice in the GenericMultiComponent3d. Iteration is done modulo the number of columns.

Parameters

slice	The index of the slice.
col	The index of the column

Returns

begin const_reverse_col_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

reverse_col_range_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::col_rbegin ( const size_type  slice, const size_type  col, const slip::Range< int > &  range  )

inherited

Returns a read-write iterator that points to the last element of the Range range of the col of a slice col in the GenericMultiComponent3d. Iteration is done in the reverse element order according to the Range.

Parameters

slice	The index of the slice.
col	The index of the column to iterate.
range	Range of the column to iterate.

Returns

begin reverse_col_range_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Precondition

col must be compatible with the range of the GenericMultiComponent3d.

The range must be inside the whole range of the GenericMultiComponent3d.

const_reverse_col_range_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::col_rbegin ( const size_type  slice, const size_type  col, const slip::Range< int > &  range  ) const

inherited

Returns a read_only iterator that points to the last element of the Range & range of the col of a slice col in the GenericMultiComponent3d. Iteration is done in the reverse element order according to the Range.

Parameters

slice	The index of the slice.
col	The index of the column to iterate.
range	Range of the column to iterate.

Returns

begin const_reverse_col_range_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Precondition

col must be compatible with the range of the GenericMultiComponent3d.

The range must be inside the whole range of the GenericMultiComponent3d.

reverse_component_col_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::col_rbegin ( const std::size_t  component, const size_type  slice, const size_type  col  )

inherited

Returns a read/write reverse iterator that points to the last element of the column column of the slice slice in the GenericMultiComponent3d. Iteration is done modulo the number of columns.

Parameters

component	The component number.
slice	The index of the slice.
col	The index of the column

Returns

begin reverse_col_iterator value

const_reverse_component_col_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::col_rbegin ( const std::size_t  component, const size_type  slice, const size_type  col  ) const

inherited

Returns a read_only reverse iterator that points to the last element of the column column of the slice slice in the GenericMultiComponent3d. Iteration is done modulo the number of columns.

Parameters

component	The component number.
slice	The index of the slice.
col	The index of the column

Returns

begin const_reverse_col_iterator value

reverse_component_col_range_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::col_rbegin ( const std::size_t  component, const size_type  slice, const size_type  col, const slip::Range< int > &  range  )

inherited

Returns a read-write iterator that points to the last element of the Range range of the col of a slice col in the GenericMultiComponent3d. Iteration is done in the reverse element order according to the Range.

Parameters

component	The component number.
slice	The index of the slice.
col	The index of the column to iterate.
range	Range of the column to iterate.

Returns

begin reverse_col_range_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Precondition

col must be compatible with the range of the GenericMultiComponent3d.

The range must be inside the whole range of the GenericMultiComponent3d.

const_reverse_component_col_range_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::col_rbegin ( const std::size_t  component, const size_type  slice, const size_type  col, const slip::Range< int > &  range  ) const

inherited

Returns a read_only iterator that points to the last element of the Range & range of the col of a slice col in the GenericMultiComponent3d. Iteration is done in the reverse element order according to the Range.

Parameters

component	The component number.
slice	The index of the slice.
col	The index of the column to iterate.
range	Range of the column to iterate.

Returns

begin const_reverse_col_range_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Precondition

col must be compatible with the range of the GenericMultiComponent3d.

The range must be inside the whole range of the GenericMultiComponent3d.

reverse_col_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::col_rend ( const size_type  slice, const size_type  col  )

inherited

Returns a read/write reverse iterator that points to the first element of the column column of the slice slice in the GenericMultiComponent3d. Iteration is done modulo the number of columns.

Parameters

slice	The index of the slice.
col	The index of the column

Returns

end reverse_col_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

const_reverse_col_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::col_rend ( const size_type  slice, const size_type  col  ) const

inherited

Returns a read_only reverse iterator that points to the first element of the column column of the slice slice in the GenericMultiComponent3d. Iteration is done modulo the number of columns.

Parameters

slice	The index of the slice.
col	The index of the column

Returns

end const_reverse_col_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

reverse_col_range_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::col_rend ( const size_type  slice, const size_type  col, const slip::Range< int > &  range  )

inherited

Returns a read-write iterator that points to one before the first element of the Range range of the col of a slice col in the GenericMultiComponent3d. Iteration is done in the reverse element order according to the Range.

Parameters

slice	The index of the slice.
col	The index of the column to iterate.
range	Range of the column to iterate.

Returns

reverse_col_range_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Precondition

col must be compatible with the range of the GenericMultiComponent3d.

The range must be inside the whole range of the GenericMultiComponent3d.

const_reverse_col_range_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::col_rend ( const size_type  slice, const size_type  col, const slip::Range< int > &  range  ) const

inherited

Returns a read-only iterator that points to the first element of the Range range of the col of a slice col in the GenericMultiComponent3d. Iteration is done in the reverse element order according to the Range.

Parameters

slice	The index of the slice.
col	The index of the column to iterate.
range	Range of the column to iterate.

Returns

const_reverse_col_range_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Precondition

col must be compatible with the range of the GenericMultiComponent3d.

The range must be inside the whole range of the GenericMultiComponent3d.

reverse_component_col_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::col_rend ( const std::size_t  component, const size_type  slice, const size_type  col  )

inherited

Returns a read/write reverse iterator that points to the first element of the column column of the slice slice in the GenericMultiComponent3d. Iteration is done modulo the number of columns.

Parameters

component	The component number.
slice	The index of the slice.
col	The index of the column

Returns

end reverse_col_iterator value

const_reverse_component_col_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::col_rend ( const std::size_t  component, const size_type  slice, const size_type  col  ) const

inherited

Returns a read_only reverse iterator that points to the first element of the column column of the slice slice in the GenericMultiComponent3d. Iteration is done modulo the number of columns.

Parameters

component	The component number.
slice	The index of the slice.
col	The index of the column

Returns

end const_reverse_col_iterator value

reverse_component_col_range_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::col_rend ( const std::size_t  component, const size_type  slice, const size_type  col, const slip::Range< int > &  range  )

inherited

Returns a read-write iterator that points to one before the first element of the Range range of the col of a slice col in the GenericMultiComponent3d. Iteration is done in the reverse element order according to the Range.

Parameters

component	The component number.
slice	The index of the slice.
col	The index of the column to iterate.
range	Range of the column to iterate.

Returns

reverse_col_range_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Precondition

col must be compatible with the range of the GenericMultiComponent3d.

The range must be inside the whole range of the GenericMultiComponent3d.

const_reverse_component_col_range_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::col_rend ( const std::size_t  component, const size_type  slice, const size_type  col, const slip::Range< int > &  range  ) const

inherited

Returns a read-only iterator that points to the first element of the Range range of the col of a slice col in the GenericMultiComponent3d. Iteration is done in the reverse element order according to the Range.

Parameters

component	The component number.
slice	The index of the slice.
col	The index of the column to iterate.
range	Range of the column to iterate.

Returns

const_reverse_col_range_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Precondition

col must be compatible with the range of the GenericMultiComponent3d.

The range must be inside the whole range of the GenericMultiComponent3d.

size_type slip::GenericMultiComponent3d< slip::Vector3d< T > >::cols ( ) const

inherited

Returns the number of columns (third dimension size) in the GenericMultiComponent3d.

size_type slip::GenericMultiComponent3d< slip::Vector3d< T > >::columns ( ) const

inherited

Returns the number of columns (third dimension size) in the GenericMultiComponent3d.

size_type slip::GenericMultiComponent3d< slip::Vector3d< T > >::dim1 ( ) const

inherited

Returns the number of slices (first dimension size) in the GenericMultiComponent3d.

size_type slip::GenericMultiComponent3d< slip::Vector3d< T > >::dim2 ( ) const

inherited

Returns the number of rows (second dimension size) in the GenericMultiComponent3d.

size_type slip::GenericMultiComponent3d< slip::Vector3d< T > >::dim3 ( ) const

inherited

Returns the number of columns (third dimension size) in the GenericMultiComponent3d.

bool slip::GenericMultiComponent3d< slip::Vector3d< T > >::empty ( ) const

inherited

Returns true if the GenericMultiComponent3d is empty. (Thus size() == 0)

iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::end ( )

inherited

Returns a read/write iterator that points one past the last element in the GenericMultiComponent3d. Iteration is done in ordinary element order.

Returns

end iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Example:

 slip::GenericMultiComponent3d<slip::color<double> > A1(10,9,5);
 slip::GenericMultiComponent3d<slip::color<double> > A2(10,9,5);
 slip::GenericMultiComponent3d<slip::color<double> > S(10,9,5);
//copy A1 in S
std::copy(A1.begin(),A1.end(),S.begin());

const_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::end ( ) const

inherited

Returns a read-only (constant) iterator that points one past the last element in the GenericMultiComponent3d. Iteration is done in ordinary element order.

Returns

const end iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Example:

slip::GenericMultiComponent3d<slip::color<double> > const A1(10,9,5);
slip::GenericMultiComponent3d<slip::color<double> > const A2(10,9,5);
slip::GenericMultiComponent3d<slip::color<double> > S(10,9,5);

component_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::end ( const std::size_t  component )

inherited

Returns a read/write iterator that points one past the last element in the GenericMultiComponent3d. Iteration is done in ordinary element order.

Parameters

component

The component number.

Returns

end component_iterator value

const_component_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::end ( const std::size_t  component ) const

inherited

Returns a read-only (constant) iterator that points one past the last element in the GenericMultiComponent3d. Iteration is done in ordinary element order.

Parameters

component

The component number.

Returns

const end component_iterator value

void slip::GenericMultiComponent3d< slip::Vector3d< T > >::fill ( const slip::Vector3d< T > &  value )

inlineinherited

Fills the container range [begin(),begin()+size()) with copies of value.

Parameters

value

A reference-to-const of arbitrary type.

Definition at line 4929 of file GenericMultiComponent3d.hpp.

void slip::GenericMultiComponent3d< slip::Vector3d< T > >::fill ( const typename slip::Vector3d< T > ::pointer  value )

inlineinherited

Fills the container range [begin(),begin()+size()) with a copy of the value array.

Parameters

value

A pointer of arbitrary type.

Definition at line 4940 of file GenericMultiComponent3d.hpp.

void slip::GenericMultiComponent3d< slip::Vector3d< T > >::fill ( const slip::Vector3d< T > *  value )

inlineinherited

Fills the container range [begin(),begin()+size()) with a copy of the value array.

Parameters

value

A pointer of arbitrary type.

Definition at line 4951 of file GenericMultiComponent3d.hpp.

void slip::GenericMultiComponent3d< slip::Vector3d< T > >::fill ( InputIterator  first, InputIterator  last  )

inlineinherited

Fills the container range [begin(),begin()+size()) with a copy of the range [first,last)

Parameters

first	An input iterator.
last	An input iterator.

Definition at line 4965 of file GenericMultiComponent3d.hpp.

void slip::GenericMultiComponent3d< slip::Vector3d< T > >::fill ( std::vector< InputIterator >  first_iterators_list, InputIterator  last  )

inlineinherited

Fills the container range [begin(),begin()+size()) with a copy of the range [first,last)

Parameters

first_iterators_list	An input iterator list.
last	An input iterator.

Definition at line 4980 of file GenericMultiComponent3d.hpp.

void slip::GenericMultiComponent3d< slip::Vector3d< T > >::fill ( std::size_t  component, InputIterator  first, InputIterator  last  )

inlineinherited

Fills the container range [begin(),begin()+size()) with a copy of the range [first,last)

Parameters

component	The component number.
first	An input iterator.
last	An input iterator.

Definition at line 5012 of file GenericMultiComponent3d.hpp.

iterator3d slip::GenericMultiComponent3d< slip::Vector3d< T > >::front_upper_left ( )

inherited

Returns a read/write iterator3d that points to the first element of the GenericMultiComponent3d. It points to the front upper left element of the GenericMultiComponent3d.

Returns

begin iterator3d value

Remarks

This iterator is compatible with BidirectionalIterator algorithms.

Example

slip::GenericMultiComponent3d<slip::color<double> > M(3,4,5);
//Print M
std::copy(M.front_upper_left(),M.back_bottom_right(),
          std::ostream_iterator<slip::color<double> >(std::cout," "));

const_iterator3d slip::GenericMultiComponent3d< slip::Vector3d< T > >::front_upper_left ( ) const

inherited

Returns a read-only iterator3d that points to the first element of the GenericMultiComponent3d. It points to the front upper left element of the GenericMultiComponent3d.

Returns

begin const iterator3d value

Remarks

This iterator is compatible with BidirectionalIterator algorithms.

Example

slip::GenericMultiComponent3d<slip::color<double> > const M(3,4,5);
//Print M
std::copy(M.front_upper_left(),M.back_bottom_right(),
          std::ostream_iterator<slip::color<double> >(std::cout," "));

iterator3d slip::GenericMultiComponent3d< slip::Vector3d< T > >::front_upper_left ( const Box3d< int > &  box )

inherited

Returns a read/write iterator3d that points to the first element of the GenericMultiComponent3d. It points to the front upper left element of the Box3d associated to the GenericMultiComponent3d.

Parameters

box	A Box3d defining the range of indices to iterate within the GenericMultiComponent3d.

Remarks

This iterator is compatible with BidirectionalIterator algorithms.

Returns

end iterator3d value

Precondition

The box indices must be inside the range of the GenericMultiComponent3d ones.

Example

slip::GenericMultiComponent3d<slip::color<double> > M(3,4,5);
slip::Box3d<int> b(1,1,1,2,2,3);
//Print M within a box
std::copy(M.front_upper_left(b),M.back_bottom_right(b),
          std::ostream_iterator<slip::color<double> >(std::cout," "));

const_iterator3d slip::GenericMultiComponent3d< slip::Vector3d< T > >::front_upper_left ( const Box3d< int > &  box ) const

inherited

Returns a read only iterator3d that points to the first element of the GenericMultiComponent3d. It points to the front upper left element of the Box3d associated to the GenericMultiComponent3d.

Parameters

box	a Box3d defining the range of indices to iterate within the GenericMultiComponent3d.

Returns

end const iterator3d value

Remarks

This iterator is compatible with BidirectionalIterator algorithms.

Precondition

The box indices must be inside the range of the GenericMultiComponent3d ones.

Example

slip::GenericMultiComponent3d<slip::color<double> > const M(3,4,5);
slip::Box3d<int> b(1,1,1,2,2,3);
//Print M within a box
std::copy(M.front_upper_left(b),M.back_bottom_right(b),
          std::ostream_iterator<slip::color<double> >(std::cout," "));

iterator3d_range slip::GenericMultiComponent3d< slip::Vector3d< T > >::front_upper_left ( const Range< int > &  slice_range, const Range< int > &  row_range, const Range< int > &  col_range  )

inherited

Returns a read/write iterator3d_range that points to the front upper left element of the ranges slice_range, row_range and col_range associated to the GenericMultiComponent3d.

Parameters

slice_range	The range of the slices.
row_range	The range of the rows.
col_range	The range of the columns.

Precondition

slice_range, row_range and col_range must be valid.

The ranges indices must be inside the ranges of the GenericMultiComponent3d ones.

Returns

iterator3d_range value

Remarks

This iterator is compatible with BidirectionalIterator algorithms.

Example

slip::GenericMultiComponent3d<slip::color<double> > M(3,4,5);
slip::Range<int> sr(0,2,2);
slip::Range<int> rr(0,3,2);
slip::Range<int> cr(0,4,2);
//Print M within a range
std::copy(M.front_upper_left(sr,rr,cr),M.back_bottom_right(sr,rr,cr),
          std::ostream_iterator<slip::color<double> >(std::cout," "));

const_iterator3d_range slip::GenericMultiComponent3d< slip::Vector3d< T > >::front_upper_left ( const Range< int > &  slice_range, const Range< int > &  row_range, const Range< int > &  col_range  ) const

inherited

Returns a read-only iterator3d_range that points to the to the front upper left element of the ranges slice_range, row_range and col_range associated to the GenericMultiComponent3d.

Parameters

slice_range	The range of the slices.
row_range	The range of the rows.
col_range	The range of the columns.

Precondition

slice_range, row_range and col_range must be valid.

The ranges indices must be inside the ranges of the GenericMultiComponent3d ones.

Returns

const_iterator3d_range value

Remarks

This iterator is compatible with BidirectionalIterator algorithms.

Example

slip::GenericMultiComponent3d<slip::color<double> > const M(3,4,5);
slip::Range<int> sr(0,2,2);
slip::Range<int> rr(0,3,2);
slip::Range<int> cr(0,4,2);
//Print M within a range
std::copy(M.front_upper_left(sr,rr,cr),M.back_bottom_right(sr,rr,cr),
          std::ostream_iterator<slip::color<double> >(std::cout," "));

component_iterator3d slip::GenericMultiComponent3d< slip::Vector3d< T > >::front_upper_left ( const std::size_t  component )

inherited

Returns a read/write component_iterator3d that points to the first element of the GenericMultiComponent3d. It points to the front upper left element of the GenericMultiComponent3d.

Parameters

component

The component number.

Returns

begin iterator3d value

Remarks

This iterator is compatible with BidirectionalIterator algorithms.

 slip::GenericMultiComponent3d<slip::Vector3d<double> > A1(8,8,4);
 slip::GenericMultiComponent3d<slip::Vector3d<double> > A2(8,8,4);
//copy the first component of the elements of A1 in A2
std::copy(A1.front_upper_left(0),A1.back_bottom_right(0),A2.front_upper_left(0));

const_component_iterator3d slip::GenericMultiComponent3d< slip::Vector3d< T > >::front_upper_left ( const std::size_t  component ) const

inherited

Returns a read only const_component_iterator3d that points to the first element of the GenericMultiComponent3d. It points to the front upper left element of the GenericMultiComponent3d.

Parameters

component

The component number.

Returns

begin iterator3d value

Remarks

This iterator is compatible with BidirectionalIterator algorithms.

component_iterator3d slip::GenericMultiComponent3d< slip::Vector3d< T > >::front_upper_left ( const std::size_t  component, const Box3d< int > &  box  )

inherited

Returns a read/write component iterator3d that points to the first element of the GenericMultiComponent3d. It points to the front upper left element of the Box3d associated to the GenericMultiComponent3d.

Parameters

component	The component number.
box	A Box3d defining the range of indices to iterate within the GenericMultiComponent3d.

Remarks

This iterator is compatible with BidirectionalIterator algorithms.

Returns

end iterator3d value

Precondition

The box indices must be inside the range of the GenericMultiComponent3d ones.

const_component_iterator3d slip::GenericMultiComponent3d< slip::Vector3d< T > >::front_upper_left ( const std::size_t  component, const Box3d< int > &  box  ) const

inherited

Returns a read only component iterator3d that points to the first element of the GenericMultiComponent3d. It points to the front upper left element of the Box3d associated to the GenericMultiComponent3d.

Parameters

component	The component number.
box	a Box3d defining the range of indices to iterate within the GenericMultiComponent3d.

Returns

end const iterator3d value

Remarks

This iterator is compatible with BidirectionalIterator algorithms.

Precondition

The box indices must be inside the range of the GenericMultiComponent3d ones.

component_iterator3d_range slip::GenericMultiComponent3d< slip::Vector3d< T > >::front_upper_left ( const std::size_t  component, const Range< int > &  slice_range, const Range< int > &  row_range, const Range< int > &  col_range  )

inherited

Returns a read/write component_iterator3d_range that points to the front upper left element of the ranges slice_range, row_range and col_range associated to the GenericMultiComponent3d.

Parameters

component	The component number.
slice_range	The range of the slices.
row_range	The range of the rows.
col_range	The range of the columns.

Precondition

slice_range, row_range and col_range must be valid.

The ranges indices must be inside the ranges of the GenericMultiComponent3d ones.

Returns

iterator3d_range value

Remarks

This iterator is compatible with BidirectionalIterator algorithms.

const_component_iterator3d_range slip::GenericMultiComponent3d< slip::Vector3d< T > >::front_upper_left ( const std::size_t  component, const Range< int > &  slice_range, const Range< int > &  row_range, const Range< int > &  col_range  ) const

inherited

Returns a read/write component_const_iterator3d_range that points to the front upper left element of the ranges slice_range, row_range and col_range associated to the GenericMultiComponent3d.

Parameters

component	The component number.
slice_range	The range of the slices.
row_range	The range of the rows.
col_range	The range of the columns.

Precondition

slice_range, row_range and col_range must be valid.

The ranges indices must be inside the ranges of the GenericMultiComponent3d ones.

Returns

iterator3d_range value

Remarks

This iterator is compatible with BidirectionalIterator algorithms.

slip::Vector3d< T > slip::GenericMultiComponent3d< slip::Vector3d< T > >::max ( ) const

inherited

Returns the max elements of the GenericMultiComponent3d according to the operator <.

Precondition

size() != 0

size_type slip::GenericMultiComponent3d< slip::Vector3d< T > >::max_size ( ) const

inherited

Returns the maximal size (number of elements) in the GenericMultiComponent3d.

slip::Vector3d< T > slip::GenericMultiComponent3d< slip::Vector3d< T > >::min ( ) const

inherited

Returns the min elements of the GenericMultiComponent3d according to the operator <.

Precondition

size() != 0

template<typename T >

std::string slip::DenseVector3dField3d< T >::name ( ) const

inline

Returns the name of the class.

Definition at line 1277 of file DenseVector3dField3d.hpp.

template<typename T >

DenseVector3dField3d< T >::norm_type slip::DenseVector3dField3d< T >::norm ( const size_type  k, const size_type  i, const size_type  j  ) const

inline

Subscript access to a local norm contained in the DenseVector3dField3d.

Parameters

k	The index of the slice for which the data should be accessed.
i	The index of the row for which the data should be accessed.
j	The index of the columns for which the data should be accessed.

Returns

Read_only (constant) reference to data.

Precondition

k < slices()

i < rows()

j < columns()

This operator allows for easy, 3d array-style, data access. Note that data access with this operator is unchecked and out_of_range lookups are not defined.

Definition at line 1145 of file DenseVector3dField3d.hpp.

template<typename T>

template<typename Container3D >

void slip::DenseVector3dField3d< T >::norm ( Container3D &  result )

inline

Computes Eucliean norm of each element in the field and write it to a Container3D.

Author

Benoit Tremblais <benoit.tremblais_AT_sic.univ-poitiers.fr>

Date

2008/05/25

Version

0.0.1

Parameters

result

A Container3D which contain the norm of each element.

Definition at line 753 of file DenseVector3dField3d.hpp.

reference slip::GenericMultiComponent3d< slip::Vector3d< T > >::operator() ( const size_type  k, const size_type  i, const size_type  j  )

inherited

Subscript access to the data contained in the GenericMultiComponent3d.

Parameters

k	The index of the slice for which the data should be accessed.
i	The index of the row for which the data should be accessed.
j	The index of the column for which the data should be accessed.

Returns

Read/Write reference to data.

Precondition

k < slices()

i < rows()

j < cols() This operator allows for easy, 3d array-style, data access. Note that data access with this operator is unchecked and out_of_range lookups are not defined.

const_reference slip::GenericMultiComponent3d< slip::Vector3d< T > >::operator() ( const size_type  k, const size_type  i, const size_type  j  ) const

inherited

Subscript access to the data contained in the GenericMultiComponent3d.

Parameters

k	The index of the slice for which the data should be accessed.
i	The index of the row for which the data should be accessed.
j	The index of the column for which the data should be accessed.

Returns

Read_only (constant) reference to data.

Precondition

k < slices()

i < rows()

j < cols() This operator allows for easy, 3d array-style, data access. Note that data access with this operator is unchecked and out_of_range lookups are not defined.

template<typename T>

DenseVector3dField3d< T > & slip::DenseVector3dField3d< T >::operator*= ( const T &  val )

inline

Definition at line 1171 of file DenseVector3dField3d.hpp.

template<typename T>

DenseVector3dField3d< T > & slip::DenseVector3dField3d< T >::operator*= ( const slip::Vector3d< T > &  val )

inline

Definition at line 1205 of file DenseVector3dField3d.hpp.

template<typename T>

DenseVector3dField3d< T > & slip::DenseVector3dField3d< T >::operator*= ( const self &  rhs )

inline

Definition at line 1254 of file DenseVector3dField3d.hpp.

template<typename T>

DenseVector3dField3d< T > & slip::DenseVector3dField3d< T >::operator+= ( const T &  val )

inline

Add val to each element of the DenseVector3dField3d.

Parameters

val

value

Returns

reference to the resulting DenseVector3dField3d

Definition at line 1155 of file DenseVector3dField3d.hpp.

template<typename T>

DenseVector3dField3d< T > & slip::DenseVector3dField3d< T >::operator+= ( const slip::Vector3d< T > &  val )

inline

Add val to each element of the DenseVector3dField3d.

Parameters

val

value

Returns

reference to the resulting DenseVector3dField3d

Definition at line 1189 of file DenseVector3dField3d.hpp.

template<typename T>

DenseVector3dField3d< T > & slip::DenseVector3dField3d< T >::operator+= ( const self &  rhs )

inline

Definition at line 1232 of file DenseVector3dField3d.hpp.

template<typename T >

DenseVector3dField3d< T > slip::DenseVector3dField3d< T >::operator- ( ) const

inline

Definition at line 1223 of file DenseVector3dField3d.hpp.

template<typename T>

DenseVector3dField3d< T > & slip::DenseVector3dField3d< T >::operator-= ( const T &  val )

inline

Definition at line 1163 of file DenseVector3dField3d.hpp.

template<typename T>

DenseVector3dField3d< T > & slip::DenseVector3dField3d< T >::operator-= ( const slip::Vector3d< T > &  val )

inline

Definition at line 1197 of file DenseVector3dField3d.hpp.

template<typename T>

DenseVector3dField3d< T > & slip::DenseVector3dField3d< T >::operator-= ( const self &  rhs )

inline

Definition at line 1243 of file DenseVector3dField3d.hpp.

template<typename T>

DenseVector3dField3d< T > & slip::DenseVector3dField3d< T >::operator/= ( const T &  val )

inline

Definition at line 1179 of file DenseVector3dField3d.hpp.

template<typename T>

DenseVector3dField3d< T > & slip::DenseVector3dField3d< T >::operator/= ( const slip::Vector3d< T > &  val )

inline

Definition at line 1213 of file DenseVector3dField3d.hpp.

template<typename T>

DenseVector3dField3d< T > & slip::DenseVector3dField3d< T >::operator/= ( const self &  rhs )

inline

Definition at line 1265 of file DenseVector3dField3d.hpp.

template<typename T>

DenseVector3dField3d< T > & slip::DenseVector3dField3d< T >::operator= ( const slip::Vector3d< T > &  val )

inline

Affects all the element of the DenseVector3dField3d by val.

Parameters

val	affectation value

Returns

reference to corresponding DenseVector3dField3d

Definition at line 1019 of file DenseVector3dField3d.hpp.

template<typename T>

DenseVector3dField3d< T > & slip::DenseVector3dField3d< T >::operator= ( const T &  val )

inline

Affects all the element of the DenseVector3dField3d by val.

Parameters

val	affectation value

Returns

reference to corresponding DenseVector3dField3d

Definition at line 1028 of file DenseVector3dField3d.hpp.

pointer* slip::GenericMultiComponent3d< slip::Vector3d< T > >::operator[] ( const size_type  k )

inherited

Subscript access to the slice datas contained in the GenericMultiComponent3d.

Parameters

k	The index of the slice for which data should be accessed.

Returns

Read/write pointer to the slice data.

Precondition

k < slices()

This operator allows for easy, 3d array-style, data access. Note that data access with this operator is unchecked and out_of_range lookups are not defined.

const_pointer const* slip::GenericMultiComponent3d< slip::Vector3d< T > >::operator[] ( const size_type  k ) const

inherited

Subscript access to the slice datas contained in the GenericMultiComponent3d.

Parameters

k	The index of the slice for which data should be accessed.

Returns

Read-only (constant) pointer* to the slice data.

Precondition

k < slices()

This operator allows for easy, 3d array-style, data access. Note that data access with this operator is unchecked and out_of_range lookups are not defined.

iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::plane_begin ( const size_type  slice )

inherited

Returns a read/write iterator that points to the first element in the in the slice plane of the GenericMultiComponent3d. Iteration is done in ordinary element order.

Parameters

slice

the slice coordinate of the plane

Returns

begin iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Example:

slip::GenericMultiComponent3d<slip::color<double> > A1(2,3,2);
slip::GenericMultiComponent3d<slip::color<double> > A2(2,3,2);
//copy the first plane (in slice direction) of A1 in A2
std::copy(A1.plane_begin(0),A1.plane_end(0),A2.plane_begin(0));

const_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::plane_begin ( const size_type  slice ) const

inherited

Returns a read-only (constant) iterator that points to the first element in the slice plane of the GenericMultiComponent3d. Iteration is done in ordinary element order.

Parameters

slice

the slice coordinate of the plane

Returns

const begin iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Example:

slip::GenericMultiComponent3d<slip::color<double> > const A1(2,3,2);
slip::GenericMultiComponent3d<slip::color<double> > A2(2,3,2);
//copy the first plane (in slice direction) of A1 in A2
std::copy(A1.plane_begin(0),A1.plane_end(0),A2.plane_begin(0));

component_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::plane_begin ( const std::size_t  component, const size_type  slice  )

inherited

Returns a read/write iterator that points to the first element in the in the slice plane of the GenericMultiComponent3d. Iteration is done in ordinary element order.

Parameters

component	The component number.
slice	the slice coordinate of the plane

Returns

begin component iterator value

const_component_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::plane_begin ( const std::size_t  component, const size_type  slice  ) const

inherited

Returns a read-only (constant) iterator that points to the first element in the slice plane of the GenericMultiComponent3d. Iteration is done in ordinary element order.

Parameters

component	The component number.
slice	the slice coordinate of the plane

Returns

const begin component iterator value

iterator2d slip::GenericMultiComponent3d< slip::Vector3d< T > >::plane_bottom_right ( PLANE_ORIENTATION  P, const size_type  plane_coordinate  )

inherited

Returns a read/write iterator that points to the last element of the plane in the GenericMultiComponent3d. It points to past the end element of the bottom right element of the plane Iteration is done in ordinary element order.

Parameters

P	number of the plane axe (PLANE_ORIENTATION).
plane_coordinate	The constant coordinate

Returns

begin iterator2d value

Precondition

P must be 0,1 or 2

Remarks

This iterator is compatible with BidirectionnalAccessIterator algorithms.

Example:

slip::GenericMultiComponent3d<slip::color<double> > M(3,4,5);
//Print the 2nd plane of M in the KI_PLANE direction
std::copy(M.plane_upper_left(slip::KI_PLANE,2),M.plane_bottom_right(
          slip::KI_PLANE,2),std::ostream_iterator<slip::color<double> >(std::cout," "));

const_iterator2d slip::GenericMultiComponent3d< slip::Vector3d< T > >::plane_bottom_right ( PLANE_ORIENTATION  P, const size_type  plane_coordinate  ) const

inherited

Returns a read/write const iterator that points to the last element of the plane in the GenericMultiComponent3d. It points to past the end element of the bottom right element of the plane Iteration is done in ordinary element order.

Parameters

P	number of the plane axe (PLANE_ORIENTATION).
plane_coordinate	The constant coordinate

Returns

begin const_iterator2d value

Precondition

P must be 0,1 or 2

Remarks

This iterator is compatible with BidirectionnalAccessIterator algorithms.

Example:

slip::GenericMultiComponent3d<slip::color<double> > const M(3,4,5);
//Print the 2nd plane of M in the KI_PLANE direction
std::copy(M.plane_upper_left(slip::KI_PLANE,2),M.plane_bottom_right(
          slip::KI_PLANE,2),std::ostream_iterator<slip::color<double> >(std::cout," "));

iterator2d slip::GenericMultiComponent3d< slip::Vector3d< T > >::plane_bottom_right ( PLANE_ORIENTATION  P, const size_type  plane_coordinate, const Box2d< int > &  b  )

inherited

Returns a read/write iterator that points to the last element of a box within a plane in the GenericMultiComponent3d. It points to past the end element of the bottom right element of the plane Iteration is done in ordinary element order.

Parameters

P	number of the plane axe (PLANE_ORIENTATION).
plane_coordinate	The constant coordinate
b	The box within the plane

Returns

begin iterator2d value

Precondition

P must be 0,1 or 2

b must be within the plane

Remarks

This iterator is compatible with BidirectionnalAccessIterator algorithms.

Example

slip::GenericMultiComponent3d<slip::color<double> > M(3,4,5);
slip::Box2d<int> b(1,1,3,3);
//Print the 2nd plane of M in the KI_PLANE direction within a box
std::copy(M.plane_upper_left(slip::KI_PLANE,2,b),M.plane_bottom_right(
          slip::KI_PLANE,2,b),std::ostream_iterator<slip::color<double> >(std::cout," "));

const_iterator2d slip::GenericMultiComponent3d< slip::Vector3d< T > >::plane_bottom_right ( PLANE_ORIENTATION  P, const size_type  plane_coordinate, const Box2d< int > &  b  ) const

inherited

Returns a read/write const iterator that points to the last element of a box within a plane in the GenericMultiComponent3d. It points to past the end element of the bottom right element of the plane Iteration is done in ordinary element order.

Parameters

P	number of the plane axe (PLANE_ORIENTATION).
plane_coordinate	The constant coordinate
b	The box within the plane

Returns

begin const_iterator2d value

Precondition

P must be 0,1 or 2

b must be within the plane

Remarks

This iterator is compatible with BidirectionnalAccessIterator algorithms.

Example

slip::GenericMultiComponent3d<slip::color<double> > const M(3,4,5);
slip::Box2d<int> b(1,1,3,3);
//Print the 2nd plane of M in the KI_PLANE direction within a box
std::copy(M.plane_upper_left(slip::KI_PLANE,2,b),M.plane_bottom_right(
          slip::KI_PLANE,2,b),std::ostream_iterator<slip::color<double> >(std::cout," "));

iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::plane_end ( const size_type  slice )

inherited

Returns a read/write iterator that points one past the last element in the slice plane of the GenericMultiComponent3d. Iteration is done in ordinary element order.

Parameters

slice

the slice coordinate of the plane

Returns

end iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Example:

slip::GenericMultiComponent3d<slip::color<double> > A1(2,3,2);
slip::GenericMultiComponent3d<slip::color<double> > A2(2,3,2);
//copy the first plane (in slice direction) of A1 in A2
std::copy(A1.plane_begin(0),A1.plane_end(0),A2.plane_begin(0));

const_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::plane_end ( const size_type  slice ) const

inherited

Returns a read-only (constant) iterator that points one past the last element in the slice plane of the GenericMultiComponent3d. Iteration is done in ordinary element order.

Parameters

slice

the slice coordinate of the plane

Returns

const end iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Example:

slip::GenericMultiComponent3d<slip::color<double> > const A1(2,3,2);
slip::GenericMultiComponent3d<slip::color<double> > A2(2,3,2);
//copy the first plane (in slice direction) of A1 in A2
std::copy(A1.plane_begin(0),A1.plane_end(0),A2.plane_begin(0));

component_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::plane_end ( const std::size_t  component, const size_type  slice  )

inherited

Returns a read/write iterator that points one past the last element in the slice plane of the GenericMultiComponent3d. Iteration is done in ordinary element order.

Parameters

component	The component number.
slice	the slice coordinate of the plane

Returns

end component iterator value

const_component_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::plane_end ( const std::size_t  component, const size_type  slice  ) const

inherited

Returns a read-only (constant) iterator that points one past the last element in the slice plane of the GenericMultiComponent3d. Iteration is done in ordinary element order.

Parameters

component	The component number.
slice	the slice coordinate of the plane

Returns

const end component iterator value

reverse_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::plane_rbegin ( const size_type  slice )

inherited

Returns a read/write reverse iterator that points to the last element in the slice plane of the GenericMultiComponent3d. Iteration is done in reverse element order.

Parameters

slice

the slice coordinate of the plane

Returns

reverse begin iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Example:

slip::GenericMultiComponent3d<slip::color<double> > A1(2,3,2);
slip::GenericMultiComponent3d<slip::color<double> > A2(2,3,2);
//copy the first plane (in slice direction) of A1 in A2 in reverse order
std::copy(A1.plane_rbegin(0),A1.plane_rend(0),A2.plane_begin(0));

const_reverse_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::plane_rbegin ( const size_type  slice ) const

inherited

Returns a read-only (constant) reverse iterator that points to the last element in the slice plane k of the GenericMultiComponent3d. Iteration is done in reverse element order.

Parameters

slice

the slice coordinate of the plane

Returns

const reverse begin iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Example:

slip::GenericMultiComponent3d<slip::color<double> > const A1(2,3,2);
slip::GenericMultiComponent3d<slip::color<double> > A2(2,3,2);
//copy the first plane (in slice direction) of A1 in A2 in reverse order
std::copy(A1.plane_rbegin(0),A1.plane_rend(0),A2.plane_begin(0));

reverse_component_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::plane_rbegin ( const std::size_t  component, const size_type  slice  )

inherited

Returns a read/write reverse iterator that points to the last element in the slice plane of the GenericMultiComponent3d. Iteration is done in reverse element order.

Parameters

component	The component number.
slice	the slice coordinate of the plane

Returns

reverse begin component iterator value

const_reverse_component_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::plane_rbegin ( const std::size_t  component, const size_type  slice  ) const

inherited

Returns a read-only (constant) reverse iterator that points to the last element in the slice plane k of the GenericMultiComponent3d. Iteration is done in reverse element order.

Parameters

component	The component number.
slice	the slice coordinate of the plane

Returns

const reverse begin component iterator value

reverse_iterator2d slip::GenericMultiComponent3d< slip::Vector3d< T > >::plane_rbottom_right ( PLANE_ORIENTATION  P, const size_type  plane_coordinate  )

inherited

Returns a read/write reverse_iterator that points to the upper left element of the plane in the GenericMultiComponent3d. Iteration is done in backward element order.

Parameters

P	number of the plane axe (PLANE_ORIENTATION).
plane_coordinate	The constant coordinate

Returns

begin iterator2d value

Precondition

P must be 0,1 or 2

Remarks

This iterator is compatible with BidirectionnalAccessIterator algorithms.

Example:

slip::GenericMultiComponent3d<slip::color<double> > M(3,4,5);
//Print the 2nd plane of M in the KI_PLANE direction in reverse order
std::copy(M.plane_rupper_left(slip::KI_PLANE,2),M.plane_rbottom_right(
          slip::KI_PLANE,2),std::ostream_iterator<slip::color<double> >(std::cout," "));

const_reverse_iterator2d slip::GenericMultiComponent3d< slip::Vector3d< T > >::plane_rbottom_right ( PLANE_ORIENTATION  P, const size_type  plane_coordinate  ) const

inherited

Returns a read/write const reverse iterator that points to the upper left element of the plane in the GenericMultiComponent3d. Iteration is done in backward element order.

Parameters

P	number of the plane axe (PLANE_ORIENTATION).
plane_coordinate	The constant coordinate

Returns

begin const_iterator2d value

Precondition

P must be 0,1 or 2

Remarks

This iterator is compatible with BidirectionnalAccessIterator algorithms.

Example:

slip::GenericMultiComponent3d<slip::color<double> > const M(3,4,5);
//Print the 2nd plane of M in the KI_PLANE direction in reverse order
std::copy(M.plane_rupper_left(slip::KI_PLANE,2),M.plane_rbottom_right(
          slip::KI_PLANE,2),std::ostream_iterator<slip::color<double> >(std::cout," "));

reverse_iterator2d slip::GenericMultiComponent3d< slip::Vector3d< T > >::plane_rbottom_right ( PLANE_ORIENTATION  P, const size_type  plane_coordinate, const Box2d< int > &  b  )

inherited

Returns a read/write reverse iterator that points to the first element of a box within a plane in the GenericMultiComponent3d. It points to the upper left element of the plane Iteration is done in backward element order.

Parameters

P	number of the plane axe (PLANE_ORIENTATION).
plane_coordinate	The constant coordinate
b	The box within the plane

Returns

begin reverse_iterator2d value

Precondition

P must be 0,1 or 2

b must be within the plane

Remarks

This iterator is compatible with BidirectionnalAccessIterator algorithms.

Example

slip::GenericMultiComponent3d<slip::color<double> > M(3,4,5);
slip::Box2d<int> b(1,1,3,3);
//Print the 2nd plane of M in the KI_PLANE direction within a box in reverse order
std::copy(M.plane_rupper_left(slip::KI_PLANE,2,b),M.plane_rbottom_right(
          slip::KI_PLANE,2,b),std::ostream_iterator<slip::color<double> >(std::cout," "));

const_reverse_iterator2d slip::GenericMultiComponent3d< slip::Vector3d< T > >::plane_rbottom_right ( PLANE_ORIENTATION  P, const size_type  plane_coordinate, const Box2d< int > &  b  ) const

inherited

Returns a read/write const reverse iterator that points to the first element of a box within a plane in the GenericMultiComponent3d. It points to the bottom right element of the plane Iteration is done in backward element order.

Parameters

P	number of the plane axe (PLANE_ORIENTATION).
plane_coordinate	The constant coordinate
b	The box within the plane

Returns

begin const_reverse_iterator2d value

Precondition

P must be 0,1 or 2

b must be within the plane

Remarks

This iterator is compatible with BidirectionnalAccessIterator algorithms.

Example

slip::GenericMultiComponent3d<slip::color<double> > const M(3,4,5);
slip::Box2d<int> b(1,1,3,3);
//Print the 2nd plane of M in the KI_PLANE direction within a box in reverse order
std::copy(M.plane_rupper_left(slip::KI_PLANE,2,b),M.plane_rbottom_right(
          slip::KI_PLANE,2,b),std::ostream_iterator<slip::color<double> >(std::cout," "));

reverse_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::plane_rend ( const size_type  slice )

inherited

Returns a read/write reverse iterator that points to one before the first element in the slice plane of the GenericMultiComponent3d. Iteration is done in reverse element order.

Parameters

slice

the slice coordinate of the plane

Returns

reverse end iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Example:

slip::GenericMultiComponent3d<slip::color<double> > A1(2,3,2);
slip::GenericMultiComponent3d<slip::color<double> > A2(2,3,2);
//copy the first plane (in slice direction) of A1 in A2 in reverse order
std::copy(A1.plane_rbegin(0),A1.plane_rend(0),A2.plane_begin(0));

const_reverse_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::plane_rend ( const size_type  slice ) const

inherited

Returns a read-only (constant) reverse iterator that points to one before the first element in the slice plane of the GenericMultiComponent3d. Iteration is done in reverse element order.

Parameters

slice

the slice coordinate of the plane

Returns

const reverse end iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Example:

slip::GenericMultiComponent3d<slip::color<double> > const A1(2,3,2);
slip::GenericMultiComponent3d<slip::color<double> > A2(2,3,2);
//copy the first plane (in slice direction) of A1 in A2 in reverse order
std::copy(A1.plane_rbegin(0),A1.plane_rend(0),A2.plane_begin(0));

reverse_component_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::plane_rend ( const std::size_t  component, const size_type  slice  )

inherited

Returns a read/write reverse iterator that points to one before the first element in the slice plane of the GenericMultiComponent3d. Iteration is done in reverse element order.

Parameters

component	The component number.
slice	the slice coordinate of the plane

Returns

reverse end component iterator value

const_reverse_component_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::plane_rend ( const std::size_t  component, const size_type  slice  ) const

inherited

Returns a read-only (constant) reverse iterator that points to one before the first element in the slice plane of the GenericMultiComponent3d. Iteration is done in reverse element order.

Parameters

component	The component number.
slice	the slice coordinate of the plane

Returns

const reverse end component iterator value

reverse_iterator2d slip::GenericMultiComponent3d< slip::Vector3d< T > >::plane_rupper_left ( PLANE_ORIENTATION  P, const size_type  plane_coordinate  )

inherited

Returns a read/write reverse_iterator that points to the bottom right element of the plane in the GenericMultiComponent3d. Iteration is done in backward element order.

Parameters

P	number of the plane axe (PLANE_ORIENTATION).
plane_coordinate	The constant coordinate

Returns

begin iterator2d value

Precondition

P must be 0,1 or 2

Remarks

This iterator is compatible with BidirectionnalAccessIterator algorithms.

Example:

slip::GenericMultiComponent3d<slip::color<double> > M(3,4,5);
//Print the 2nd plane of M in the KI_PLANE direction in reverse order
std::copy(M.plane_rupper_left(slip::KI_PLANE,2),M.plane_rbottom_right(
          slip::KI_PLANE,2),std::ostream_iterator<slip::color<double> >(std::cout," "));

const_reverse_iterator2d slip::GenericMultiComponent3d< slip::Vector3d< T > >::plane_rupper_left ( PLANE_ORIENTATION  P, const size_type  plane_coordinate  ) const

inherited

Returns a read/write const reverse iterator that points to the bottom right element of the plane in the GenericMultiComponent3d. Iteration is done in backward element order.

Parameters

P	number of the plane axe (PLANE_ORIENTATION).
plane_coordinate	The constant coordinate

Returns

begin const_iterator2d value

Precondition

P must be 0,1 or 2

Remarks

This iterator is compatible with BidirectionnalAccessIterator algorithms.

Example:

slip::GenericMultiComponent3d<slip::color<double> > const M(3,4,5);
//Print the 2nd plane of M in the KI_PLANE direction in reverse order
std::copy(M.plane_rupper_left(slip::KI_PLANE,2),M.plane_rbottom_right(
          slip::KI_PLANE,2),std::ostream_iterator<slip::color<double> >(std::cout," "));

reverse_iterator2d slip::GenericMultiComponent3d< slip::Vector3d< T > >::plane_rupper_left ( PLANE_ORIENTATION  P, const size_type  plane_coordinate, const Box2d< int > &  b  )

inherited

Returns a read/write reverse iterator that points to the last element of a box within a plane in the GenericMultiComponent3d. It points to the bottom right element of the box Iteration is done in backward element order.

Parameters

P	number of the plane axe (PLANE_ORIENTATION).
plane_coordinate	The constant coordinate
b	The box within the plane

Returns

begin reverse_iterator2d value

Precondition

P must be 0,1 or 2

b must be within the plane

Remarks

This iterator is compatible with BidirectionnalAccessIterator algorithms.

Example

slip::GenericMultiComponent3d<slip::color<double> > M(3,4,5);
slip::Box2d<int> b(1,1,3,3);
//Print the 2nd plane of M in the KI_PLANE direction within a box in reverse order
std::copy(M.plane_rupper_left(slip::KI_PLANE,2,b),M.plane_rbottom_right(
          slip::KI_PLANE,2,b),std::ostream_iterator<slip::color<double> >(std::cout," "));

const_reverse_iterator2d slip::GenericMultiComponent3d< slip::Vector3d< T > >::plane_rupper_left ( PLANE_ORIENTATION  P, const size_type  plane_coordinate, const Box2d< int > &  b  ) const

inherited

Returns a read/write const reverse iterator that points to the last element of a box within a plane in the GenericMultiComponent3d. It points to the bottom right element of the plane Iteration is done in backward element order.

Parameters

P	number of the plane axe (PLANE_ORIENTATION).
plane_coordinate	The constant coordinate
b	The box within the plane

Returns

begin const_reverse_iterator2d value

Precondition

P must be 0,1 or 2

b must be within the plane

Remarks

This iterator is compatible with BidirectionnalAccessIterator algorithms.

Example

slip::GenericMultiComponent3d<slip::color<double> > const M(3,4,5);
slip::Box2d<int> b(1,1,3,3);
//Print the 2nd plane of M in the KI_PLANE direction within a box in reverse order
std::copy(M.plane_rupper_left(slip::KI_PLANE,2,b),M.plane_rbottom_right(
          slip::KI_PLANE,2,b),std::ostream_iterator<slip::color<double> >(std::cout," "));

iterator2d slip::GenericMultiComponent3d< slip::Vector3d< T > >::plane_upper_left ( PLANE_ORIENTATION  P, const size_type  plane_coordinate  )

inherited

Returns a read/write iterator that points to the first element of the plane in the GenericMultiComponent3d. It points to the upper left element of the plane Iteration is done in ordinary element order.

Parameters

P	number of the plane axe (PLANE_ORIENTATION).
plane_coordinate	The constant coordinate

Returns

begin iterator2d value

Precondition

P must be 0,1 or 2

Remarks

This iterator is compatible with BidirectionnalAccessIterator algorithms.

Example:

slip::GenericMultiComponent3d<slip::color<double> > M(3,4,5);
//Print the 2nd plane of M in the KI_PLANE direction
std::copy(M.plane_upper_left(slip::KI_PLANE,2),M.plane_bottom_right(
          slip::KI_PLANE,2),std::ostream_iterator<slip::color<double> >(std::cout," "));

const_iterator2d slip::GenericMultiComponent3d< slip::Vector3d< T > >::plane_upper_left ( PLANE_ORIENTATION  P, const size_type  plane_coordinate  ) const

inherited

Returns a read/write const iterator that points to the first element of the plane in the GenericMultiComponent3d. It points to the upper left element of the plane Iteration is done in ordinary element order.

Parameters

P	number of the plane axe (PLANE_ORIENTATION).
plane_coordinate	The constant coordinate

Returns

begin const_iterator2d value

Precondition

P must be 0,1 or 2

Remarks

This iterator is compatible with BidirectionnalAccessIterator algorithms.

Example:

slip::GenericMultiComponent3d<slip::color<double> > const M(3,4,5);
//Print the 2nd plane of M in the KI_PLANE direction
std::copy(M.plane_upper_left(slip::KI_PLANE,2),M.plane_bottom_right(
          slip::KI_PLANE,2),std::ostream_iterator<slip::color<double> >(std::cout," "));

iterator2d slip::GenericMultiComponent3d< slip::Vector3d< T > >::plane_upper_left ( PLANE_ORIENTATION  P, const size_type  plane_coordinate, const Box2d< int > &  b  )

inherited

Returns a read/write iterator that points to the first element of a box within a plane in the GenericMultiComponent3d. It points to the upper left element of the box Iteration is done in ordinary element order.

Parameters

P	number of the plane axe (PLANE_ORIENTATION).
plane_coordinate	The constant coordinate
b	The box within the plane

Returns

begin iterator2d value

Precondition

P must be 0,1 or 2

b must be within the plane

Remarks

This iterator is compatible with BidirectionnalAccessIterator algorithms.

Example

slip::GenericMultiComponent3d<slip::color<double> > M(3,4,5);
slip::Box2d<int> b(1,1,3,3);
//Print the 2nd plane of M in the KI_PLANE direction within a box
std::copy(M.plane_upper_left(slip::KI_PLANE,2,b),M.plane_bottom_right(
          slip::KI_PLANE,2,b),std::ostream_iterator<slip::color<double> >(std::cout," "));

const_iterator2d slip::GenericMultiComponent3d< slip::Vector3d< T > >::plane_upper_left ( PLANE_ORIENTATION  P, const size_type  plane_coordinate, const Box2d< int > &  b  ) const

inherited

Returns a read/write const iterator that points to the first element of a box within a plane in the GenericMultiComponent3d. It points to the upper left element of the plane Iteration is done in ordinary element order.

Parameters

P	number of the plane axe (PLANE_ORIENTATION).
plane_coordinate	The constant coordinate
b	The box within the plane

Returns

begin const_iterator2d value

Precondition

P must be 0,1 or 2

b must be within the plane

Remarks

This iterator is compatible with BidirectionnalAccessIterator algorithms.

Example

slip::GenericMultiComponent3d<slip::color<double> > const M(3,4,5);
slip::Box2d<int> b(1,1,3,3);
//Print the 2nd plane of M in the KI_PLANE direction within a box
std::copy(M.plane_upper_left(slip::KI_PLANE,2,b),M.plane_bottom_right(
          slip::KI_PLANE,2,b),std::ostream_iterator<slip::color<double> >(std::cout," "));

reverse_iterator3d slip::GenericMultiComponent3d< slip::Vector3d< T > >::rback_bottom_right ( )

inherited

Returns a read/write reverse iterator3d. It points to past the front upper left element of the GenericMultiComponent3d. Iteration is done in the reverse order.

Returns

reverse iterator3d value

Remarks

This iterator is compatible with BidirectionalIterator algorithms.

Example

slip::GenericMultiComponent3d<slip::color<double> > M(3,4,5);
//Print M in reverse order
std::copy(M.rfront_upper_left(),M.rback_bottom_right(),
          std::ostream_iterator<slip::color<double> >(std::cout," "));

const_reverse_iterator3d slip::GenericMultiComponent3d< slip::Vector3d< T > >::rback_bottom_right ( ) const

inherited

Returns a read only reverse iterator3d. It points to past the front upper left element of the GenericMultiComponent3d. Iteration is done in the reverse order.

Returns

const reverse iterator3d value

Remarks

This iterator is compatible with BidirectionalIterator algorithms.

Example

slip::GenericMultiComponent3d<slip::color<double> > const M(3,4,5);
//Print M in reverse order
std::copy(M.rfront_upper_left(),M.rback_bottom_right(),
          std::ostream_iterator<slip::color<double> >(std::cout," "));

reverse_iterator3d slip::GenericMultiComponent3d< slip::Vector3d< T > >::rback_bottom_right ( const Box3d< int > &  box )

inherited

Returns a read/write reverse iterator3d. It points to one before the front upper left element of the Box3d box associated to the GenericMultiComponent3d.

Parameters

box	A Box3d defining the range of indices to iterate within the GenericMultiComponent3d.

Precondition

The box indices must be inside the range of the GenericMultiComponent3d ones.

Returns

reverse iterator3d value

Remarks

This iterator is compatible with BidirectionalIterator algorithms.

Example

slip::GenericMultiComponent3d<slip::color<double> > M(3,4,5);
slip::Box3d<int> b(1,1,1,2,2,3);
//Print M within a box in reverse order
std::copy(M.rfront_upper_left(b),M.rback_bottom_right(b),
          std::ostream_iterator<slip::color<double> >(std::cout," "));

const_reverse_iterator3d slip::GenericMultiComponent3d< slip::Vector3d< T > >::rback_bottom_right ( const Box3d< int > &  box ) const

inherited

Returns a read-only reverse iterator3d. It points to one before the front upper left element of the Box3d box associated to the GenericMultiComponent3d.

Parameters

box	A Box3d defining the range of indices to iterate within the GenericMultiComponent3d.

Precondition

The box indices must be inside the range of the GenericMultiComponent3d ones.

Returns

const reverse iterator3d value

Remarks

This iterator is compatible with BidirectionalIterator algorithms.

Example

slip::GenericMultiComponent3d<slip::color<double> > const M(3,4,5);
slip::Box3d<int> b(1,1,1,2,2,3);
//Print M within a box in reverse order
std::copy(M.rfront_upper_left(b),M.rback_bottom_right(b),
          std::ostream_iterator<slip::color<double> >(std::cout," "));

reverse_iterator3d_range slip::GenericMultiComponent3d< slip::Vector3d< T > >::rback_bottom_right ( const Range< int > &  slice_range, const Range< int > &  row_range, const Range< int > &  col_range  )

inherited

Returns a read/write reverse_iterator3d_range that points to one before the front upper left element of the ranges row_range and col_range associated to the GenericMultiComponent3d. Iteration is done in the reverse order.

Parameters

slice_range	The range of the slices.
row_range	The range of the rows.
col_range	The range of the columns.

Precondition

slice_range, row_range and col_range must be valid.

The ranges indices must be inside the ranges of the GenericMultiComponent3d ones.

Returns

reverse_iterator3d_range value

Remarks

This iterator is compatible with BidirectionalIterator algorithms.

Example

slip::GenericMultiComponent3d<slip::color<double> > M(3,4,5);
slip::Range<int> sr(0,2,2);
slip::Range<int> rr(0,3,2);
slip::Range<int> cr(0,4,2);
//Print M within a range in reverse order
std::copy(M.rfront_upper_left(sr,rr,cr),M.rback_bottom_right(sr,rr,cr),
          std::ostream_iterator<slip::color<double> >(std::cout," "));

const_reverse_iterator3d_range slip::GenericMultiComponent3d< slip::Vector3d< T > >::rback_bottom_right ( const Range< int > &  slice_range, const Range< int > &  row_range, const Range< int > &  col_range  ) const

inherited

Returns a read-only reverse_iterator3d_range that points to one before the front upper left element of the ranges row_range and col_range associated to the GenericMultiComponent3d.Iteration is done in the reverse order.

Parameters

slice_range	The range of the slices.
row_range	The range of the rows.
col_range	The range of the columns.

Precondition

slice_range, row_range and col_range must be valid.

The ranges indices must be inside the ranges of the GenericMultiComponent3d ones.

Returns

const_reverse_iterator3d_range value

Remarks

This iterator is compatible with BidirectionalIterator algorithms.

Example

slip::GenericMultiComponent3d<slip::color<double> > const M(3,4,5);
slip::Range<int> sr(0,2,2);
slip::Range<int> rr(0,3,2);
slip::Range<int> cr(0,4,2);
//Print M within a range in reverse order
std::copy(M.rfront_upper_left(sr,rr,cr),M.rback_bottom_right(sr,rr,cr),
          std::ostream_iterator<slip::color<double> >(std::cout," "));

reverse_component_iterator3d slip::GenericMultiComponent3d< slip::Vector3d< T > >::rback_bottom_right ( const std::size_t  component )

inherited

Returns a read/write reverse component iterator3d. It points to past the front upper left element of the GenericMultiComponent3d. Iteration is done in the reverse order.

Parameters

component

The component number.

Returns

reverse component iterator3d value

Remarks

This iterator is compatible with BidirectionalIterator algorithms.

const_reverse_component_iterator3d slip::GenericMultiComponent3d< slip::Vector3d< T > >::rback_bottom_right ( const std::size_t  component ) const

inherited

Returns a read only reverse component iterator3d. It points to past the front upper left element of the GenericMultiComponent3d. Iteration is done in the reverse order.

Parameters

component

The component number.

Returns

const reverse component iterator3d value

Remarks

This iterator is compatible with BidirectionalIterator algorithms.

reverse_component_iterator3d slip::GenericMultiComponent3d< slip::Vector3d< T > >::rback_bottom_right ( const std::size_t  component, const Box3d< int > &  box  )

inherited

Returns a read/write reverse component iterator3d. It points to one before the front upper left element of the Box3d box associated to the GenericMultiComponent3d.

Parameters

component	The component number.
box	A Box3d defining the range of indices to iterate within the GenericMultiComponent3d.

Precondition

The box indices must be inside the range of the GenericMultiComponent3d ones.

Returns

reverse iterator3d value

Remarks

This iterator is compatible with BidirectionalIterator algorithms.

const_reverse_component_iterator3d slip::GenericMultiComponent3d< slip::Vector3d< T > >::rback_bottom_right ( const std::size_t  component, const Box3d< int > &  box  ) const

inherited

Returns a read-only reverse component iterator3d. It points to one before the front upper left element of the Box3d box associated to the GenericMultiComponent3d.

Parameters

component	The component number.
box	A Box3d defining the range of indices to iterate within the GenericMultiComponent3d.

Precondition

The box indices must be inside the range of the GenericMultiComponent3d ones.

Returns

const reverse iterator3d value

Remarks

This iterator is compatible with BidirectionalIterator algorithms.

reverse_component_iterator3d_range slip::GenericMultiComponent3d< slip::Vector3d< T > >::rback_bottom_right ( const std::size_t  component, const Range< int > &  slice_range, const Range< int > &  row_range, const Range< int > &  col_range  )

inherited

Returns a read/write reverse_component_iterator3d_range. It points to one before the front upper left element of the ranges slice_range, row_range and col_range associated to the GenericMultiComponent3d.

Parameters

component	The component number.
slice_range	The range of the slices.
row_range	The range of the rows.
col_range	The range of the columns.

Precondition

slice_range, row_range and col_range must be valid.

The ranges indices must be inside the ranges of the GenericMultiComponent3d ones.

Returns

reverse iterator3d value

Remarks

This iterator is compatible with BidirectionalIterator algorithms.

const_reverse_component_iterator3d_range slip::GenericMultiComponent3d< slip::Vector3d< T > >::rback_bottom_right ( const std::size_t  component, const Range< int > &  slice_range, const Range< int > &  row_range, const Range< int > &  col_range  ) const

inherited

Returns a read/write reverse_const_component_iterator3d_range. It points to one before the front upper left element of the ranges slice_range, row_range and col_range associated to the GenericMultiComponent3d.

Parameters

component	The component number.
slice_range	The range of the slices.
row_range	The range of the rows.
col_range	The range of the columns.

Precondition

slice_range, row_range and col_range must be valid.

The ranges indices must be inside the ranges of the GenericMultiComponent3d ones.

Returns

reverse iterator3d value

Remarks

This iterator is compatible with BidirectionalIterator algorithms.

reverse_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::rbegin ( )

inherited

Returns a read/write reverse iterator that points to the last element in the GenericMultiComponent3d. Iteration is done in reverse element order.

Returns

reverse begin iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Example:

 slip::GenericMultiComponent3d<slip::color<double> > A1(10,9,5);
 slip::GenericMultiComponent3d<slip::color<double> > A2(10,9,5);
 slip::GenericMultiComponent3d<slip::color<double> > S(10,9,5);
//copy A1 in S
std::copy(A1.begin(),A1.end(),S.begin());

const_reverse_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::rbegin ( ) const

inherited

Returns a read-only (constant) reverse iterator that points to the last element in the GenericMultiComponent3d. Iteration is done in reverse element order.

Returns

const reverse begin iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Example:

 slip::GenericMultiComponent3d<slip::color<double> > const A1(10,9,5);
 slip::GenericMultiComponent3d<slip::color<double> > const A2(10,9,5);
 slip::GenericMultiComponent3d<slip::color<double> > S(10,9,5);
//copy A1 in S
std::copy(A1.begin(),A1.end(),S.begin());

reverse_component_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::rbegin ( const std::size_t  component )

inherited

Returns a read/write iterator that points to the first element in the GenericMultiComponent3d. Iteration is done in ordinary element order.

Parameters

component

The component number.

Returns

begin reverse_component_iterator value

const_reverse_component_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::rbegin ( const std::size_t  component ) const

inherited

Returns a read-only (constant) iterator that points to the first element in the GenericMultiComponent3d. Iteration is done in ordinary element order.

Parameters

component

The component number.

Returns

const begin reverse_component_iterator value

template<typename T >

void slip::DenseVector3dField3d< T >::read_tecplot ( const std::string &  file_path_name )

inline

Reads a DenseVector3dField3d from a tecplot file path name.

Parameters

file_path_name

The data format is the following:

TITLE= title

VARIABLES= X Y Z U V W

ZONE T= zone, K= dim1(), I= dim2(), J= dim3()

x y z Vx Vy Vz

Definition at line 1307 of file DenseVector3dField3d.hpp.

reverse_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::rend ( )

inherited

Returns a read/write reverse iterator that points to one before the first element in the GenericMultiComponent3d. Iteration is done in reverse element order.

Returns

reverse end iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Example:

 slip::GenericMultiComponent3d<slip::color<double> > A1(10,9,5);
 slip::GenericMultiComponent3d<slip::color<double> > A2(10,9,5);
 slip::GenericMultiComponent3d<slip::color<double> > S(10,9,5);
//copy A1 in S
std::copy(A1.begin(),A1.end(),S.begin());

const_reverse_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::rend ( ) const

inherited

Returns a read-only (constant) reverse iterator that points to one before the first element in the GenericMultiComponent3d. Iteration is done in reverse element order.

Returns

const reverse end iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Example:

 slip::GenericMultiComponent3d<slip::color<double> > const A1(10,9,5);
 slip::GenericMultiComponent3d<slip::color<double> > const A2(10,9,5);
 slip::GenericMultiComponent3d<slip::color<double> > S(10,9,5);
//copy A1 in S
std::copy(A1.begin(),A1.end(),S.begin());

reverse_component_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::rend ( const std::size_t  component )

inherited

Returns a read/write iterator that points one past the last element in the GenericMultiComponent3d. Iteration is done in ordinary element order.

Parameters

component

The component number.

Returns

end reverse_component_iterator value

const_reverse_component_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::rend ( const std::size_t  component ) const

inherited

Returns a read-only (constant) iterator that points one past the last element in the GenericMultiComponent3d. Iteration is done in ordinary element order.

Parameters

component

The component number.

Returns

const end reverse_component_iterator value

void slip::GenericMultiComponent3d< slip::Vector3d< T > >::resize ( const size_type  slices, const size_type  rows, const size_type  cols, const slip::Vector3d< T > &  val = Block()  )

inherited

Resizes a GenericMultiComponent3d.

Parameters

slices	first dimension of the GenericMultiComponent3d
rows	second dimension of the GenericMultiComponent3d
cols	third dimension of the GenericMultiComponent3d
val	new value for all the elements

reverse_iterator3d slip::GenericMultiComponent3d< slip::Vector3d< T > >::rfront_upper_left ( )

inherited

Returns a read/write reverse iterator3d. It points to the back bottom right element of the GenericMultiComponent3d. Iteration is done within the GenericMultiComponent3d in the reverse order.

Returns

reverse_iterator3d value

Remarks

This iterator is compatible with BidirectionalIterator algorithms.

Example

slip::GenericMultiComponent3d<slip::color<double> > M(3,4,5);
//Print M in reverse order
std::copy(M.rfront_upper_left(),M.rback_bottom_right(),
          std::ostream_iterator<slip::color<double> >(std::cout," "));

const_reverse_iterator3d slip::GenericMultiComponent3d< slip::Vector3d< T > >::rfront_upper_left ( ) const

inherited

Returns a read only reverse iterator3d that points. It points to the back bottom right element of the GenericMultiComponent3d. Iteration is done within the GenericMultiComponent3d in the reverse order.

Returns

const_reverse_iterator3d value

Remarks

This iterator is compatible with BidirectionalIterator algorithms.

Example

slip::GenericMultiComponent3d<slip::color<double> > const M(3,4,5);
//Print M in reverse order
std::copy(M.rfront_upper_left(),M.rback_bottom_right(),
          std::ostream_iterator<slip::color<double> >(std::cout," "));

reverse_iterator3d slip::GenericMultiComponent3d< slip::Vector3d< T > >::rfront_upper_left ( const Box3d< int > &  box )

inherited

Returns a read/write reverse iterator3d. It points to the back bottom right element of the Box3d associated to the GenericMultiComponent3d. Iteration is done in the reverse order.

Parameters

box	a Box3d defining the range of indices to iterate within the GenericMultiComponent3d.

Precondition

The box indices must be inside the range of the GenericMultiComponent3d ones.

Returns

reverse iterator3d value

Remarks

This iterator is compatible with BidirectionalIterator algorithms.

Example

slip::GenericMultiComponent3d<slip::color<double> > M(3,4,5);
slip::Box3d<int> b(1,1,1,2,2,3);
//Print M within a box in reverse order
std::copy(M.rfront_upper_left(b),M.rback_bottom_right(b),
          std::ostream_iterator<slip::color<double> >(std::cout," "));

const_reverse_iterator3d slip::GenericMultiComponent3d< slip::Vector3d< T > >::rfront_upper_left ( const Box3d< int > &  box ) const

inherited

Returns a read only reverse iterator3d. It points to the back bottom right element of the Box3d box associated to the GenericMultiComponent3d. Iteration is done in the reverse order.

Parameters

box	A Box3d defining the range of indices to iterate within the GenericMultiComponent3d.

Precondition

The box indices must be inside the range of the GenericMultiComponent3d ones.

Returns

const reverse iterator3d value

Remarks

This iterator is compatible with BidirectionalIterator algorithms.

Example

slip::GenericMultiComponent3d<slip::color<double> > const M(3,4,5);
slip::Box3d<int> b(1,1,1,2,2,3);
//Print M within a box in reverse order
std::copy(M.rfront_upper_left(b),M.rback_bottom_right(b),
          std::ostream_iterator<slip::color<double> >(std::cout," "));

reverse_iterator3d_range slip::GenericMultiComponent3d< slip::Vector3d< T > >::rfront_upper_left ( const Range< int > &  slice_range, const Range< int > &  row_range, const Range< int > &  col_range  )

inherited

Returns a read/write reverse_iterator3d_range that points to the past the back bottom right element of the ranges row_range and col_range associated to the GenericMultiComponent3d. Iteration is done in the reverse order.

Parameters

slice_range	The range of the slices.
row_range	The range of the rows.
col_range	The range of the columns.

Precondition

slice_range, row_range and col_range must be valid.

The ranges indices must be inside the ranges of the GenericMultiComponent3d ones.

Returns

reverse_iterator3d_range value

Remarks

This iterator is compatible with BidirectionalIterator algorithms.

Example

slip::GenericMultiComponent3d<slip::color<double> > M(3,4,5);
slip::Range<int> sr(0,2,2);
slip::Range<int> rr(0,3,2);
slip::Range<int> cr(0,4,2);
//Print M within a range in reverse order
std::copy(M.rfront_upper_left(sr,rr,cr),M.rback_bottom_right(sr,rr,cr),
          std::ostream_iterator<slip::color<double> >(std::cout," "));

const_reverse_iterator3d_range slip::GenericMultiComponent3d< slip::Vector3d< T > >::rfront_upper_left ( const Range< int > &  slice_range, const Range< int > &  row_range, const Range< int > &  col_range  ) const

inherited

Returns a read-only reverse_iterator3d_range that points to the past the back bottom right element of the ranges row_range and col_range associated to the GenericMultiComponent3d. Iteration is done in the reverse order.

Parameters

slice_range	The range of the slices.
row_range	The range of the rows.
col_range	The range of the columns.

Precondition

slice_range, row_range and col_range must be valid.

The ranges indices must be inside the ranges of the GenericMultiComponent3d ones.

Returns

const_reverse_iterator3d_range value

Remarks

This iterator is compatible with BidirectionalIterator algorithms.

Example

slip::GenericMultiComponent3d<slip::color<double> > const M(3,4,5);
slip::Range<int> sr(0,2,2);
slip::Range<int> rr(0,3,2);
slip::Range<int> cr(0,4,2);
//Print M within a range in reverse order
std::copy(M.rfront_upper_left(sr,rr,cr),M.rback_bottom_right(sr,rr,cr),
          std::ostream_iterator<slip::color<double> >(std::cout," "));

reverse_component_iterator3d slip::GenericMultiComponent3d< slip::Vector3d< T > >::rfront_upper_left ( const std::size_t  component )

inherited

Returns a read/write reverse component iterator3d. It points to the back bottom right element of the GenericMultiComponent3d. Iteration is done within the GenericMultiComponent3d in the reverse order.

Parameters

component

The component number.

Returns

reverse_component_iterator3d value

Remarks

This iterator is compatible with BidirectionalIterator algorithms.

const_reverse_component_iterator3d slip::GenericMultiComponent3d< slip::Vector3d< T > >::rfront_upper_left ( const std::size_t  component ) const

inherited

Returns a read only reverse component iterator3d that points. It points to the back bottom right element of the GenericMultiComponent3d. Iteration is done within the GenericMultiComponent3d in the reverse order.

Parameters

component

The component number.

Returns

const_reverse_component_iterator3d value

Remarks

This iterator is compatible with BidirectionalIterator algorithms.

reverse_component_iterator3d slip::GenericMultiComponent3d< slip::Vector3d< T > >::rfront_upper_left ( const std::size_t  component, const Box3d< int > &  box  )

inherited

Returns a read/write reverse component iterator3d. It points to the back bottom right element of the Box3d associated to the GenericMultiComponent3d. Iteration is done in the reverse order.

Parameters

component	The component number.
box	a Box3d defining the range of indices to iterate within the GenericMultiComponent3d.

Precondition

The box indices must be inside the range of the GenericMultiComponent3d ones.

Returns

reverse iterator3d value

Remarks

This iterator is compatible with BidirectionalIterator algorithms.

const_reverse_component_iterator3d slip::GenericMultiComponent3d< slip::Vector3d< T > >::rfront_upper_left ( const std::size_t  component, const Box3d< int > &  box  ) const

inherited

Returns a read only reverse component iterator3d. It points to the back bottom right element of the Box3d box associated to the GenericMultiComponent3d. Iteration is done in the reverse order.

Parameters

component	The component number.
box	A Box3d defining the range of indices to iterate within the GenericMultiComponent3d.

Precondition

The box indices must be inside the range of the GenericMultiComponent3d ones.

Returns

const reverse iterator3d value

Remarks

This iterator is compatible with BidirectionalIterator algorithms.

reverse_component_iterator3d_range slip::GenericMultiComponent3d< slip::Vector3d< T > >::rfront_upper_left ( const std::size_t  component, const Range< int > &  slice_range, const Range< int > &  row_range, const Range< int > &  col_range  )

inherited

Returns a read/write reverse_component_iterator3d_range. It points to the back bottom right element of the ranges slice_range, row_range and col_range associated to the GenericMultiComponent3d.

Parameters

component	The component number.
slice_range	The range of the slices.
row_range	The range of the rows.
col_range	The range of the columns.

Precondition

slice_range, row_range and col_range must be valid.

The ranges indices must be inside the ranges of the GenericMultiComponent3d ones.

Returns

reverse iterator3d value

Remarks

This iterator is compatible with BidirectionalIterator algorithms.

const_reverse_component_iterator3d_range slip::GenericMultiComponent3d< slip::Vector3d< T > >::rfront_upper_left ( const std::size_t  component, const Range< int > &  slice_range, const Range< int > &  row_range, const Range< int > &  col_range  ) const

inherited

Returns a read/write reverse_const_component_iterator3d_range. It points to the back bottom right element of the ranges slice_range, row_range and col_range associated to the GenericMultiComponent3d.

Parameters

component	The component number.
slice_range	The range of the slices.
row_range	The range of the rows.
col_range	The range of the columns.

Precondition

slice_range, row_range and col_range must be valid.

The ranges indices must be inside the ranges of the GenericMultiComponent3d ones.

Returns

reverse iterator3d value

Remarks

This iterator is compatible with BidirectionalIterator algorithms.

row_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::row_begin ( const size_type  slice, const size_type  row  )

inherited

Returns a read/write iterator that points to the first element of the row row of the slice slice in the GenericMultiComponent3d. Iteration is done in ordinary element order.

Parameters

slice	The index of the slice.
row	The index of the row.

Returns

begin row_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

const_row_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::row_begin ( const size_type  slice, const size_type  row  ) const

inherited

Returns a read_only iterator that points to the first element of the row row of the slice slice in the GenericMultiComponent3d. Iteration is done in ordinary element order.

Parameters

slice	The index of the slice.
row	The index of the row.

Returns

begin const_row_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

row_range_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::row_begin ( const size_type  slice, const size_type  row, const slip::Range< int > &  range  )

inherited

Returns a read/write iterator that points to the first element of the Range range of the row row in the GenericMultiComponent3d. Iteration is done in ordinary element order according to the Range.

Parameters

slice	The index of the slice.
row	The index of the row to iterate.
range	Range of the row to iterate.

Returns

begin row_range_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Precondition

row must be compatible with the range of the GenericMultiComponent3d.

The range must be inside the whole range of the GenericMultiComponent3d.

 slip::GenericMultiComponent3d<slip::color<double> > A1(8,8,8);
 slip::GenericMultiComponent3d<slip::color<double> > A2(8,4,5);
 slip::Range<int> range(0,A1.dim3()-1,2);
//copy the the elements of the row 0 of the slice 0 of A1 iterated according to the
//range in the row 1 of the slice 1 of A2
std::copy(A1.row_begin(0,0,range),A1.row_end(0,0,range),A2.row_begin(1,1));

const_row_range_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::row_begin ( const size_type  slice, const size_type  row, const slip::Range< int > &  range  ) const

inherited

Returns a read-only iterator that points to the first element of the Range range of the row row in the GenericMultiComponent3d. Iteration is done in ordinary element order according to the Range.

Parameters

slice	The index of the slice.
row	The index of the row to iterate.
range	Range of the row to iterate.

Returns

begin const_row_range_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Precondition

row must be compatible with the range of the GenericMultiComponent3d.

The range must be inside the whole range of the GenericMultiComponent3d.

 slip::GenericMultiComponent3d<slip::color<double> > const A1(8,8,8);
 slip::GenericMultiComponent3d<slip::color<double> > A2(8,4,5);
 slip::Range<int> range(0,A1.dim3()-1,2);
//copy the the elements of the row 0 of the slice 0 of A1 iterated according to the
//range in the row 1 of the slice 1 of A2
std::copy(A1.row_begin(0,0,range),A1.row_end(0,0,range),A2.row_begin(1,1));

component_row_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::row_begin ( const std::size_t  component, const size_type  slice, const size_type  row  )

inherited

Returns a read/write iterator that points to the first element of the row row of the slice slice in the GenericMultiComponent3d. Iteration is done in ordinary element order.

Parameters

component	The component number.
slice	The index of the slice.
row	The index of the row.

Returns

begin row_iterator value

const_component_row_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::row_begin ( const std::size_t  component, const size_type  slice, const size_type  row  ) const

inherited

Returns a read_only iterator that points to the first element of the row row of the slice slice in the GenericMultiComponent3d. Iteration is done in ordinary element order.

Parameters

component	The component number.
slice	The index of the slice.
row	The index of the row.

Returns

begin const_row_iterator value

component_row_range_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::row_begin ( const std::size_t  component, const size_type  slice, const size_type  row, const slip::Range< int > &  range  )

inherited

Returns a read/write iterator that points to the first element of the Range range of the row row in the GenericMultiComponent3d. Iteration is done in ordinary element order according to the Range.

Parameters

component	The component number.
slice	The index of the slice.
row	The index of the row to iterate.
range	Range of the row to iterate.

Returns

begin row_range_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Precondition

row must be compatible with the range of the GenericMultiComponent3d.

The range must be inside the whole range of the GenericMultiComponent3d.

 slip::Array3d<double> A1(8,8,8);
 slip::Array3d<double> A2(8,4,5);
 slip::Range<int> range(0,A1.dim2()-1,2);
//copy the the elements of the row 0 of A1 iterated according to the
//range in the row 1 of A2
std::copy(A1.row_begin(0,range),A1.row_end(0,range),A2.row_begin(1));

const_component_row_range_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::row_begin ( const std::size_t  component, const size_type  slice, const size_type  row, const slip::Range< int > &  range  ) const

inherited

Returns a read-only iterator that points to the first element of the Range range of the row row in the GenericMultiComponent3d. Iteration is done in ordinary element order according to the Range.

Parameters

component	The component number.
slice	The index of the slice.
row	The index of the row to iterate.
range	Range of the row to iterate.

Returns

begin const_row_range_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Precondition

row must be compatible with the range of the GenericMultiComponent3d.

The range must be inside the whole range of the GenericMultiComponent3d.

 slip::Array3d<double> A1(8,8,8);
 slip::Array3d<double> A2(8,4,5);
 slip::Range<int> range(0,A1.dim2()-1,2);
//copy the the elements of the row 0 of A1 iterated according to the
//range in the row 1 of A2
std::copy(A1.row_begin(0,range),A1.row_end(0,range),A2.row_begin(1));

row_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::row_end ( const size_type  slice, const size_type  row  )

inherited

Returns a read/write iterator that points to the past-the-end element of the row row of the slice slice in the GenericMultiComponent3d. Iteration is done in ordinary element order.

Parameters

slice	The index of the slice.
row	The index of the row.

Returns

end row_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

const_row_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::row_end ( const size_type  slice, const size_type  row  ) const

inherited

Returns a read_only iterator that points to the past-the-end element of the row row of the slice slice in the GenericMultiComponent3d. Iteration is done in ordinary element order.

Parameters

slice	The index of the slice.
row	The index of the row.

Returns

end const_row_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

row_range_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::row_end ( const size_type  slice, const size_type  row, const slip::Range< int > &  range  )

inherited

Returns a read/write iterator that points one past the end element of the Range range of the row row in the GenericMultiComponent3d. Iteration is done in ordinary element order according to the Range.

Parameters

slice	The index of the slice.
row	The index of the row to iterate.
range	Range of the row to iterate.

Returns

end row_range_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Precondition

row must be compatible with the range of the GenericMultiComponent3d.

The range must be inside the whole range of the GenericMultiComponent3d.

 slip::GenericMultiComponent3d<slip::color<double> > A1(8,8,8);
 slip::GenericMultiComponent3d<slip::color<double> > A2(8,4,5);
 slip::Range<int> range(0,A1.dim3()-1,2);
//copy the the elements of the row 0 of the slice 0 of A1 iterated according to the
//range in the row 1 of the slice 1 of A2
std::copy(A1.row_begin(0,0,range),A1.row_end(0,0,range),A2.row_begin(1,1));

const_row_range_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::row_end ( const size_type  slice, const size_type  row, const slip::Range< int > &  range  ) const

inherited

Returns a read_only iterator that points one past the last element of the Range range of the row row in the GenericMultiComponent3d. Iteration is done in ordinary element order according to the Range.

Parameters

slice	The index of the slice.
row	Row to iterate.
range	Range of the row to iterate

Returns

begin const_row_range_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Precondition

row must be compatible with the range of the GenericMultiComponent3d.

The range must be inside the whole range of the GenericMultiComponent3d.

 slip::GenericMultiComponent3d<slip::color<double> > const A1(8,8,8);
 slip::GenericMultiComponent3d<slip::color<double> > A2(8,4,5);
 slip::Range<int> range(0,A1.dim3()-1,2);
//copy the the elements of the row 0 of the slice 0 of A1 iterated according to the
//range in the row 1 of the slice 1 of A2
std::copy(A1.row_begin(0,0,range),A1.row_end(0,0,range),A2.row_begin(1,1));

component_row_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::row_end ( const std::size_t  component, const size_type  slice, const size_type  row  )

inherited

Returns a read/write iterator that points to the past-the-end element of the row row of the slice slice in the GenericMultiComponent3d. Iteration is done in ordinary element order.

Parameters

component	The component number.
slice	The index of the slice.
row	The index of the row.

Returns

end row_iterator value

const_component_row_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::row_end ( const std::size_t  component, const size_type  slice, const size_type  row  ) const

inherited

Returns a read_only iterator that points to the past-the-end element of the row row of the slice slice in the GenericMultiComponent3d. Iteration is done in ordinary element order.

Parameters

component	The component number.
slice	The index of the slice.
row	The index of the row.
component	The component number.

Returns

end const_row_iterator value

component_row_range_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::row_end ( const std::size_t  component, const size_type  slice, const size_type  row, const slip::Range< int > &  range  )

inherited

Returns a read/write iterator that points one past the end element of the Range range of the row row in the GenericMultiComponent3d. Iteration is done in ordinary element order according to the Range.

Parameters

component	The component number.
slice	The index of the slice.
row	The index of the row to iterate.
range	Range of the row to iterate.

Returns

end row_range_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Precondition

row must be compatible with the range of the GenericMultiComponent3d.

The range must be inside the whole range of the GenericMultiComponent3d.

 slip::Array3d<double> A1(8,8,8);
 slip::Array3d<double> A2(8,4,5);
 slip::Range<int> range(0,A1.dim2()-1,2);
//copy the the elements of the row 0 of A1 iterated according to the
//range in the row 1 of A2
std::copy(A1.row_begin(0,range),A1.row_end(0,range),A2.row_begin(1));

const_component_row_range_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::row_end ( const std::size_t  component, const size_type  slice, const size_type  row, const slip::Range< int > &  range  ) const

inherited

Returns a read_only iterator that points one past the last element of the Range range of the row row in the GenericMultiComponent3d. Iteration is done in ordinary element order according to the Range.

Parameters

component	The component number.
slice	The index of the slice.
row	Row to iterate.
range	Range of the row to iterate

Returns

begin const_row_range_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Precondition

row must be compatible with the range of the GenericMultiComponent3d.

The range must be inside the whole range of the GenericMultiComponent3d.

 slip::Array3d<double> A1(8,8,8);
 slip::Array3d<double> A2(8,4,5);
 slip::Range<int> range(0,A1.dim2()-1,2);
//copy the the elements of the row 0 of A1 iterated according to the
//range in the row 1 of A2
std::copy(A1.row_begin(0,range),A1.row_end(0,range),A2.row_begin(1));

reverse_row_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::row_rbegin ( const size_type  slice, const size_type  row  )

inherited

Returns a read/write reverse iterator that points to the last element of the row row of the slice slice in the GenericMultiComponent3d. Iteration is done in reverse element order.

Parameters

slice	The index of the slice.
row	The index of the row.

Returns

begin reverse_row_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

const_reverse_row_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::row_rbegin ( const size_type  slice, const size_type  row  ) const

inherited

Returns a read_only reverse iterator that points to the last element of the row row of the slice slice in the GenericMultiComponent3d. Iteration is done in reverse element order.

Parameters

slice	The index of the slice.
row	The index of the row.

Returns

begin const_reverse_row_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

reverse_row_range_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::row_rbegin ( const size_type  slice, const size_type  row, const slip::Range< int > &  range  )

inherited

Returns a read-write iterator that points to the last element of the Range range of the row of a slice row and slice in the GenericMultiComponent3d. Iteration is done in the reverse element order according to the Range.

Parameters

slice	The index of the slice.
row	The index of the row to iterate.
range	Range of the row to iterate.

Returns

reverse_row_range_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Precondition

row must be compatible with the range of the GenericMultiComponent3d.

The range must be inside the whole range of the GenericMultiComponent3d.

const_reverse_row_range_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::row_rbegin ( const size_type  slice, const size_type  row, const slip::Range< int > &  range  ) const

inherited

Returns a read-only iterator that points to the last element of the Range range of the row of a slice row in the GenericMultiComponent3d. Iteration is done in the reverse element order according to the Range.

Parameters

slice	The index of the slice.
row	The index of the row to iterate.
range	Range of the row to iterate

Returns

begin const_reverse_row_range_iterator value

Precondition

row must be compatible with the range of the GenericMultiComponent3d.

The range must be inside the whole range of the GenericMultiComponent3d.

reverse_component_row_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::row_rbegin ( const std::size_t  component, const size_type  slice, const size_type  row  )

inherited

Returns a read/write reverse iterator that points to the last element of the row row of the slice slice in the GenericMultiComponent3d. Iteration is done in reverse element order.

Parameters

component	The component number.
slice	The index of the slice.
row	The index of the row.

Returns

begin reverse_row_iterator value

const_reverse_component_row_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::row_rbegin ( const std::size_t  component, const size_type  slice, const size_type  row  ) const

inherited

Returns a read_only reverse iterator that points to the last element of the row row of the slice slice in the GenericMultiComponent3d. Iteration is done in reverse element order.

Parameters

component	The component number.
slice	The index of the slice.
row	The index of the row.

Returns

begin const_reverse_row_iterator value

reverse_component_row_range_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::row_rbegin ( const std::size_t  component, const size_type  slice, const size_type  row, const slip::Range< int > &  range  )

inherited

Returns a read-write iterator that points to the last element of the Range range of the row of a slice row and slice in the GenericMultiComponent3d. Iteration is done in the reverse element order according to the Range.

Parameters

component	The component number.
slice	The index of the slice.
row	The index of the row to iterate.
range	Range of the row to iterate.

Returns

reverse_row_range_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Precondition

row must be compatible with the range of the GenericMultiComponent3d.

The range must be inside the whole range of the GenericMultiComponent3d.

const_reverse_component_row_range_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::row_rbegin ( const std::size_t  component, const size_type  slice, const size_type  row, const slip::Range< int > &  range  ) const

inherited

Returns a read-only iterator that points to the last element of the Range range of the row of a slice row in the GenericMultiComponent3d. Iteration is done in the reverse element order according to the Range.

Parameters

component	The component number.
slice	The index of the slice.
row	The index of the row to iterate.
range	Range of the row to iterate

Returns

begin const_reverse_row_range_iterator value

Precondition

row must be compatible with the range of the GenericMultiComponent3d.

The range must be inside the whole range of the GenericMultiComponent3d.

reverse_row_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::row_rend ( const size_type  slice, const size_type  row  )

inherited

Returns a read/write reverse iterator that points to the first element of the row row of the slice slice in the GenericMultiComponent3d. Iteration is done in reverse element order.

Parameters

slice	The index of the slice.
row	The index of the row.

Returns

end reverse_row_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

const_reverse_row_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::row_rend ( const size_type  slice, const size_type  row  ) const

inherited

Returns a read_only reverse iterator that points to the first element of the row row of the slice slice in the GenericMultiComponent3d. Iteration is done in reverse element order.

Parameters

slice	The index of the slice.
row	The index of the row.

Returns

end const_reverse_row_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

reverse_row_range_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::row_rend ( const size_type  slice, const size_type  row, const slip::Range< int > &  range  )

inherited

Returns a read-write iterator that points one before the first element of the Range range of the row of a slice row in the GenericMultiComponent3d. Iteration is done in the reverse element order according to the Range.

Parameters

slice	The index of the slice.
row	The index of the row to iterate.
range	Range of the row to iterate.

Returns

reverse_row_range_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Precondition

row must be compatible with the range of the GenericMultiComponent3d.

The range must be inside the whole range of the GenericMultiComponent3d.

const_reverse_row_range_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::row_rend ( const size_type  slice, const size_type  row, const slip::Range< int > &  range  ) const

inherited

Returns a read-only iterator that points one before the first element of the Range range of the row of a slice row in the GenericMultiComponent3d. Iteration is done in the reverse element order according to the Range.

Parameters

slice	The index of the slice.
row	The index of the row to iterate.
range	Range of the row to iterate

Returns

const_reverse_row_range_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Precondition

row must be compatible with the range of the GenericMultiComponent3d.

The range must be inside the whole range of the GenericMultiComponent3d.

reverse_component_row_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::row_rend ( const std::size_t  component, const size_type  slice, const size_type  row  )

inherited

Returns a read/write reverse iterator that points to the first element of the row row of the slice slice in the GenericMultiComponent3d. Iteration is done in reverse element order.

Parameters

component	The component number.
slice	The index of the slice.
row	The index of the row.

Returns

end reverse_row_iterator value

const_reverse_component_row_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::row_rend ( const std::size_t  component, const size_type  slice, const size_type  row  ) const

inherited

Returns a read_only reverse iterator that points to the first element of the row row of the slice slice in the GenericMultiComponent3d. Iteration is done in reverse element order.

Parameters

component	The component number.
slice	The index of the slice.
row	The index of the row.

Returns

end const_reverse_row_iterator value

reverse_component_row_range_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::row_rend ( const std::size_t  component, const size_type  slice, const size_type  row, const slip::Range< int > &  range  )

inherited

Returns a read-write iterator that points one before the first element of the Range range of the row of a slice row in the GenericMultiComponent3d. Iteration is done in the reverse element order according to the Range.

Parameters

component	The component number.
slice	The index of the slice.
row	The index of the row to iterate.
range	Range of the row to iterate.

Returns

reverse_row_range_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Precondition

row must be compatible with the range of the GenericMultiComponent3d.

The range must be inside the whole range of the GenericMultiComponent3d.

const_reverse_component_row_range_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::row_rend ( const std::size_t  component, const size_type  slice, const size_type  row, const slip::Range< int > &  range  ) const

inherited

Returns a read-only iterator that points one before the first element of the Range range of the row of a slice row in the GenericMultiComponent3d. Iteration is done in the reverse element order according to the Range.

Parameters

component	The component number.
slice	The index of the slice.
row	The index of the row to iterate.
range	Range of the row to iterate

Returns

const_reverse_row_range_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Precondition

row must be compatible with the range of the GenericMultiComponent3d.

The range must be inside the whole range of the GenericMultiComponent3d.

size_type slip::GenericMultiComponent3d< slip::Vector3d< T > >::rows ( ) const

inherited

Returns the number of rows (first dimension size) in the GenericMultiComponent3d.

size_type slip::GenericMultiComponent3d< slip::Vector3d< T > >::size ( ) const

inherited

Returns the number of elements in the GenericMultiComponent3d.

slice_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::slice_begin ( const size_type  row, const size_type  col  )

inherited

Returns a read/write iterator that points to the first element of the line (row,col) threw the slices in the GenericMultiComponent3d. Iteration is done in ordinary element order (increasing slice number).

Parameters

row	row coordinate of the line
col	col coordinate of the line

Returns

slice_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Example:

slip::GenericMultiComponent3d<slip::color<double> > A1(10,9,5);
slip::GenericMultiComponent3d<slip::color<double> > A2(10,9,5);
slip::GenericMultiComponent3d<slip::color<double> > S(10,9,5);
//copy A1 in S
std::copy(A1.begin(),A1.end(),S.begin());

const_slice_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::slice_begin ( const size_type  row, const size_type  col  ) const

inherited

Returns a read-only (constant) iterator that points to the first element of the line (row,col) threw the slices in the GenericMultiComponent3d. Iteration is done in ordinary element order (increasing slice number).

Parameters

row	row coordinate of the line
col	col coordinate of the line

Returns

const_slice_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Example:

slip::GenericMultiComponent3d<slip::color<double> > const A1(10,9,5);
slip::GenericMultiComponent3d<slip::color<double> > const A2(10,9,5);
slip::GenericMultiComponent3d<slip::color<double> > S(10,9,5);
//copy A1 in S
std::copy(A1.begin(),A1.end(),S.begin());

slice_range_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::slice_begin ( const size_type  row, const size_type  col, const slip::Range< int > &  range  )

inherited

Returns a read/write iterator that points to the first element of the Range range of the of the line (row,col) threw the slices in the GenericMultiComponent3d. Iteration is done in ordinary element order according to the Range.

Parameters

row	row coordinate of the line
col	col coordinate of the line
range	Range of the line to iterate.

Returns

begin slice_range_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Precondition

the range must be compatible with the slice dimensions

The range must be inside the whole range of the GenericMultiComponent3d.

Example:

 slip::GenericMultiComponent3d<slip::color<double> > A1(8,8,8);
 slip::GenericMultiComponent3d<slip::color<double> > A2(4,8,8);
 slip::Range<int> range(0,A1.dim1()-1,2);
//copy the the elements of the line (0,0) of A1 iterated according to the
//range in the line (1,1) of A2
std::copy(A1.slice_begin(0,0,range),A1.slice_end(0,0,range),A2.slice_begin(1,1));

const_slice_range_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::slice_begin ( const size_type  row, const size_type  col, const slip::Range< int > &  range  ) const

inherited

Returns a read only (constant) iterator that points to the first element of the Range range of the of the line (row,col) threw the slices in the GenericMultiComponent3d. Iteration is done in ordinary element order according to the Range.

Parameters

row	row coordinate of the line
col	col coordinate of the line
range	Range of the line to iterate.

Returns

begin const_slice_range_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Precondition

the range must be compatible with the slice dimensions

The range must be inside the whole range of the GenericMultiComponent3d.

Example:

 slip::GenericMultiComponent3d<slip::color<double> > const A1(8,8,8);
 slip::GenericMultiComponent3d<slip::color<double> > const A2(4,8,8);
 slip::Range<int> range(0,A1.dim1()-1,2);
//copy the the elements of the line (0,0) of A1 iterated according to the
//range in the line (1,1) of A2
std::copy(A1.slice_begin(0,0,range),A1.slice_end(0,0,range),A2.slice_begin(1,1));

component_slice_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::slice_begin ( const std::size_t  component, const size_type  row, const size_type  col  )

inherited

Returns a read/write iterator that points to the first element of the line (row,col) threw the slices in the GenericMultiComponent3d. Iteration is done in ordinary element order (increasing slice number).

Parameters

component	The component number.
row	row coordinate of the line
col	col coordinate of the line

Returns

slice_iterator value

const_component_slice_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::slice_begin ( const std::size_t  component, const size_type  row, const size_type  col  ) const

inherited

Returns a read-only (constant) iterator that points to the first element of the line (row,col) threw the slices in the GenericMultiComponent3d. Iteration is done in ordinary element order (increasing slice number).

Parameters

component	The component number.
row	row coordinate of the line
col	col coordinate of the line

Returns

const_slice_iterator value

component_slice_range_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::slice_begin ( const std::size_t  component, const size_type  row, const size_type  col, const slip::Range< int > &  range  )

inherited

Returns a read/write iterator that points to the first element of the Range range of the of the line (row,col) threw the slices in the GenericMultiComponent3d. Iteration is done in ordinary element order according to the Range.

Parameters

component	The component number.
row	row coordinate of the line
col	col coordinate of the line
range	Range of the line to iterate.

Returns

begin slice_range_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Precondition

the range must be compatible with the slice dimensions

The range must be inside the whole range of the GenericMultiComponent3d.

 slip::Array3d<double> A1(8,8,8);
 slip::Array3d<double> A2(4,8,8);
 slip::Range<int> range(0,A1.dim1()-1,2);
//copy the the elements of the line (0,0) of A1 iterated according to the
//range in the line (1,1) of A2
std::copy(A1.slice_begin(0,0,range),A1.slice_end(0,0,range),A2.slice_begin(1,1));

const_component_slice_range_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::slice_begin ( const std::size_t  component, const size_type  row, const size_type  col, const slip::Range< int > &  range  ) const

inherited

Returns a read only (constant) iterator that points to the first element of the Range range of the of the line (row,col) threw the slices in the GenericMultiComponent3d. Iteration is done in ordinary element order according to the Range.

Parameters

component	The component number.
row	row coordinate of the line
col	col coordinate of the line
range	Range of the line to iterate.

Returns

begin const_slice_range_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Precondition

the range must be compatible with the slice dimensions

The range must be inside the whole range of the GenericMultiComponent3d.

 slip::Array3d<double> const A1(M); //M is an already existing %GenericMultiComponent3d
 slip::Range<int> range(0,A1.dim1()-1,2);
//display the elements of the line (0,0) of A1 iterated according to the range
std::copy(A1.slice_begin(0,0,range),A1.slice_end(0,0,range),std::ostream_iterator<double>(std::cout," "));

slice_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::slice_end ( const size_type  row, const size_type  col  )

inherited

Returns a read/write iterator that points to the one past the end element of the line (row,col) threw the slices in the GenericMultiComponent3d. Iteration is done in ordinary element order (increasing slice number).

Parameters

row	row coordinate of the line
col	col coordinate of the line

Returns

slice_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Example:

slip::GenericMultiComponent3d<slip::color<double> > A1(10,9,5);
slip::GenericMultiComponent3d<slip::color<double> > A2(10,9,5);
slip::GenericMultiComponent3d<slip::color<double> > S(10,9,5);
//copy A1 in S
std::copy(A1.begin(),A1.end(),S.begin());

const_slice_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::slice_end ( const size_type  row, const size_type  col  ) const

inherited

Returns a read-only (constant) iterator that points to the one past the end element of the line (row,col) threw the slices in the GenericMultiComponent3d. Iteration is done in ordinary element order (increasing slice number).

Parameters

row	row coordinate of the line
col	col coordinate of the line

Returns

const_slice_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Example:

slip::GenericMultiComponent3d<slip::color<double> > const A1(10,9,5);
slip::GenericMultiComponent3d<slip::color<double> > const A2(10,9,5);
slip::GenericMultiComponent3d<slip::color<double> > S(10,9,5);
//copy A1 in S
std::copy(A1.begin(),A1.end(),S.begin());

slice_range_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::slice_end ( const size_type  row, const size_type  col, const slip::Range< int > &  range  )

inherited

Returns a read/write iterator that points one past the end element of the Range range of the of the line (row,col) threw the slices in the GenericMultiComponent3d. Iteration is done in ordinary element order according to the Range.

Parameters

row	row coordinate of the line
col	col coordinate of the line
range	Range of the line to iterate.

Returns

end slice_range_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Precondition

the range must be compatible with the slice dimensions

The range must be inside the whole range of the GenericMultiComponent3d.

Example:

 slip::GenericMultiComponent3d<slip::color<double> > A1(8,8,8);
 slip::GenericMultiComponent3d<slip::color<double> > A2(4,8,8);
 slip::Range<int> range(0,A1.dim1()-1,2);
//copy the the elements of the line (0,0) of A1 iterated according to the
//range in the line (1,1) of A2
std::copy(A1.slice_begin(0,0,range),A1.slice_end(0,0,range),A2.slice_begin(1,1));

const_slice_range_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::slice_end ( const size_type  row, const size_type  col, const slip::Range< int > &  range  ) const

inherited

Returns a read_only iterator that points one past the last element of the Range range of the of the line (row,col) threw the slices in the GenericMultiComponent3d. Iteration is done in ordinary element order according to the Range.

Parameters

row	row coordinate of the line
col	col coordinate of the line
range	Range of the line to iterate.

Returns

end const_slice_range_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Precondition

the range must be compatible with the slice dimensions

The range must be inside the whole range of the GenericMultiComponent3d.

Example:

 slip::GenericMultiComponent3d<slip::color<double> > const A1(8,8,8);
 slip::GenericMultiComponent3d<slip::color<double> > const A2(4,8,8);
 slip::Range<int> range(0,A1.dim1()-1,2);
//copy the the elements of the line (0,0) of A1 iterated according to the
//range in the line (1,1) of A2
std::copy(A1.slice_begin(0,0,range),A1.slice_end(0,0,range),A2.slice_begin(1,1));

component_slice_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::slice_end ( const std::size_t  component, const size_type  row, const size_type  col  )

inherited

Returns a read/write iterator that points to the one past the end element of the line (row,col) threw the slices in the GenericMultiComponent3d. Iteration is done in ordinary element order (increasing slice number).

Parameters

component	The component number.
row	row coordinate of the line
col	col coordinate of the line

Returns

slice_iterator value

const_component_slice_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::slice_end ( const std::size_t  component, const size_type  row, const size_type  col  ) const

inherited

Returns a read-only (constant) iterator that points to the one past the end element of the line (row,col) threw the slices in the GenericMultiComponent3d. Iteration is done in ordinary element order (increasing slice number).

Parameters

component	The component number.
row	row coordinate of the line
col	col coordinate of the line

Returns

const_slice_iterator value

component_slice_range_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::slice_end ( const std::size_t  component, const size_type  row, const size_type  col, const slip::Range< int > &  range  )

inherited

Returns a read/write iterator that points one past the end element of the Range range of the of the line (row,col) threw the slices in the GenericMultiComponent3d. Iteration is done in ordinary element order according to the Range.

Parameters

component	The component number.
row	row coordinate of the line
col	col coordinate of the line
range	Range of the line to iterate.

Returns

end slice_range_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Precondition

the range must be compatible with the slice dimensions

The range must be inside the whole range of the GenericMultiComponent3d.

 slip::Array3d<double> A1(8,8,8);
 slip::Array3d<double> A2(4,8,8);
 slip::Range<int> range(0,A1.dim1()-1,2);
//copy the the elements of the line (0,0) of A1 iterated according to the
//range in the line (1,1) of A2
std::copy(A1.slice_range_begin(0,0,range),A1.slice_range_end(0,0,range),A2.slice_begin(1,1));

const_component_slice_range_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::slice_end ( const std::size_t  component, const size_type  row, const size_type  col, const slip::Range< int > &  range  ) const

inherited

Returns a read_only iterator that points one past the last element of the Range range of the of the line (row,col) threw the slices in the GenericMultiComponent3d. Iteration is done in ordinary element order according to the Range.

Parameters

component	The component number.
row	row coordinate of the line
col	col coordinate of the line
range	Range of the line to iterate.

Returns

end const_slice_range_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Precondition

the range must be compatible with the slice dimensions

The range must be inside the whole range of the GenericMultiComponent3d.

 slip::Array3d<double> const A1(M); //M is an already existing %GenericMultiComponent3d
 slip::Range<int> range(0,A1.dim1()-1,2);
//display the elements of the line (0,0) of A1 iterated according to the range
std::copy(A1.slice_begin(0,0,range),A1.slice_end(0,0,range),std::ostream_iterator<double>(std::cout," "));

reverse_slice_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::slice_rbegin ( const size_type  row, const size_type  col  )

inherited

Returns a read/write iterator that points to the last element of the line (row,col) threw the slices in the GenericMultiComponent3d. Iteration is done in reverse element order (decreasing slice number).

Parameters

row	row coordinate of the line
col	col coordinate of the line

Returns

reverse_slice_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Example:

slip::GenericMultiComponent3d<slip::color<double> > A1(10,9,5);
slip::GenericMultiComponent3d<slip::color<double> > A2(10,9,5);
slip::GenericMultiComponent3d<slip::color<double> > S(10,9,5);
//copy A1 in S
std::copy(A1.rbegin(),A1.rend(),S.rbegin());

const_reverse_slice_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::slice_rbegin ( const size_type  row, const size_type  col  ) const

inherited

Returns a read-only (constant) iterator that points to the last element of the line (row,col) threw the slices in the GenericMultiComponent3d. Iteration is done in reverse element order (decreasing slice number).

Parameters

row	row coordinate of the line
col	col coordinate of the line

Returns

const_reverse_slice_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Example:

slip::GenericMultiComponent3d<slip::color<double> > const A1(10,9,5);
slip::GenericMultiComponent3d<slip::color<double> > const A2(10,9,5);
slip::GenericMultiComponent3d<slip::color<double> > S(10,9,5);
//copy A1 in S
std::copy(A1.rbegin(),A1.rend(),S.rbegin());

reverse_slice_range_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::slice_rbegin ( const size_type  row, const size_type  col, const slip::Range< int > &  range  )

inherited

Returns a read/write iterator that points to the last element of the Range range of the of the line (row,col) threw the slices in the GenericMultiComponent3d. Iteration is done in the reverse element order according to the Range.

Parameters

row	row coordinate of the line
col	col coordinate of the line
range	Range of the line to iterate.

Returns

begin reverse_slice_range_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Precondition

the range must be compatible with the slice dimensions

The range must be inside the whole range of the GenericMultiComponent3d.

Example:

 slip::GenericMultiComponent3d<slip::color<double> > A1(8,8,8);
 slip::GenericMultiComponent3d<slip::color<double> > A2(4,8,8);
 slip::Range<int> range(0,A1.dim1()-1,2);
//copy the the elements of the line (0,0) of A1 iterated according to the
//range in the line (1,1) of A2
std::copy(A1.slice_rbegin(0,0,range),A1.slice_rend(0,0,range),A2.slice_rbegin(1,1));

const_reverse_slice_range_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::slice_rbegin ( const size_type  row, const size_type  col, const slip::Range< int > &  range  ) const

inherited

Returns a read only (constant) iterator that points to the last element of the Range range of the of the line (row,col) threw the slices in the GenericMultiComponent3d. Iteration is done in reverse element order according to the Range.

Parameters

row	row coordinate of the line
col	col coordinate of the line
range	Range of the line to iterate.

Returns

begin const_reverse_slice_range_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Precondition

the range must be compatible with the slice dimensions

The range must be inside the whole range of the GenericMultiComponent3d.

Example:

 slip::GenericMultiComponent3d<slip::color<double> > const A1(8,8,8);
 slip::GenericMultiComponent3d<slip::color<double> > const A2(4,8,8);
 slip::Range<int> range(0,A1.dim1()-1,2);
//copy the the elements of the line (0,0) of A1 iterated according to the
//range in the line (1,1) of A2
std::copy(A1.slice_rbegin(0,0,range),A1.slice_rend(0,0,range),A2.slice_rbegin(1,1));

reverse_component_slice_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::slice_rbegin ( const std::size_t  component, const size_type  row, const size_type  col  )

inherited

Returns a read/write iterator that points to the last element of the line (row,col) threw the slices in the GenericMultiComponent3d. Iteration is done in reverse element order (decreasing slice number).

Parameters

component	The component number.
row	row coordinate of the line
col	col coordinate of the line

Returns

reverse_slice_iterator value

const_reverse_component_slice_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::slice_rbegin ( const std::size_t  component, const size_type  row, const size_type  col  ) const

inherited

Returns a read-only (constant) iterator that points to the last element of the line (row,col) threw the slices in the GenericMultiComponent3d. Iteration is done in reverse element order (decreasing slice number).

Parameters

component	The component number.
row	row coordinate of the line
col	col coordinate of the line

Returns

const_reverse_slice_iterator value

reverse_component_slice_range_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::slice_rbegin ( const std::size_t  component, const size_type  row, const size_type  col, const slip::Range< int > &  range  )

inherited

Returns a read/write iterator that points to the last element of the Range range of the of the line (row,col) threw the slices in the GenericMultiComponent3d. Iteration is done in the reverse element order according to the Range.

Parameters

component	The component number.
row	row coordinate of the line
col	col coordinate of the line
range	Range of the line to iterate.

Returns

begin reverse_slice_range_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Precondition

the range must be compatible with the slice dimensions

The range must be inside the whole range of the GenericMultiComponent3d.

const_reverse_component_slice_range_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::slice_rbegin ( const std::size_t  component, const size_type  row, const size_type  col, const slip::Range< int > &  range  ) const

inherited

Returns a read only (constant) iterator that points to the last element of the Range range of the of the line (row,col) threw the slices in the GenericMultiComponent3d. Iteration is done in reverse element order according to the Range.

Parameters

component	The component number.
row	row coordinate of the line
col	col coordinate of the line
range	Range of the line to iterate.

Returns

begin const_reverse_slice_range_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Precondition

the range must be compatible with the slice dimensions

The range must be inside the whole range of the GenericMultiComponent3d.

reverse_slice_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::slice_rend ( const size_type  row, const size_type  col  )

inherited

Returns a read/write iterator that points to the one before the first element of the line (row,col) threw the slices in the GenericMultiComponent3d. Iteration is done in reverse element order (decreasing slice number).

Parameters

row	row coordinate of the line
col	col coordinate of the line

Returns

reverse_slice_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Example:

slip::GenericMultiComponent3d<slip::color<double> > A1(10,9,5);
slip::GenericMultiComponent3d<slip::color<double> > A2(10,9,5);
slip::GenericMultiComponent3d<slip::color<double> > S(10,9,5);
//copy A1 in S
std::copy(A1.rbegin(),A1.rend(),S.rbegin());

const_reverse_slice_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::slice_rend ( const size_type  row, const size_type  col  ) const

inherited

Returns a read (constant) iterator that points to the one before the first element of the line (row,col) threw the slices in the GenericMultiComponent3d. Iteration is done in reverse element order (decreasing slice number).

Parameters

row	row coordinate of the line
col	col coordinate of the line

Returns

const_reverse_slice_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Example:

slip::GenericMultiComponent3d<slip::color<double> > const A1(10,9,5);
slip::GenericMultiComponent3d<slip::color<double> > const A2(10,9,5);
slip::GenericMultiComponent3d<slip::color<double> > S(10,9,5);
//copy A1 in S
std::copy(A1.rbegin(),A1.rend(),S.rbegin());

reverse_slice_range_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::slice_rend ( const size_type  row, const size_type  col, const slip::Range< int > &  range  )

inherited

Returns a read/write iterator that points to the first element of the Range range of the of the line (row,col) threw the slices in the GenericMultiComponent3d. Iteration is done in reverse element order according to the Range.

Parameters

row	row coordinate of the line
col	col coordinate of the line
range	Range of the line to iterate.

Returns

end reverse_slice_range_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Precondition

the range must be compatible with the slice dimensions

The range must be inside the whole range of the GenericMultiComponent3d.

Example:

 slip::GenericMultiComponent3d<slip::color<double> > A1(8,8,8);
 slip::GenericMultiComponent3d<slip::color<double> > A2(4,8,8);
 slip::Range<int> range(0,A1.dim1()-1,2);
//copy the the elements of the line (0,0) of A1 iterated according to the
//range in the line (1,1) of A2
std::copy(A1.slice_rbegin(0,0,range),A1.slice_rend(0,0,range),A2.slice_rbegin(1,1));

const_reverse_slice_range_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::slice_rend ( const size_type  row, const size_type  col, const slip::Range< int > &  range  ) const

inherited

Returns a read_only iterator that points one past the lastto the first element of the Range range of the of the line (row,col) threw the slices in the GenericMultiComponent3d. Iteration is done in reverse element order according to the Range.

Parameters

row	row coordinate of the line
col	col coordinate of the line
range	Range of the line to iterate.

Returns

end const_reverse_slice_range_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Precondition

the range must be compatible with the slice dimensions

The range must be inside the whole range of the GenericMultiComponent3d.

Example:

 slip::GenericMultiComponent3d<slip::color<double> > const A1(8,8,8);
 slip::GenericMultiComponent3d<slip::color<double> > const A2(4,8,8);
 slip::Range<int> range(0,A1.dim1()-1,2);
//copy the the elements of the line (0,0) of A1 iterated according to the
//range in the line (1,1) of A2
std::copy(A1.slice_rbegin(0,0,range),A1.slice_rend(0,0,range),A2.slice_rbegin(1,1));

reverse_component_slice_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::slice_rend ( const std::size_t  component, const size_type  row, const size_type  col  )

inherited

Returns a read/write iterator that points to the one before the first element of the line (row,col) threw the slices in the GenericMultiComponent3d. Iteration is done in reverse element order (decreasing slice number).

Parameters

component	The component number.
row	row coordinate of the line
col	col coordinate of the line

Returns

reverse_slice_iterator value

const_reverse_component_slice_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::slice_rend ( const std::size_t  component, const size_type  row, const size_type  col  ) const

inherited

Returns a read (constant) iterator that points to the one before the first element of the line (row,col) threw the slices in the GenericMultiComponent3d. Iteration is done in reverse element order (decreasing slice number).

Parameters

component	The component number.
row	row coordinate of the line
col	col coordinate of the line

Returns

const_reverse_slice_iterator value

reverse_component_slice_range_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::slice_rend ( const std::size_t  component, const size_type  row, const size_type  col, const slip::Range< int > &  range  )

inherited

Returns a read/write iterator that points to the first element of the Range range of the of the line (row,col) threw the slices in the GenericMultiComponent3d. Iteration is done in reverse element order according to the Range.

Parameters

component	The component number.
row	row coordinate of the line
col	col coordinate of the line
range	Range of the line to iterate.

Returns

end reverse_slice_range_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Precondition

the range must be compatible with the slice dimensions

The range must be inside the whole range of the GenericMultiComponent3d.

const_reverse_component_slice_range_iterator slip::GenericMultiComponent3d< slip::Vector3d< T > >::slice_rend ( const std::size_t  component, const size_type  row, const size_type  col, const slip::Range< int > &  range  ) const

inherited

Returns a read_only iterator that points one past the lastto the first element of the Range range of the of the line (row,col) threw the slices in the GenericMultiComponent3d. Iteration is done in reverse element order according to the Range.

Parameters

component	The component number.
row	row coordinate of the line
col	col coordinate of the line
range	Range of the line to iterate.

Returns

end const_reverse_slice_range_iterator value

Remarks

This iterator is compatible with RandomAccessIterator algorithms.

Precondition

the range must be compatible with the slice dimensions

The range must be inside the whole range of the GenericMultiComponent3d.

size_type slip::GenericMultiComponent3d< slip::Vector3d< T > >::slice_size ( ) const

inherited

Returns the number of elements in a slice of the GenericMultiComponent3d.

size_type slip::GenericMultiComponent3d< slip::Vector3d< T > >::slices ( ) const

inherited

Returns the number of slices (first dimension size) in the GenericMultiComponent3d.

void slip::GenericMultiComponent3d< slip::Vector3d< T > >::swap ( self &  M )

inherited

Swaps data with another GenericMultiComponent3d.

Parameters

M	A GenericMultiComponent3d of the same element type

template<typename T >

T & slip::DenseVector3dField3d< T >::u ( const size_type  k, const size_type  i, const size_type  j  )

inline

Subscript access to first element of the data contained in the DenseVector3dField3d.

Parameters

k	The index of the slice for which the data should be accessed.
i	The index of the row for which the data should be accessed.
j	The index of the column for which the data should be accessed.

Returns

Read/Write reference to data.

Precondition

k < slices()

i < rows()

j < columns()

This operator allows for easy, 3d array-style, data access. Note that data access with this operator is unchecked and out_of_range lookups are not defined.

Definition at line 1054 of file DenseVector3dField3d.hpp.

template<typename T >

const T & slip::DenseVector3dField3d< T >::u ( const size_type  k, const size_type  i, const size_type  j  ) const

inline

Subscript access to first element of the data contained in the DenseVector3dField3d.

Parameters

k	The index of the slice for which the data should be accessed.
i	The index of the row for which the data should be accessed.
j	The index of the column for which the data should be accessed.

Returns

Read const_reference to data.

Precondition

k < slices()

i < rows()

j < columns()

This operator allows for easy, 3d array-style, data access. Note that data access with this operator is unchecked and out_of_range lookups are not defined.

Definition at line 1063 of file DenseVector3dField3d.hpp.

template<typename T >

T & slip::DenseVector3dField3d< T >::v ( const size_type  k, const size_type  i, const size_type  j  )

inline

Subscript access to second element of the data contained in the DenseVector3dField3d.

Parameters

k	The index of the slice for which the data should be accessed.
i	The index of the row for which the data should be accessed.
j	The index of the column for which the data should be accessed.

Returns

Read/Write reference to data.

Precondition

k < slices()

i < rows()

j < columns()

This operator allows for easy, 3d array-style, data access. Note that data access with this operator is unchecked and out_of_range lookups are not defined.

Definition at line 1091 of file DenseVector3dField3d.hpp.

template<typename T >

const T & slip::DenseVector3dField3d< T >::v ( const size_type  k, const size_type  i, const size_type  j  ) const

inline

Subscript access to second element of the data contained in the DenseVector3dField3d.

Parameters

k	The index of the slice for which the data should be accessed.
i	The index of the row for which the data should be accessed.
j	The index of the column for which the data should be accessed.

Returns

Read const_reference to data.

Precondition

k < slices()

i < rows()

j < columns()

This operator allows for easy, 3d array-style, data access. Note that data access with this operator is unchecked and out_of_range lookups are not defined.

Definition at line 1101 of file DenseVector3dField3d.hpp.

template<typename T >

T & slip::DenseVector3dField3d< T >::Vx1 ( const size_type  k, const size_type  i, const size_type  j  )

inline

Subscript access to first element of the data contained in the DenseVector3dField3d.

Parameters

k	The index of the slice for which the data should be accessed.
i	The index of the row for which the data should be accessed.
j	The index of the column for which the data should be accessed.

Returns

Read/Write reference to data.

Precondition

k < slices()

i < rows()

j < columns()

This operator allows for easy, 3d array-style, data access. Note that data access with this operator is unchecked and out_of_range lookups are not defined.

Definition at line 1037 of file DenseVector3dField3d.hpp.

template<typename T >

const T & slip::DenseVector3dField3d< T >::Vx1 ( const size_type  k, const size_type  i, const size_type  j  ) const

inline

Subscript access to first element of the data contained in the DenseVector3dField3d.

Parameters

k	The index of the slice for which the data should be accessed.
i	The index of the row for which the data should be accessed.
j	The index of the column for which the data should be accessed.

Returns

Read const_reference to data.

Precondition

k < slices()

i < rows()

j < columns()

This operator allows for easy, 3d array-style, data access. Note that data access with this operator is unchecked and out_of_range lookups are not defined.

Definition at line 1046 of file DenseVector3dField3d.hpp.

template<typename T >

T & slip::DenseVector3dField3d< T >::Vx2 ( const size_type  k, const size_type  i, const size_type  j  )

inline

Subscript access to second element of the data contained in the DenseVector3dField3d.

Parameters

k	The index of the slice for which the data should be accessed.
i	The index of the row for which the data should be accessed.
j	The index of the column for which the data should be accessed.

Returns

Read/Write reference to data.

Precondition

k < slices()

i < rows()

j < columns()

This operator allows for easy, 3d array-style, data access. Note that data access with this operator is unchecked and out_of_range lookups are not defined.

Definition at line 1072 of file DenseVector3dField3d.hpp.

template<typename T >

const T & slip::DenseVector3dField3d< T >::Vx2 ( const size_type  k, const size_type  i, const size_type  j  ) const

inline

Subscript access to second element of the data contained in the DenseVector3dField3d.

Parameters

k	The index of the slice for which the data should be accessed.
i	The index of the row for which the data should be accessed.
j	The index of the column for which the data should be accessed.

Returns

Read const_reference to data.

Precondition

k < slices()

i < rows()

j < columns()

This operator allows for easy, 3d array-style, data access. Note that data access with this operator is unchecked and out_of_range lookups are not defined.

Definition at line 1082 of file DenseVector3dField3d.hpp.

template<typename T >

T & slip::DenseVector3dField3d< T >::Vx3 ( const size_type  k, const size_type  i, const size_type  j  )

inline

Subscript access to third element of the data contained in the DenseVector3dField3d.

Parameters

k	The index of the slice for which the data should be accessed.
i	The index of the row for which the data should be accessed.
j	The index of the column for which the data should be accessed.

Returns

Read/Write reference to data.

Precondition

k < slices()

i < rows()

j < columns()

This operator allows for easy, 3d array-style, data access. Note that data access with this operator is unchecked and out_of_range lookups are not defined.

Definition at line 1110 of file DenseVector3dField3d.hpp.

template<typename T >

const T & slip::DenseVector3dField3d< T >::Vx3 ( const size_type  k, const size_type  i, const size_type  j  ) const

inline

Subscript access to third element of the data contained in the DenseVector3dField3d.

Parameters

k	The index of the slice for which the data should be accessed.
i	The index of the row for which the data should be accessed.
j	The index of the column for which the data should be accessed.

Returns

Read const_reference to data.

Precondition

k < slices()

i < rows()

j < columns()

This operator allows for easy, 3d array-style, data access. Note that data access with this operator is unchecked and out_of_range lookups are not defined.

Definition at line 1119 of file DenseVector3dField3d.hpp.

template<typename T >

T & slip::DenseVector3dField3d< T >::w ( const size_type  k, const size_type  i, const size_type  j  )

inline

Subscript access to third element of the data contained in the DenseVector3dField3d.

Parameters

k	The index of the slice for which the data should be accessed.
i	The index of the row for which the data should be accessed.
j	The index of the column for which the data should be accessed.

Returns

Read/Write reference to data.

Precondition

k < slices()

i < rows()

j < columns()

This operator allows for easy, 3d array-style, data access. Note that data access with this operator is unchecked and out_of_range lookups are not defined.

Definition at line 1127 of file DenseVector3dField3d.hpp.

template<typename T >

const T & slip::DenseVector3dField3d< T >::w ( const size_type  k, const size_type  i, const size_type  j  ) const

inline

Subscript access to third element of the data contained in the DenseVector3dField3d.

Parameters

k	The index of the slice for which the data should be accessed.
i	The index of the row for which the data should be accessed.
j	The index of the column for which the data should be accessed.

Returns

Read const_reference to data.

Precondition

k < slices()

i < rows()

j < columns()

This operator allows for easy, 3d array-style, data access. Note that data access with this operator is unchecked and out_of_range lookups are not defined.

Definition at line 1136 of file DenseVector3dField3d.hpp.

template<typename T >

void slip::DenseVector3dField3d< T >::write_tecplot ( const std::string &  file_path_name, const std::string &  title, const std::string &  zone  )

inline

Writes a DenseVector3dField3d to a tecplot file path name.

Parameters

file_path_name
title
zone

The data format is the following:

TITLE= title

VARIABLES= X Y Z U V W

ZONE T= zone, K= dim1(), I= dim2(), J= dim3()

x y z Vx Vy Vz

Definition at line 1289 of file DenseVector3dField3d.hpp.

Friends And Related Function Documentation

template<typename T>

friend class boost::serialization::access

friend

Definition at line 763 of file DenseVector3dField3d.hpp.

Member Data Documentation

const std::size_t slip::GenericMultiComponent3d< slip::Vector3d< T > >::COMPONENTS

staticinherited

Definition at line 313 of file GenericMultiComponent3d.hpp.

template<typename T>

const std::size_t slip::DenseVector3dField3d< T >::DIM = 3

static

Definition at line 201 of file DenseVector3dField3d.hpp.

---

The documentation for this class was generated from the following file:

• src/Container/DenseVector3dField3d.hpp
